To Configure the Print Key Function for Trigger:
1.
Press the console MENU button.
2. Click on Administrator > Print Keys.
3.
Select the desired Print Key tab: Print 1, Print 2 or Print 3.
Note: Each of the three (3) tabs corresponds to one of the three (3) PRINT buttons on the
console: PRINT 1, PRINT 2 and PRINT 3/ARCHIVE.
4.
Select the Trigger option then press OK.
5.
To print a test image on the thermal printer, hit the corresponding console PRINT button.
