SONIX SERIES ULTRASOUND SYSTEM
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SONIX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ultrasonix SONIX Series

Summary of Contents for Ultrasonix SONIX Series

  • Page 1 SONIX SERIES ULTRASOUND SYSTEM USER MANUAL...
  • Page 3 Ultrasonix Medical Corporation SONIX Series Ultrasound System User Manual Ultrasonix Medical Corporation 130 – 4311 Viking Way Richmond, BC V6V 2K9 Canada www.ultrasonix.com 1.866.437.9508 1.604.279.8550 © 2008 Ultrasonix Medical Corporation 00.040.144, Revision E, September 25, 2008 All rights Reserved. Printed in Canada US Patents 6,911,008 –...

  • Page 5: Table Of Contents

    Power Cord: OP, SP, RP, 01 and International (CEP) ................2-10 2.8.2 WIRELESS ADAPTER ............................2-11 TRANSDUCER BASKET (CEP) ..........................2-11 2.10 CABLE HOOKS (CEP) ............................2-11 2.11 CONSOLE COVER ..............................2-12 2.12 SONIX Series User Manual 00.040.144, Revision E Table of Contents...
  • Page 6 4.6.1.1 DICOM Worklist ............................4-17 4.6.2 Manipulating the DICOM Worklist Database.................4-18 4.6.2.1 PracticeHwy Worklist ...........................4-20 4.6.3 Manipulating the PracticeHwy Worklist Database.................4-21 4.6.3.1 Hide ................................4-21 4.6.4 USER-DEFINED PRESETS FOR NON-3D/4D FORMATS ..................4-22 Table of Contents 00.040.144, Revision E SONIX Series User Manual...
  • Page 7 Optimizing a 3D Image ..........................5-37 5.6.6 Optimizing a 4D Image ..........................5-39 5.6.7 3D/4D Active Rotation ..........................5-43 5.6.8 4D and CINE ............................... 5-44 5.6.9 5.6.10 User-Defined Presets for 3D/4D........................5-44 SONIX Series User Manual 00.040.144, Revision E Table of Contents...
  • Page 8 6.4.2 OPTIMIZATION/EDITING OF ACQUIRED IMAGES ....................6-31 4D AND CINE ................................6-32 PRESETS ................................6-32 Resetting Factory Defaults...........................6-32 6.7.1 Selecting a Default USER (Preset) ......................6-33 6.7.2 User-Defined Presets ..........................6-34 6.7.3 Loading Presets............................6-35 6.7.4 Table of Contents 00.040.144, Revision E SONIX Series User Manual...
  • Page 9 TEXT AND ANNOTATIONS ............................8-1 Keyboard Text ............................... 8-1 8.1.1 Set Text Home Position..........................8-2 8.1.2 Application-Specific Annotations ........................8-2 8.1.3 Deleting Text/Annotation ..........................8-3 8.1.4 Text Arrow ..............................8-3 8.1.5 PICTOGRAMS ................................8-4 SONIX Series User Manual 00.040.144, Revision E Table of Contents...
  • Page 10 LCD Display ..........................9-72 9.2.5.2 VCR/Photo ............................9-73 9.2.5.3 Footswitch.............................9-74 9.2.5.4 Brightness/Contrast ........................9-75 9.2.5.5 Patient Settings............................9-76 9.2.6 Status Bar ..............................9-79 9.2.7 Capture Settings ............................9-82 9.2.8 Software Update ............................9-83 9.2.9 9.2.10 Licensing..............................9-85 SERVICE MENU..............................9-86 Table of Contents 00.040.144, Revision E SONIX Series User Manual...
  • Page 11 A.6.1 SONIX OP/SP/RP/01 and CEP ........................A-5 A.6.2 Additional Hardware ............................A-5 ENVIRONMENTAL CONDITIONS ..........................A-6 A.7.1 SONIX OP/SP/RP/01 ............................A-6 A.7.2 SONIX CEP ..............................A-6 A.7.3 Additional Hardware ............................A-7 LIMITING TRANSDUCER SURFACE HEATING ......................A-8 LATEX ..................................A-8 SONIX Series User Manual 00.040.144, Revision E Table of Contents...
  • Page 12 APPENDIX F: REFERENCES ............................F-1 OB REFERENCES ..............................F-1 Gestational Age Tables ..........................F-2 F.1.1 Growth Analysis Tables ..........................F-4 F.1.2 GENERAL AND CARDIAC REFERENCES......................F-5 APPENDIX G: GLOSSARY ............................. G-1 Table of Contents 00.040.144, Revision E SONIX Series User Manual viii...

  • Page 13: Chapter 1: Introduction

    CHAPTER 1: INTRODUCTION AUDIENCE This user manual is a reference for operators using a SONIX Series ultrasound system. It is designed for a reader familiar with ultrasound imaging techniques; it does not provide training in sonography or clinical practices. Before using the system the operator must have ultrasound training.

  • Page 14: Updates

    It is the user's responsibility to ensure the SONIX CEP is used only under the electrical conditions dictated by Ultrasonix Medical Corp. Failure to comply with these conditions may result in damage to the system which is not covered by the Ultrasonix warranty.

  • Page 15: Privacy Disclaimer

    Buyer further agrees that (i) any of the Ultrasonix suppliers of software is a direct and intended beneficiary of this end-user sublicense and may enforce it directly against Buyer with respect to software supplied by such...

  • Page 16: Trademarks And Patents

    TRADEMARKS AND PATENTS Ultrasonix SONIX systems are protected under US patents 6,911,008 – 6,558,326 – 6,325,759. © Windows is a trademark of Microsoft Corporation. ® DICOM (Digital Imaging and Communications in Medicine) is the registered trademark of the National Electrical Manufacturers Association (NEMA) for its standards publications relating to digital communications of medical information.

  • Page 17: Chapter 2: Sonix Introduction

    CHAPTER 2: SONIX INTRODUCTION Congratulations on your purchase of the Ultrasonix SONIX Ultrasound system. The SONIX is a high quality, easy to use diagnostic ultrasound system that is stable, highly mobile and designed to be convenient and comfortable to operate.
  • Page 18 Locking Wheels. (This style of wheel only available on the OP, 01 and CEP). Uninterruptible Power Supply Note: All SONIX OP, 01 and CEP wheels lock in a single position. Chapter 2: SONIX Introduction 00.040.144, Revision E SONIX Series User Manual...

  • Page 19: Operator Console

    Thumb Grips for Rotating the Console on SP and RP Models Note: Some features may not be available on all system configurations. Refer to Appendix B: System Specifications for details. SONIX Series User Manual 00.040.144, Revision E Chapter 2: SONIX Introduction...
  • Page 20 (e.g., toggle between image fields on dual/quad image, toggle UPDATE Button between 2D and Doppler Trace image fields, toggles the active caliper, etc) as well as "Right Click" mouse button functionality. Chapter 2: SONIX Introduction 00.040.144, Revision E SONIX Series User Manual...
  • Page 21 Adjusts the steering angle dependent on the active imaging mode: • Color Doppler Region of Interest (ROI) box STEER Toggle Button • PW Doppler sample line • B-Mode/2D beam on linear transducers. SONIX Series User Manual 00.040.144, Revision E Chapter 2: SONIX Introduction...
  • Page 22 The method selected appears in an information bubble to the bottom right of the image screen. Refer to Chapter 7: Clinical Analysis for further details. Chapter 2: SONIX Introduction 00.040.144, Revision E SONIX Series User Manual...

  • Page 23: System Case

    Contact your local service representative for further information. Refer to the SONIX Series Service Manual for complete details about the system case. Warning: Do not touch the patient and the transducer ports simultaneously. BACK CONNECTIVITY PANEL The Back Connectivity Panel is located on the tower which extends up from the back of the system case.

  • Page 24: Ups (Cep)

    2.6.1 UPS Use Model Ultrasonix recommends that all users adhere to the following use model. Failure to adhere to this use model may lead to premature battery failure. In these circumstances, battery replacement will not be covered by the warranty.

  • Page 25: Ups Emergency Power Off Switch (Cep)

    Once the EPO switch is pressed, unplug the power cord from the wall outlet. IMPORTANT: Use this switch only in the event of an emergency. Once turned off, the CEP will be completely disabled until your internal service provider or a certified Ultrasonix Service Technician can reset the system.

  • Page 26: Power Cord

    It may also damage the cable reel, leading to further hazards when operating the system. Should the cable reel require maintenance or replacement, contact Ultrasonix Technical Support. DO NOT use excessive force when extending or retracting the cord. This can cause the cord to separate from the reel and potentially expose anyone in the vicinity to lethal voltages.

  • Page 27: Wireless Adapter

    User Guide included with the system. 2.10 TRANSDUCER BASKET (CEP) The SONIX CEP comes equipped with a factory-installed transducer basket sized to hold the Ultrasonix EC9-5/10 Endocavity Transducer. The basket end-notches allow the transducer cable to hang freely. Figure 2-4: Transducer Basket 2.11 CABLE HOOKS (CEP)

  • Page 28: Console Cover

    OP, SP or RP, refer to the latest price list for details on purchasing this item. See 11.10 Console Cover for details on installing or replacing the console cover. Chapter 2: SONIX Introduction 00.040.144, Revision E SONIX Series User Manual 2-12...

  • Page 29: Chapter 3: Getting Started

    If it’s no longer connected, the system will default to the first available transducer. This default transducer selection is not affected even if the system is turned off between exams. SONIX Series User Manual 00.040.144, Revision E Chapter 3: Getting Started...

  • Page 30: Qsonix Feature

    If desired, after initial access to the QSONIX feature, use the trackball and SELECT button to check the Skip Welcome Page checkbox in order to remove hide this page. Chapter 3: Getting Started 00.040.144, Revision E SONIX Series User Manual...

  • Page 31: Quick Exam Start-Up

    Welcome Page button (which is only visible when the page is skipped). Select Skip to prevent the Welcome Page from appearing the next time the QSONIX button is selected. SONIX Series User Manual 00.040.144, Revision E Chapter 3: Getting Started...
  • Page 32 Exam Type/Application will be available. If the selected Application is not compatible with the currently connected transducers, the system will prompt for a different transducer. Users can also click Back twice and select a different Application. Chapter 3: Getting Started 00.040.144, Revision E SONIX Series User Manual...
  • Page 33 Note: If additional patient information is required select More… to open the full Exam Management data entry page. Refer to Chapter 4: Patient Management for complete details on Exam Management data entry. Select Start Exam to begin imaging. SONIX Series User Manual 00.040.144, Revision E Chapter 3: Getting Started...

  • Page 34: Operator Console Tutorial

    Select SONIX Console Tutorial and a brief, onscreen description will be presented when any console button, dial or knob is activated. Select Exit Tutorial to return to the Welcome to QSONIX page. Chapter 3: Getting Started 00.040.144, Revision E SONIX Series User Manual...

  • Page 35: Online User Manual Access

    Ensure the console TEXT button is not active and that all Windows dialog boxes are closed. Press the console keyboard "u" key. To Close the User Manual PDF: Click the "X" in the upper right corner of the PDF window. SONIX Series User Manual 00.040.144, Revision E Chapter 3: Getting Started...

  • Page 36: Online Live Chat Support

    3.3.4 Online Live Chat Support The Online Support feature is a real-time help discussion with the Ultrasonix Technical Support team. Refer to 9.2.2 Network to configure the system for live chat support and network connectivity. To Access Online Live Chat Support: Press the console QSONIX button.

  • Page 37: Chapter 4: Patient Management

    (e.g., punctuation marks, symbols and letters from other languages Local tab Worklist tab (if enabled in DICOM or PracticeHwy) Hide tab (blanks patient data to preserve privacy) SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...
  • Page 38 DICOM Configuration). In order to actually update Worklist data, the system must also have an active connection to a DICOM server. To Access the Exam Management Page: Press the console ID button. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual...

  • Page 39: Patient Information

    Options in Table 9-25: Patient Settings for details. Note: All these fields can be completed using the barcode reader. Simply ensure the cursor is in the required field and scan the relevant barcode. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...
  • Page 40 Note: Fields that will accept data entry via the keyboard will also accept data scanned with the barcode reader. Simply ensure that the cursor is located in the required field then scan the relevant barcode. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual...

  • Page 41: Application Information

    Cardiac calculations. Follicular • LMP (Last Menstrual Period) • Exp. Ovul. (Expected Date of Ovulation) • Day of Cycles • Gravida, Para and Aborta fields. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...
  • Page 42 • Previous Exam enables the entry of previous OB exam data for fetal trending (refer to 4.1.2.1 OB Previous Exams for details). Other • Height and Weight have both metric and imperial measurement options • BSA is auto-calculated and displayed once Height/Weight is entered. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual...
  • Page 43 The application-related data entry fields to the left side of the Application Information section change with the selection of the various applications. Note: The Application selected here is not tied to an Imaging Preset or Exam Type/Application. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...

  • Page 44: Ob Previous Exams

    Note: Trending data from previous exams stored on the system does not appear in this list. Instead, it is displayed on the individual trending graph OB report pages with an active patient. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual...

  • Page 45: Exam Information

    Label 1, 2, and 3. Note: All these fields can be completed using the barcode reader. Simply ensure the cursor is in the required field and scan the relevant barcode. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...
  • Page 46 Note: Fields that will accept data entry via the keyboard will also accept data scanned with the barcode reader. Simply ensure that the cursor is located in the required field then scan the relevant barcode. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-10...

  • Page 47: Selecting A Transducer

    Note: If an Imaging Preset has been hidden, it will not be available for selection from the touch screen (or QSONIX). This option applies to both default and user-defined Imaging Presets. Refer to 9.1.1.1 Show/Hide Imaging Presets, for more details. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...

  • Page 48: Beginning An Exam For A New Patient

    Note: Fields that will accept data entry via the keyboard will also accept data scanned with the barcode reader. Simply ensure that the cursor is located in the required field then scan the relevant barcode. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-12...

  • Page 49: Ending An Exam

    DICOM and PracticeHwy cannot be configured for use at the same time. Select this tab to blank out the patient data on the Exam Management page. This feature provides Hide data privacy. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management 4-13...

  • Page 50: Local

    Information section. Date of the Last Exam performed on the patient (if applicable). Last Exam (Number of) Images Total number of Images stored for the patient's most recent exam. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-14...

  • Page 51: Manipulating The Local Database

    When the list has been narrowed sufficiently (e.g., to one Patient ID or all patients with the desired Last Name), use the trackball and SELECT button to choose the desired patient. Press ENTER. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...
  • Page 52 Note: To change the order of the list (e.g., from numerical by Patient ID number to alphabetical by Last Name), position the cursor over the relevant Field Header and press SELECT. To reverse the order press SELECT again. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-16...

  • Page 53: Dicom Worklist

    (mm/dd/yyyy), End Date (mm/dd/yyyy), Exam Type, Procedure ID, Station AE Title, Station Location and Modality Type. Figure 4-5: Exam Management Page (DICOM Worklist) Search Worklist Button Update Worklist Button Worklist Tab Figure 4-6: DICOM Worklist Search Page SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management 4-17...

  • Page 54: Manipulating The Dicom Worklist Database

    Note: The parameters from the last search will be retained for the duration of the current (computer-defined) date. Note: Worklist Search results are limited to a maximum of 100 records. Any result list longer than 100 records will be truncated. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-18...
  • Page 55 If it no longer connected, the system will default to the first available transducer. This default transducer selection is not affected even if the system is turned off between exams. SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management...

  • Page 56: Practicehwy Worklist

    4.6.3 PracticeHwy Worklist Users wishing to configure the system for use with PracticeHwy must contact Ultrasonix Technical Support. Note: An Internet connection must be available and configured for use with Remote Support (9.2.2.5 Online Remote Support) in order to allow Ultrasonix Technical Support to install the relevant software add-ons.

  • Page 57: Manipulating The Practicehwy Worklist Database

    This is very useful when an Operator needs to quickly protect the privacy of patient data that would otherwise be visible to anyone within viewing distance. To reveal patient data, simply click another database tab. Figure 4-9: Hide Tab SONIX Series User Manual 00.040.144, Revision E Chapter 4: Patient Management 4-21...

  • Page 58: User-Defined Presets For Non-3D/4D Formats

    The user-defined Preset will now be available on the Imaging Presets page under the selected Application. Note: For more details on the Imaging Presets page, refer to 9.1.1 Presets. Chapter 4: Patient Management 00.040.144, Revision E SONIX Series User Manual 4-22...

  • Page 59: Chapter 5: Imaging

    Note: Not all imaging modes or features are available with all system configurations. Refer to Appendix B: System Specifications for feature availability. 2D/M-MODE When first entering M-Mode, all factory supplied Imaging Presets will default to the maximum Zoom setting. Note: This will not affect user-defined Presets. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 60: B-Mode)

    • Penetration: lowest frequency • EPI: greater penetration and improved contrast resolution for the technically difficult patient. Note: EPI is only available for use with the C5-2/60 curved array transducer. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual...
  • Page 61 Note: Press the B-MODE button/dial to exit other imaging modes (Color, PW Doppler, M- Mode, Panoramic, 3D, etc.) at any time during the imaging session and return to 2D imaging. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 62 Adjusts the color Maps of the 2D image: 0 to 7. Chroma Adjusts the level of visual smoothing of the 2D image. Persist Adjusts the grayscale Map: 1 to 9. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual...
  • Page 63 Use the touch screen dial below the column containing the desired selection to make the adjustment to the imaging parameter (e.g., turn dial left to decrease Persistence or right to increase Persistence). SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 64: Clarity (Speckle Reduction)

    To reduce the level of magnification, press the ZOOM toggle button down to the desired level. To exit the Zoom feature, press the B-MODE button to return to 2D imaging. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 65: Dual Imaging Format

    Press UPDATE to toggle back and forth between the dual images, freezing the inactive image and unfreezing the newly active image. Press B-MODE to exit Dual imaging. Note: Color Doppler is available during Dual but not Quad imaging. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 66: Quad Imaging Format

    (UPDATE only or FREEZE and UPDATE), the images will be active or frozen, respectively. Press DUAL/QUAD or B-MODE to exit Quad imaging. Note: Color Doppler is available during Dual but not Quad imaging. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 67: M-Mode Imaging Mode

    Tap the touch screen M-Mode tab. Tap desired selection (e.g., Chroma). Use the touch screen dial below the column containing the desired selection to make the adjustment to the imaging parameter. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 68: Cine Clip Storage And Thumbnail Image/Clip Review

    Use to select end frame for CINE clip, one (1) frame at a time. Use to select CINE Play Speed (⅛, ¼, ½, full (1) or double (2)). Play Speed Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-10...
  • Page 69 Figure 5-5: CINE Frame Indicators Current Frame/Total # of Frames Available Start… End Frames (Select Start and End Frames for clip storage) Appears when CINE clip storage is in progress. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-11...

  • Page 70: Stored Thumbnail Review

    Tap the touch screen Review tab. Tap desired selection (e.g., Speed). Use the touch screen dial below the column containing the desired selection to make the adjustment to the CINE Review. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-12...

  • Page 71: Color/Power Doppler

    Color Doppler Imaging Parameters Figure 5-7: Color Doppler Imaging Parameters Color Gain Pulse Repetition Frequency FrC – Frequency of transducer in Color mode Wall Filter PersistC – Color Persistence Color Color Map SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-13...
  • Page 72 Note: Decreasing the Frame Rate increases color quality providing higher color line density. Increasing the Frame Rate decreases color quality. Adjusts the size of the Color ROI box horizontally. Box Width Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-14...

  • Page 73: Color Doppler Imaging Mode

    PW cursor/Gate positioning. Alternate controls are available on the Color tab to resize the Color ROI box. The Color ROI box moves with the PW cursor. Press COLOR to exit Color Doppler imaging. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 74: Color Power Doppler Imaging Mode

    Freezing the image will freeze both sides simultaneously. To exit the simultaneous 2D/Color and 2D imaging mode, tap Simult 2D/Color located under the touch screen Color tab. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-16...

  • Page 75: Pulsed Wave (Pw) Doppler And Triplex

    B (2D with and without Color) Active B/PW (Simultaneous 2D and Doppler Trace) Active B/C (2D with Color) Press UPDATE to toggle control between modes. Triplex Press UPDATE to toggle control between modes. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-17...
  • Page 76 Press to Steer Doppler cursor angle right or left. Also used to steer Color ROI box and STEER button 2D linear image field. The DOPPLER VOLUME control dial is located to the left of the touch screen on the operator console. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-18...
  • Page 77 Tap the desired selection (e.g., PW Gate size). Use the dial below the relevant touch screen column to adjust the imaging parameter (e.g., turn dial left to decrease Gate size/turn dial right to increase Gate size). SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 78: Pulsed Wave (Pw) Doppler Imaging Mode

    Press UPDATE to display a live Doppler Trace and a frozen 2D image/cursor. Press UPDATE to toggle back and forth between PW Trace and 2D/cursor. Press B-MODE to exit PW imaging mode. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-20...

  • Page 79: Triplex Imaging Mode

    PW, Active B/C and Triplex imaging modes. If required, tap Layout to move to the appropriate Split Imaging selection. To return to Duplex imaging, tap Triplex on the touch screen. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...

  • Page 80: Elastography

    Elastography is used to measure tissue stiffness. Note: Elastography is a licensed option that is not available in all markets. Consult your local dealer or Ultrasonix Technical Support to determine availability in your area. Elastography is only available with a linear transducer.
  • Page 81 Adjusts the Elastography Persistence. The range is 0 to 6. Persist To Activate Elastography Imaging Mode: Press the console PROBE button. Select a linear transducer. Press the console ELASTOGRAPHY button. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-23...

  • Page 82: Panoramic Imaging Mode

    Caution: Measurements performed on the acquired Panoramic image may be inaccurate as the accuracy of the geometric re-composition is very user-dependent. Measurements performed on the acquired Panoramic image should be used for informational purposes only. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-24...
  • Page 83 Caution: Measurements performed on the acquired Panoramic image may be inaccurate as the accuracy of the geometric re-composition is very user-dependent. Measurements performed on the acquired Panoramic image should be used for informational purposes only. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-25...

  • Page 84: Freehand 3D And Standard 3D/4D Imaging

    Sets the Orientation of the VR. Reset applies to this option. VR Orient Note: This setting is tracked under Current Display on the right side of the LCD display. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-26...
  • Page 85 Note: This setting is tracked under Current Display on the right side of the LCD display. Rotates the selected image about the X-axis. X-axis Rotates the selected image about the Y-axis. Y-axis Rotates the selected image about the Z-axis. Z-axis SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-27...
  • Page 86 Top, Bottom, Left, Right, Front and Back. Reset applies to this option. VR View Note: This setting is tracked under Current Display on the right side of the LCD display. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-28...
  • Page 87 Note: 4D images default to the A|VR dual image screen. For more information on adjusting the items in Current Display, refer to the appropriate fields in the tables beginning on page 5-26. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 88 Note: To move a selected item (e.g., the Acquisition Plane ROI) use the trackball to position the cursor, press the console SELECT button and use the trackball to drag the desired item to its new position. Press SELECT again to complete the action. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-30...

  • Page 89: Freehand 3D Imaging (All Non-4D Sonix Transducers)

    FREEZE button is pressed and present the following message bubble. The acquired image will be rendered to the LCD display in the A|B|C|VR format. Note: Use the 3D/4D Main touch screen selections to change the viewing format. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 90 Select OK to complete the configuration. The acquired image will be rendered to the LCD display in the A|B|C|VR format. Note: Use the 3D/4D Main touch screen selections to change the viewing format. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-32...

  • Page 91: Imaging (Sonix 4D Transducer)

    The acquired 3D rendering with its associated views will be presented on the LCD display. Note: See 5.6.5 3D/4D Image Formats for the LCD Display for details on image views. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 92 Slowly move the transducer over the area of interest. Press the console FREEZE button to complete the acquisition. Note: See 5.6.5 3D/4D Image Formats for the LCD Display for details on image views. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-34...

  • Page 93: Specific Lcd Display Details

    Volumes per Second (VPS) setting. VPS is auto-calculated based on the FOV and Quality settings. It cannot be edited. (Volumes per Second) MI (Mechanical Index) The MI is displayed for informational purposes only. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-35...

  • Page 94: 4D Image Formats For The Lcd Display

    MPR Rendering will be displayed in place of the VR image. Figure 5-17: MPR Rendering Presentation Settings The combined settings of VR Orient and VR View determine the initial MPR Rendering presentation (far left). Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-36...

  • Page 95: Optimizing A 3D Image

    Check Enable MPR ROI, then the Position radio button to adjust the location of the ROI rectangle (solid line). Press the console SELECT button then use the trackball to drag the image to the desired position (in either the A, B or C Plane). SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-37...
  • Page 96 Rotation for details on this functionality. To undo the changes made to the image, tap Reset on 3D/4D Main. Note: Reset will return many, but not all, settings to their original positions. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-38...

  • Page 97: Optimizing A 4D Image

    Press the console SELECT button, then use the trackball to drag the ROI rectangle to the desired dimension (in either the A, B or C Plane). Press SELECT again to lock in the Size of ROI rectangle. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 98 Rotation for details on this functionality. To undo the changes made to the image, tap Reset on 3D/4D Main. Note: Reset will return many, but not all, settings to their original positions. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-40...
  • Page 99 Press the console SELECT button, then use the trackball to drag the ROI rectangle to the desired size (in either the A, B or C Plane). Press SELECT again to lock in the Size of ROI rectangle. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 100 Rotation for details on this functionality. To undo the changes made to the image, tap Reset on 3D/4D Main. Note: Reset will return many, but not all, settings to their original positions. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-42...

  • Page 101: 4D Active Rotation

    Table 5-24: Sample VR Image with Axes, Boundary Box and Reference Planes Axes: green, blue and red arrows. Boundary Box: exterior yellow box. Reference Planes: green, blue and red boxes. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging 5-43...

  • Page 102: And Cine

    Invalid Preset Name warning bubble. If this happens, click Cancel to exit, or type in a different name and select OK to accept it. Select OK to save the Preset Name or Cancel to exit without saving. Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-44...
  • Page 103 Invalid Preset Name warning bubble. If this happens, and click Cancel to exit or type in a different name and select OK to accept it. Select OK to save the Preset Name or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 5: Imaging...
  • Page 104 Chapter 5: Imaging 00.040.144, Revision E SONIX Series User Manual 5-46...

  • Page 105: Chapter 6: Advanced 3D/4D Imaging

    (refer to 11.4 Advanced 3D/4D Software Dongle for details on dongle location). IMPORTANT: The software dongle supplied by Ultrasonix must be connected to connection point 7 on the System Case Connectivity Panel at all times in order to access Advanced 3D/4D Imaging.
  • Page 106 Exam Management page and select a patient. Tap Obstetrics or Skeletal on the touch screen. Tap 3D or 4D on the touch screen. Press the console UPDATE button to begin imaging. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 107: Touch Screen Options

    3D/4D Volume Rendering (VR) of the image. Displays only the Volume Rendering of the 3D/4D image. Displays side-by-side, split-screen view of the Coronal Plane (C) image with a C|VR 3D/4D VR image. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 108 Rotates the selected image about the Z-axis. Z-axis Sets the Orientation of the VR. VR Orient Note: To exit 3D/4D imaging at any time, tap the 4D Main tab then tap Exit. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 109: Advanced

    4D Advanced and Sculpt…. Note: 4D Advanced, Sculpt… options (below) cannot be applied during image acquisition. Figure 6-3: 4D Advanced Touch Screen Controls Figure 6-4: 4D Sculpt Touch Screen Controls SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 110 Rotates the selected image about the X-axis. X-axis Rotates the selected image about the Y-axis. Y-axis Rotates the selected image about the Z-axis. Z-axis Sets the Orientation of the VR. VR Orient Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 111: Display

    LCD display will also change. Note: In MEASURE MODE, the CONTRAST setting will change, but the effect will only be visible in DISPLAY, SLICE, RENDER and USERSET MODES (6.3). SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 112 Tap/dial to suppress image artifacts or noise with a Threshold adjustment. Threshold Note: The Dynamic Range of the image will be optimized automatically based on the selected Threshold setting. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual...

  • Page 113: Cine

    Use to select end frame for CINE clip, one (1) frame at a time. Use to select CINE Play Speed (⅛, ¼, ½, full (1) or double (2)). Play Speed SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...

  • Page 114: Measurements

    Stenosis % Area Measures Stenosis percentage based on the Area of a user-drawn Ellipse. Note: Use the trackball to position the cursor and the console SELECT button to anchor the calipers for each step of each measurement. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-10...

  • Page 115: Lcd Display Options

    To move a slider to a new position, position the mouse arrow over the slider, press the console SELECT button then use the trackball to move the slider. Press SELECT again to anchor the slider in the new position. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...

  • Page 116: Display Mode

    To move a slider to a new position, position the mouse arrow over the slider, press the console SELECT button then use the trackball to move the slider. Press SELECT again to anchor the slider in the new position. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-12...
  • Page 117 Note: This setting can also be adjusted from the 4D Display touch screen with the 3D Map button (6.2.3). The touch screen Reset button applies to this setting. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 118 Note: This setting can also be adjusted from the 4D Display touch screen with the 3D Cntrst Pos button (6.2.3). The touch screen Reset button applies to this setting. Figure 6-10: DISPLAY MODE – Axis Planes (Niche Mode) Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-14...

  • Page 119: Measure Mode

    Note: Use the trackball and console SELECT button to click on the various onscreen buttons. Use the trackball to position the cursor and the console SELECT button to anchor the calipers for each step of each measurement. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 120 Ellipse + Line Not in use. Sphere Clears all measurements, Text and Arrows from the image. CLEAR Note: The default MEASURE MODE is with no measurement settings selected. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-16...

  • Page 121: Slice Mode

    To move a slider to a new position, position the mouse arrow over the slider, press the console SELECT button then use the trackball to move the slider. Press SELECT again to anchor the slider in the new position. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 122 Side by Side Note: Refer to Figure 6-13 to determine the order in which the slices are presented. Displays the SLICE MODE image as a Single image. Single Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-18...
  • Page 123 3D Map button (6.2.3), but only if 3D (above) is selected on the LCD display. 3D Map changes will apply to the VR. The touch screen Reset button applies to this setting. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 124 3D Cntrst Pos button (6.2.3) but only if 3D (above) is selected on the LCD display. 3D Cntrst Pos changes will apply to the The touch screen Reset button applies to this setting. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-20...

  • Page 125: Render Mode

    To move a slider to a new position, position the mouse arrow over the slider, press the console SELECT button then use the trackball to move the slider. Press SELECT again to anchor the slider in the new position. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...
  • Page 126 Note: For the VR, this setting can also be adjusted from the 4D Display touch screen with the 3D Map button (6.2.3). The touch screen Reset button applies to this setting. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-22...
  • Page 127 Note: For the VR, this setting can also be adjusted from the 4D Display touch screen with the 3D Cntrst Pos button (6.2.3). The touch screen Reset button applies to this setting. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...

  • Page 128: Userset Mode

    To move a slider to a new position, position the mouse arrow over the slider, press the console SELECT button then use the trackball to move the slider. Press SELECT again to anchor the slider in the new position. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-24...
  • Page 129 Table 6-11: USERSET MODE Options Pre-configured for use with the Skeletal Preset option presented on the first 3D/4D touch screen (Figure 6-1). Note: Ultrasonix does not recommend editing the Preset parameters for USER 1 USER 1. The 4D Main touch screen Reset button applies to this setting.
  • Page 130 Note: For the VR, this setting can also be adjusted from the 4D Display touch screen with the 3D Cntrst Pos button (6.2.3). The touch screen Reset button applies to this setting. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-26...

  • Page 131: Additional Lcd Display Details

    The GainB setting is taken from the last Gain setting used while in 2D B- Mode. GainB Note: To edit this setting, the operator must exit Advanced 3D/4D and enter 2D B-Mode. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging 6-27...

  • Page 132: Image Acquisition

    On occasion, color is used to highlight the A, B and C Planes. Figure 6-18: Image Quadrants Green: Acquisition Plane (A) Blue: Transverse Plane (B) Perpendicular to the Acquisition Plane Red: Coronal Plane (C) Volume Rendering (VR) Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-28...
  • Page 133 6.4.1 3D Imaging To Acquire a 3D Image with an Ultrasonix 4D Transducer: Ensure a 4D transducer is connected to the system. Note: The 4D transducer must be inserted into the upper most transducer connection port to ensure proper function.

  • Page 134: Imaging

    Press the console FREEZE button to complete the acquisition. The final image of acquired 4D CINE file will be presented on the LCD display in the default format A|VR. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-30...

  • Page 135: Optimization/Editing Of Acquired Images

    If there are any saved images less than 24 hours old, they will be presented as thumbnails on the bottom left of the imaging screen. Click on the desired thumbnail to open the image for editing. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging...

  • Page 136: And Cine

    MODE provides the ability to return these Presets to their factory default settings, providing the changes have not been saved. Note: Ultrasonix does not recommend editing the Preset parameters for USER 1 and 2. To Reset USER 1 and USER 2 to Factory Defaults: Note: Ultrasonix does not recommend editing the factory default Preset parameters for USER 1 and 2.

  • Page 137: Selecting A Default User (Preset)

    6.7.2 Selecting a Default USER (Preset) For convenience, Ultrasonix has configured Advanced 3D/4D to enable the user to select a default Preset to be applied to every image immediately after acquisition. When this default is not appropriate, the user has the option to load a different one (6.7.4 Loading Presets).

  • Page 138: User-Defined Presets

    On the LCD display, move to USERSET MODE. Click on USER 3, 4 or 5. Note: Ultrasonix does not recommend editing the Preset parameters for USER 1 and 2. To save the parameters of the new Preset, click SAVE. Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E...

  • Page 139: Loading Presets

    On the LCD display, move to USERSET MODE. Click on one of the four (4) USER Presets not currently active. Click LOAD to activate the selected Preset. SONIX Series User Manual 00.040.144, Revision E Chapter 6: Advanced 3D/4D Imaging 6-35...
  • Page 140 Chapter 6: Advanced 3D/4D Imaging 00.040.144, Revision E SONIX Series User Manual 6-36...

  • Page 141: Chapter 7: Clinical Analysis

    The measurement/calculation package defaults to the Exam Type/Application selected. For example, the Obstetrical calculation package is the default when an OB Application is selected. To access measurements specific to an alternate Application, tap Select App on the touch screen. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...
  • Page 142 The method selected appears in a message bubble on the lower right corner of the LCD display and becomes the default. % Area Red e.g., for Area, measurement is set to Continual Trace ‹‹ | ›› Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual...

  • Page 143: Basic Measurements

    Note: To reposition the first caliper, press UPDATE to toggle control between the two calipers. Press SELECT to set the measurement. The measurement value will appear on the bottom of the LCD display. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 144: Area Or Circumference (Area/Circ) Measurement

    Use the trackball to trace the Circumference of the area of interest. Press SELECT to set the trace. The Area and Circumference values will appear on the bottom right of the LCD display. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual...

  • Page 145: Ellipse Method Area Or Circumference Measurement

    Note: Press UPDATE to toggle control of the calipers/Ellipse prior to completion of the measurement. Press SELECT to complete the Ellipse measurement. The Area and Circumference values will appear on the bottom right of the LCD display. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 146: Volume Calculation

    All three (3) measurements must be completed to calculate the Volume. Between FREEZE and UNFREEZE, until the Volume calculation is complete, the measurement values will reappear on the LCD display each time the console MEASURE button is pressed. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual...

  • Page 147: Percent Diameter Reduction Calculation (% Diam Red)

    The resulting % Diameter Reduction will be presented on the bottom right of the LCD display along with the inner and outer diameter measurements that were used in the calculation. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 148: Percent Area Reduction Calculation (% Area Red)

    Uses the Trace method for both outer and inner measurements. Trace/Trace Uses the Trace method for the outer measurement and the Ellipse method for the Trace/Ellipse inner measurement. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual...

  • Page 149: Ellipse/Ellipse Method Of Percent Area Reduction Calculation (% Area Red)

    The resulting % Area Reduction will be presented on the bottom right of the LCD display along with the inner and outer measurements that were used in the calculation. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 150: Ellipse/Trace Method Of Percent Area Reduction Calculation (% Area Red)

    The resulting % Area Reduction will be presented on the bottom right of the LCD display along with the inner and outer measurements that were used in the calculation. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-10...

  • Page 151: Trace/Trace Method Of Percent Area Reduction Calculation (% Area Red)

    The resulting % Area Reduction will be presented on the bottom right of the LCD display along with the inner and outer measurements that were used in the calculation. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 152: Trace/Ellipse Method Of Percent Area Reduction Calculation (% Area Red)

    The resulting % Area Reduction will be presented on the bottom right of the LCD display along with the inner and outer measurements that were used in the calculation. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-12...

  • Page 153: M-Mode Basic Measurements

    Use the trackball to position the second caliper to the desired location. Press SELECT to set the measurement. The Time, Distance and Slope values will be presented on the bottom right of the LCD display. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 154: Pw Doppler Basic Measurements

    Use the trackball to position the second caliper. An End Diastolic Velocity (EDV) value with associated Resistive Index (RI) and Systolic/Diastolic Ratio (SD ) will be presented on the LCD display. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-14...

  • Page 155: Doppler Manual Trace Measurement

    Press SELECT to end and set the Trace. Note: Use the keyboard BACKSPACE key to correct an incorrect move on a Trace measurement. The Trace values will be presented on the LCD display. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis 7-15...

  • Page 156: Doppler Manual Trace Measurement - Point By Point Method

    The second caliper appears on the screen. Use the trackball to position it. Press SELECT to set the D-Range. The Trace values will be presented on the screen. Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-16...

  • Page 157: Doppler Heart Rate Measurement

    Use the trackball to position the second caliper to the desired next beat. Press SELECT to set the measurement. The Heart Rate value will be presented on the screen. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 158: Application-Specific Measurement/Calculation

    Ensure correct fetus (A, B or C) is selected on the Measurements touch screen prior to performing obstetrical measurements. Fetal labels are not displayed with the measurement on the image field. Ultrasonix recommends that the user annotate the image as required to differentiate the measurements.
  • Page 159 Note: For additional details on performing a particular type of measurement (e.g., HC requires a Circumference – Trace or Ellipse), refer to 7.1, 7.2 and 7.3 under Basic Measurements. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...

  • Page 160: Reports/Clinical Analysis

    Note: In order to access an individual report page after an exam has ended, it must either be printed or stored (refer to 9.2.4 Print Keys for setup details on the console PRINT 1, PRINT 2 and PRINT 3/ARCHIVE buttons). Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-20...

  • Page 161: Obstetrics Report

    Caution: In the case of twins or triplets, ensure the correct fetus is selected prior to deleting the OB parameter measurement. Tap Back on the touch screen to return to OB. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis...
  • Page 162 Obstetrics Report. The buttons will vary by Report page (e.g., the Graphs selection will not be available on the actual Graphs page of this report.) Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-22...
  • Page 163 Each item on the OB Report Anatomy Checklist page has a small, editable Comment field. Use Select/Clear All to select/deselect all items in the Anatomy Checklist at the same time. SONIX Series User Manual 00.040.144, Revision E Chapter 7: Clinical Analysis 7-23...
  • Page 164 Multi-line, editable Comment field (available with all Reports). Enter data using the keyboard. Each graph is labeled in Percentile (as this one is) or Standard Deviation (e.g., ±2SD). Chapter 7: Clinical Analysis 00.040.144, Revision E SONIX Series User Manual 7-24...

  • Page 165: Chapter 8: Text, Annotations And Pictograms

    Use the trackball to relocate the Text cursor as required. Use the keyboard backspace arrow to remove the letter(s) to the left of the Text cursor. Press TEXT to exit Text/Annotation mode. SONIX Series User Manual 00.040.144, Revision E Chapter 8: Text, Annotations and Pictograms...

  • Page 166: Set Text Home Position

    Note: To modify the preset Annotations, refer to 9.1.2 Presets – Annotations. Repeat steps 2 and 3 as many times as required. Press TEXT to exit Text/Annotation mode. Chapter 8: Text, Annotations and Pictograms 00.040.144, Revision E SONIX Series User Manual...

  • Page 167: Deleting Text/Annotation

    – when the FREEZE button is pressed again (i.e., when the image is unfrozen) the Text arrows will be removed without having to press ARROW as described in step 6. SONIX Series User Manual 00.040.144, Revision E Chapter 8: Text, Annotations and Pictograms...

  • Page 168: Pictograms

    To re-access the Pictogram functions after performing other imaging functions, press PICTOGRAM again and repeat steps 2 to 6. To hide the Pictogram from view, tap the Hide button on the touch screen. Chapter 8: Text, Annotations and Pictograms 00.040.144, Revision E SONIX Series User Manual...

  • Page 169: Chapter 9: System Setup

    Admin Settings: optional password protection • Service Settings: always password protected. Only qualified Ultrasonix Medical Corporation service personnel can access this menu. The following tables provide a quick overview of the system's setup menus. Refer to the related sections later in this chapter for further details on any particular setup option.
  • Page 170 Network Caution: System networking options are intended for use inside your organization's firewall. Organizations that elect to configure/use the networking functionality provided by Ultrasonix are assuming all liabilities and risks associated with that decision. Enable and configure DICOM Storage, Print and Worklist.
  • Page 171 From the User Settings menu, select Admin… to access Admin Settings. From the Admin Settings menu, select Service… to access the Service Mode dialog. Note: To exit the entire menu system in one step, press the console MENU button. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 172: User Settings

    Default settings are locked (as indicated by the lock icon adjacent to the Preset name). Additional user-definable aspects of the default settings are available through the three (3) tabs on the Presets Setup page: Annotations, Pictograms and 3D/4D. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual...
  • Page 173 Press the console MENU button. Select Presets. Highlight the user-defined Preset to be deleted. Click the Delete button. Select Yes to confirm the deletion or No to cancel the operation. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 174: Show/Hide Imaging Presets

    C5-2/60 > Obstetrics > Fetal Echo. Fetal Echo not available under the Obstetrics Preset for the C5-2/60 transducer. Note: This show/hide function applies to both default and user-defined Presets. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual...
  • Page 175 To Show/Hide an Imaging Preset (on the Touch Screen and QSONIX Imaging Preset Dialog): Press the console MENU button. Select Presets. Select/deselect the relevant checkbox. Select OK to accept the changes or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 176: Presets - Annotations

    Page Selector New Page Delete Page Restore Defaults Note: The order in which Annotations appear here is matched on the touch screen during Text entry (8.1 Text and Annotations). Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual...

  • Page 177: Modify Annotations

    Alternatively, if multiple pages already exist, move through them using the onscreen page selection button, making changes as required. Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 178: Presets - Pictograms

    Figure 9-4: Presets Setup – Pictograms Pictograms Tab Pictogram Selectors Pictogram Order Selectors List of Pictograms attached to selected Preset List of Available Pictograms Selected Pictogram Restore Defaults Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-10...

  • Page 179: Modify The Pictograms Attached To Presets

    Use the order (up/down) selector buttons to move the item to another place in the list of selected Pictograms. Repeat Steps 5 and 6 as many times as required. Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-11...

  • Page 180: Presets - 3D/4D

    (e.g., User-Defined Preset). Note: These settings do not apply to Chapter 6: Advanced 3D/4D Imaging. Figure 9-5: Presets Setup – 3D/4D 3D/4D Tab Assigned 3D Preset Options Restore Defaults Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-12...
  • Page 181 LCD display. Use the trackball and SELECT button to view the Presets listed in the drop-down menu. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 182: Annotations

    To Access the Global Annotation Settings Dialog: Press the console MENU button. Select Annotations. Note: Refer to 9.1.2 Presets – Annotations for details on configuring Preset-specific Annotations. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-14...

  • Page 183: Measurements

    Caution: Some caliper sizes/colors, font sizes or dot colors may not appear clearly on the image screen, stored image or printed/recorded image. To ensure clear visualization of the caliper, label font and connection points, Ultrasonix recommends setting the caliper graphics to at least Regular or Medium.

  • Page 184: Display Options For Measurement/Calculation Values

    Number of beats used to measure the HR and FHR on an Heart Rate Beats M-Mode and Doppler Trace. Range: 1 – 7 beats. Type of unit used to display Volume calculation: ml or cc. Volume Units Warning: Ultrasonix does not endorse user-defined Measurements, Calculations Tables diagnostic purposes. user-defined Measurements, Calculations and Tables are used at the Operator's discretion and risk only.
  • Page 185 Select the desired measurement/calculation from the second drop-down menu (e.g., if Area was selected in step 3, select AR, CIR, SA, LA, or any combination thereof). Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 186: Managing Ob Settings

    Warning: Various factors may affect the accuracy of Obstetrical measurements. Ensure: • system Date and Time are configured correctly. • desired Obstetrical calculation author has been selected for each parameter. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-18...

  • Page 187: Managing Ob Tables

    9.1.6.3 Managing OB Tables Warning: Ultrasonix does not endorse user-defined Measurements, Calculations and Tables for diagnostic purposes. All user-defined Measurements, Calculations and Tables are used at the Operator's discretion and risk only. To Create New Obstetrical Calculation Authors and Look-up Tables: Press the console MENU button.
  • Page 188 Note: AC and HC are assumed to be Circumference measurements. Select Save to accept the changes and return to the OB Table Editor or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-20...
  • Page 189 Select the Save & Exit button to save any newly entered/edited data and exit the page, Save to save any newly entered/edited data but remain in the OB Table Editor or Exit to cancel any newly entered/edited data and exit the page. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 190: Settings

    Select/deselect the Provide 3D Freehand Options After Acquisition checkbox. Note: This is a global option and applies to all 3D/4D Presets. Select OK to accept the change and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-22...
  • Page 191 Note: User-defined Presets are marked with a key icon. Click the Delete button. Select Yes to accept the deletion and exit or No to exit without deleting the Preset. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 192: Display Settings

    Displays image screen with high resolution image field and thumbnail images below. Image w/ Thumbnails Note: Ultrasonix recommends using this setting. Displays a full screen image field with no thumbnail images. This setting provides a larger image field for viewing the LCD display from a distance (e.g., during surgical procedures) but has a reduced image...

  • Page 193: Dicom Server Selection

    Note: DICOM Storage and/or DICOM Print will only be available for selection if they have been previously configured (9.2.3.1 and/or 9.2.3.2). Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 194: Biopsy Guide Settings

    Sets the Biopsy Guide Orientation to the (vertical) center of the imaging screen. Central To Configure the Biopsy Guide Settings: Press the console MENU button. Select Biopsy Guide. Select the radio button for the desired Guide Orientation. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-26...

  • Page 195: Sonix Live Setup

    (refer to 9.2.7 Status Bar for details on the SONIX Live icon). Note: Because Streaming Video may cause a noticeable decrease in overall system performance, Ultrasonix recommends activating SONIX Live only when video streaming is required. Note: VLC Media Player is freeware available from VideoLAN. The SONIX system is delivered with the server-side software ready for use.
  • Page 196 Because Streaming Video cause noticeable decrease in overall system performance, Ultrasonix recommends activating SONIX Live only when video streaming is required. The radio button selects the SONIX Live Viewer (VLC) SONIX Live Viewer rather than Windows Media Player. Select from the drop-down menu (for multicasting) or type in the relevant Stream to IP Address of the client.

  • Page 197: Sonix Live And Vlc Media Player

    Live and VLC Media Player or 9.1.11.2 SONIX Live and Windows Media Player). Because Streaming Video may cause a noticeable decrease in overall system performance, Ultrasonix recommends activating SONIX Live only when video streaming is required. Press the console MENU button.
  • Page 198 Open (or run) the self-extracting VLC installation software. When prompted, select English as the Installer Language and click OK. Click Next to continue past the Welcome screen. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-30...
  • Page 199 On the Choose Components dialog, select Custom as the type of installation. Select the checkboxes for all available optional components and click Next. Note: Ensure the target PC has enough space to complete the installation. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...
  • Page 200 Click Install to accept the default Destination Folder and begin the install. Note: To change the Destination Folder location/name, check Browse and follow the instructions. When the installation is done, click Finish. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-32...
  • Page 201 Click the + (plus) signs to expand Video and Output modules. Check Advanced options. From the Video output module drop-down menu select OpenGL video output. Click the + (plus) signs to close Output modules and Video. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-33...
  • Page 202 Click the + (plus) signs to expand Input/Codecs and Other codecs. Select FFmpeg. Set the Post processing quality field to 6. Click Save. Click the Open button. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-34...
  • Page 203 Note: For unicasting, select UDP/RTP. For multicasting, select UDP/RTP Multicast and enter the multicast IP Address in the Address field. Ensure the Port is set to 1234. Click OK. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-35...
  • Page 204 The SONIX Live icon will only be visible if it has been enabled (refer to 9.2.7 Status Bar for more details). Select OK to accept the changes or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-36...

  • Page 205: Sonix Live And Windows Media Player

    The SONIX Live icon will only be visible if it has been enabled (refer to 9.2.7 Status Bar for more details). Select OK to accept the changes or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...
  • Page 206 IP Address is 127.0.0.1, type in http://127.0.0.1:8080. Click the OK button and the SONIX Live video stream will be displayed in the Windows Media Player. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-38...

  • Page 207: Admin Settings

    Password protection (see page 9-44 for details). Figure 9-14: Admin Settings Menu To Access Admin Settings: Press the console MENU button. Select Admin… to access the Admin Settings menu. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-39...

  • Page 208: System Settings

    System Settings System Settings are used to configure the Institution Name, Regional parameters, Imaging Modes, Shutdown Options, User Data settings, Auto-Freeze and Admin Password. Figure 9-15: System Settings Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-40...
  • Page 209 Turkish or Korean as the language for Keyboard Layout. Additionally, because Keyboard Layout selections are controlled by Windows rather than Ultrasonix, there are many more Keyboard Layouts to choose from than there are Interface Languages. Select country-specific parameters, including Date and Time Internal Settings…...
  • Page 210 Selecting Enable Fast Boot allows the system to power up faster by reducing the amount of initial system auto-testing. Enable Fast Boot Note: Ultrasonix recommends occasionally deselecting this (Hibernation mode) feature and powering the system off and on once in order to ensure maximum system performance.
  • Page 211 Imports user-configured System Settings from an external storage device (USB key, CD, DVD, etc). Settings must have been previously exported from a SONIX system. Note: Ultrasonix does not recommend importing user-defined Presets created with a previous software version as they may not be compatible for use with a more recent software update.
  • Page 212 From the User Manual Language drop-down menu, select the desired language. Note: If this option is inaccessible (grayed out), there are no PDF User Manuals available on the system. Select Close to accept the language selection and exit. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-44...
  • Page 213 Select OK to begin the export process or Cancel to exit without exporting. If OK is selected in the previous step, a completion dialog will be presented when the export process has finished (this will take approximately 15-45 seconds). SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...
  • Page 214 To Import User Data: Note: Ultrasonix does not recommend importing user-defined Presets created with a previous software version as they may not be compatible for use with a more recent software update. Connect the external USB storage device from which the data will be imported.

  • Page 215: Network

    Note: Refer to Appendix B: System Specifications for wireless availability on the various system configurations. The Online Remote Support button is used to connect with an online Ultrasonix technician. Ultrasonix Technical Support will help configure this option should it ever be required.
  • Page 216 Note: Ultrasonix Online Support addresses are added automatically. Use to Delete extra, non-Ultrasonix Online Support IP Delete addresses. Note: Ultrasonix recommends that Network connections be configured using the settings provided by your IT Department. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual...

  • Page 217: Ethernet (Lan) Network Configuration

    IP address, Subnet mask, and Default gateway. Select OK and press the console MENU button to exit the menu system. Note: It may be necessary to restart in order for the changes to take affect. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 218: Dialup Network Configuration

    Select OK and press the console MENU button to exit the menu system. Note: While the system is dialing out, the current dialing status to the ISP will be displayed. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-50...

  • Page 219: Wireless Settings

    When a wireless network is in place, it will be necessary to obtain your institution's Network Key in order to login. Note: Ask your IT department for the Network Key. Used to Connect/Disconnect from the wireless network. Connect/Disconnect SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-51...

  • Page 220: Online (Chat) Support

    Ensure the Online Support Enabled box is checked. Enter the Contact IP address (above Add and Delete). Click Add. Select OK to accept the settings and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-52...

  • Page 221: Online Remote Support

    9.2.2.5 Online Remote Support Online Remote Support allows Ultrasonix Technical Support to view and control the SONIX for diagnostic purposes. Note: A network connection is required for Online Remote Support. To Configure Online Remote Support: Press the console MENU button.

  • Page 222: Dicom Configuration

    Select/deselect the appropriate Turn on… checkbox beside the desired feature (Storage, Print or Worklist) in order to activate/deactivate access to a DICOM feature. Select/deselect the appropriate Server radio button to activate/deactivate access to that Server's Settings button. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-54...

  • Page 223: Dicom Storage Configuration

    Configuration, Storage Settings, Brightness/Contrast and Storage Commitment. Configure the four (4) dialogs as required. Repeat these instructions for as many of the three (3) available Servers as necessary. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-55...
  • Page 224 Select to send verification request to DICOM Storage device (ping to verify Connection Test connection). Use to insert text symbol(s) not available on the console keyboard (e.g., Insert (Symbol) punctuation marks, symbols and letters from other languages). Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-56...
  • Page 225 (e.g., Failed to connect to DICOM). Use to insert text symbol(s) not available on the console keyboard Insert (Symbol) (e.g., punctuation marks, symbols and letters from other languages). SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-57...
  • Page 226 Note: To adjust the Brightness/Contrast settings, position the trackball arrow Reset over the Brightness or Contrast slider. Press and hold the SELECT button while moving the trackball left or right to the desired position. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-58...
  • Page 227 PDU size in bytes. Packet Data Unit (PDU) Size Use to insert text symbol(s) not available on the console keyboard Insert (Symbol) (e.g., punctuation marks, symbols and letters from other languages). SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-59...

  • Page 228: Dicom Print Configuration

    An onscreen dialog with four (4) tabs will be presented: AE Configuration, Print Settings, Advanced Print Settings and Brightness/Contrast. Configure the four (4) dialogs as required. Repeat these instructions for as many of the three (3) available Servers as necessary. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-60...
  • Page 229 Select to send verification request to DICOM Print device (ping to verify Connection Test connection). Use to insert text symbol(s) not available on the console keyboard (e.g., Insert (Symbol) punctuation marks, symbols and letters from other languages). SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-61...
  • Page 230 Select the location to which the print job will be sent: Processor or Film Destination Magazine. Use to insert text symbol(s) not available on the console keyboard Insert (Symbol) (e.g., punctuation marks, symbols and letters from other languages). Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-62...
  • Page 231 Enter the printer-specific Image Size in mm. Image Size Use to insert text symbol(s) not available on the console keyboard Insert (Symbol) (e.g., punctuation marks, symbols and letters from other languages). SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-63...
  • Page 232 Note: To adjust the Brightness/Contrast settings, position the trackball arrow Reset over the Brightness or Contrast slider. Press and hold the SELECT button while moving the trackball left or right to the desired position. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-64...

  • Page 233: Dicom Worklist Configuration

    Select Admin… > DICOM. Check Turn on DICOM Print. Click the associated Settings button. An onscreen dialog with one (1) tab will be presented: AE Configuration. Configure the dialog as required. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-65...
  • Page 234 Select to send verification request to DICOM Worklist device (ping to Connection Test verify connection). Use to insert text symbol(s) not available on the console keyboard (e.g., Insert (Symbol) punctuation marks, symbols and letters from other languages). Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-66...

  • Page 235: Print Keys

    Sends a Trigger signal to attached video printers (e.g., Thermal Printer). Trigger (Photo Printer/VCR) Note: To select Store Locally (above), all other options must be deselected. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-67...
  • Page 236 Select the desired tab: Print 1, Print 2 or Print 3. Configure the individual Print Keys as required. Select OK to accept the changes and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-68...

  • Page 237: Peripherals

    To Access the Peripherals Dialog: Press the console MENU button. Select Admin… > Peripherals. Select the relevant Peripherals dialog tab: Paper Printer, LCD Display, VCR/Photo, Footswitch or Brightness/Contrast. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-69...

  • Page 238: Paper Printer

    Select the number of print Rows. Rows Select to allow Image Sheet Printing. Enable Enter text to be printed in each Header. Header Footer Note: This field is always disabled. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-70...
  • Page 239 To send partial print pages (e.g., 3 images remaining on a 4 image/sheet format) at the end of an exam, press the console ID button and select End Exam. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 240: Lcd Display

    Note: Click the Restore Factory button to reconfigure the LCD display to factory settings. Repeat steps 4 and 5 as many times as required. Select OK to accept the changes and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-72...

  • Page 241: Vcr/Photo

    Select Admin… > Peripherals. Select the VCR/Photo tab. Select/deselect Enable Video Out as required. Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-73...

  • Page 242: Footswitch

    Select the Footswitch tab. Check Enabled. Select the desired action from the drop-down menu: Print or Freeze. Select OK to accept the changes and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-74...

  • Page 243: Brightness/Contrast

    Press and hold the SELECT button while moving the trackball to the desired position. Note: Click the Reset button to restore Brightness/Contrast settings to factory defaults. Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup...

  • Page 244: Patient Settings

    Information (4.1.1). Accession # Insurance # When selected, BBT will be available for under Application Information (4.1.2). Note: BBT is only applicable when the Application is set to OB. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-76...
  • Page 245 Select/deselect this field to display/hide the Patient Information Hide Patient Information during an exam. Select this option to capitalize all letters in a patient's name or Capitalize Patient Names identification number. and Patient ID SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-77...
  • Page 246 Press the console MENU button. Select Admin… > Patient. Configure the Patient Settings as required. Select OK to accept the changes and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-78...

  • Page 247: Status Bar

    This icon will be visible only when the DICOM Worklist server is being accessed. Note: A Network connection must exist in order to have Success Failure access to a DICOM network. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-79...
  • Page 248 Note: If Battery power is available, the icon displayed will be the appropriate Battery Level icon (see below). Wall Plug Battery Ultrasonix recommends selecting this option so users will always be aware of the power source in use. Displays the approximate amount of Battery power remaining. Battery level...
  • Page 249 Press the console MENU button. Select Admin… > Status Bar. Select/deselect Displayed Indicators as required. Select OK to accept the changes and exit or Cancel to exit without saving. SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-81...

  • Page 250: Capture Settings

    Press the console MENU button. Select Admin… > Capture. Configure Capture Settings as required. Select OK to accept the changes and exit or Cancel to exit without saving. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-82...

  • Page 251: Software Update

    Click to view the Release Notes associated with the Available Updates selection. Release Notes Note: An Internet connection is required to access Release Notes. Lets the user know when the update is complete or Ready. Update Progress SONIX Series User Manual 00.040.144, Revision E Chapter 9: System Setup 9-83...
  • Page 252 Select Update to begin the update process or Cancel to exit without updating. Note: The Update Progress bar displays the download progress. Upon completion, the Software Update will be auto-installed and the system will restart automatically. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual 9-84...

  • Page 253: Licensing

    Add License Button Show Key Local Drive… Button Separations Note: Contact your Ultrasonix representative for details on obtaining a new license key and enabling additional features. To Access the Licensing Dialog: Press the console MENU button. Select Admin… > Licensing.

  • Page 254: Service Menu

    Check to ensure the new license has been added then click Close to exit the Licensing dialog. SERVICE MENU Access to Service is password protected and restricted to certified, Ultrasonix Service representatives. Chapter 9: System Setup 00.040.144, Revision E SONIX Series User Manual...

  • Page 255: Chapter 10: Image Storage, Review And Transfer

    Hard drive capacity for patient data storage is 160 gigabytes. Depending on the number/type of images involved, the system can store more than 50,000 exams. Note: Ultrasonix recommends regular patient/image file back-up and purging of older patient files stored on the system.
  • Page 256 To select all Patients at the same time, tap the touch screen Select All button. Click Review and the Image Review page will be presented with the exam files for the selected Patient(s). Chapter 10: Image Storage, Review and Transfer 00.040.144, Revision E SONIX Series User Manual 10-2...
  • Page 257 White arrow head indicates more images. for image transfer or deletion. The trackball arrow cursor triggers scrolling of thumbnails both to the right and left. SONIX Series User Manual 00.040.144, Revision E Chapter 10: Image Storage, Review and Transfer 10-3...
  • Page 258 The image thumbnails on the bottom of the screen represent all the available images for the exam under review. To scroll through the thumbnails, use the trackball to move the cursor over to the right or left side of the thumbnails. Chapter 10: Image Storage, Review and Transfer 00.040.144, Revision E SONIX Series User Manual 10-4...
  • Page 259 Select to Exit the clip review and return to 2D imaging. Exit Select to view the clip. Play Select to Pause viewing of the stored clip. Pause SONIX Series User Manual 00.040.144, Revision E Chapter 10: Image Storage, Review and Transfer 10-5...
  • Page 260 Tap the desired selection on the touch screen menu (e.g., Speed). Use the dial below the selected touch screen button to make the adjustment to the CINE review. Chapter 10: Image Storage, Review and Transfer 00.040.144, Revision E SONIX Series User Manual 10-6...

  • Page 261: Deleting Image(S)/Exam(S)

    Note: Select Clear to reset the screen and deselect the patient(s), exam(s) and image(s). Clear does not delete the images, it simply resets the screen by unchecking the selections. SONIX Series User Manual 00.040.144, Revision E Chapter 10: Image Storage, Review and Transfer...

  • Page 262: Image Transfer

    To select all exams for a patient, check the checkbox for the desired patient. To select only desired images, open each exam and check the checkbox for the desired images. Figure 10-4: Select Storage Destination Dialog Chapter 10: Image Storage, Review and Transfer 00.040.144, Revision E SONIX Series User Manual 10-8...
  • Page 263 DICOM image in a lossless JPEG format. DCM JPEG lossless Note: These images will be readable by any PACS system that reads DICOM 3.0 formatted files. SONIX Series User Manual 00.040.144, Revision E Chapter 10: Image Storage, Review and Transfer 10-9...
  • Page 264 Clear does not delete the images, it simply resets the screen by unchecking the selections. Select the desired Storage Destination. Note: All connected Ultrasonix-approved digital storage peripherals will appear in the list of Storage Destinations. If PracticeHwy or a DICOM Storage Server is connected, they will also be available for selection.
  • Page 265 Note: If the Queue jams during transfer/print, press SHIFT+ID. This will display the relevant Queue, enabling the user to delete the job and release the function. SONIX Series User Manual 00.040.144, Revision E Chapter 10: Image Storage, Review and Transfer...
  • Page 266 Chapter 10: Image Storage, Review and Transfer 00.040.144, Revision E SONIX Series User Manual 10-12...

  • Page 267: Chapter 11: Connectivity And Peripherals

    The system includes a wide range of connectivity features that allow the user to simultaneously connect a variety of peripherals. Refer to 9.2.5 and the SONIX Series Service Manual for further details on peripheral connectivity. Warning: Do not touch the patient and the transducer ports simultaneously.
  • Page 268 Figure 11-2: System Case Connectivity Panel (SX1.1) Figure 11-3: System Case Connectivity Panel (SX1.1 mod) Chapter 11: Connectivity and Peripherals 00.040.144, Revision E SONIX Series User Manual 11-2...
  • Page 269 Figure 11-4: System Case Connectivity Panel (OP/SP SX1.2/1.3-FI) Figure 11-5: System Case Connectivity Panel (OP/SP SX1.2/1.3-F) SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals 11-3...
  • Page 270 Figure 11-6: System Case Connectivity Panel (OP/SP SX1.4) Figure 11-7: System Case Connectivity Panel (CEP SX3.0) Chapter 11: Connectivity and Peripherals 00.040.144, Revision E SONIX Series User Manual 11-4...
  • Page 271 Figure 11-8: System Case Connectivity Panel (CEP SXmod 3.1) Figure 11-9: System Case Connectivity Panel (CEP SX3.2/3.3-FI) SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals 11-5...
  • Page 272 Figure 11-10: System Case Connectivity Panel (CEP SX3.2/3.3-F) Figure 11-11: System Case Connectivity Panel (CEP SX3.4) Chapter 11: Connectivity and Peripherals 00.040.144, Revision E SONIX Series User Manual 11-6...
  • Page 273 Ultrasonix-approved USB peripherals. Use to connect the barcode reader and wireless adapter. Used by the LCD display and wireless adapter. CEP: Line-in (blue): may be used to connect an Ultrasonix-approved audio input device. Sound connections System Speaker connection (green).
  • Page 274 Concelman (BNC) Refer to 9.2.5 Peripherals to configure the trigger action of the switching device. Port may be connected directly to an Ultrasonix-approved triggered device, such as a video printer. 19 Print BNC Refer to 9.2.4 Print Keys to configure the PRINT keys.

  • Page 275: Back Connectivity Panel

    Figure 11-13: Console Front The system provides (two) 2 USB ports and a DVD/CD writer at the front of the operator console. These USB ports can be used to connect Ultrasonix-approved USB devices (such as a USB thumb drive) for image file transfer.

  • Page 276: Advanced 3D/4D Software Dongle

    Figure 11-15: Advanced 3D/4D Software Dongle (Connected to System Case Connectivity Panel) Connected Dongle (with power on) IMPORTANT: The software dongle is supplied by Ultrasonix and must be attached to connection point 7 on the System Case Connectivity Panel at all times in order to access Advanced 3D/4D Imaging.

  • Page 277: Ultrasonix-Approved Devices

    SONY VCR and SONY DVD Recorder connected to RGB-Sync • Canon i80 InkJet Printer connected to Parallel Port. Note: Refer to the most recent Ultrasonix price list to determine the exact makes/models of Ultrasonix- approved devices. SONIX Series User Manual 00.040.144, Revision E...

  • Page 278: Ups (Cep)

    During installation, the technician will ensure that the system – and therefore the UPS – is left plugged in, allowing it to completely charge the battery. This will take approximately 3.5 hours. As a data safety measure, Ultrasonix has configured the UPS alert system to ensure an optimal warning time for UPS battery recharging.
  • Page 279 To fully charge the battery after an Alert Level 1 automated shutdown, leave the system plugged in continuously for 3.5 hours. If the charging cycle must be interrupted, Ultrasonix recommends leaving the system plugged in for a minimum of one (1) hour before unplugging it.

  • Page 280: Ups Battery Sleep Mode (Cep)

    If the CEP fails to wake, the EPO switch may have been pressed and the UPS breakers will need to be reset. Contact your internal service provider or Ultrasonix Technical Support. If the CEP boots correctly, leave the system plugged in and recharging – uninterrupted – for at least 60 minutes to attain approximately 60 minutes of battery life.

  • Page 281: Ups Emergency Power Off Switch (Cep)

    Once the EPO switch has been pressed, the CEP will be completely disabled until your internal service provider or a certified Ultrasonix Service Technician can reset the system. Service calls that result from misuse of the EPO switch are not covered under the system Warranty and may not be covered by the Service Contract.

  • Page 282: Connecting The Barcode Reader

    UNDER NO CIRCUMSTANCES should users or technicians attempt to open or service the laser scanner. Attempting to open the barcode reader may cause exposure to hazardous laser light. Should the barcode reader require maintenance or replacement, contact Ultrasonix Technical Support. Caution: Do not apply ultrasound gel to the barcode reader.

  • Page 283: Cep

    System Case Connectivity Panel (refer to the figures in 11.1 System Case Connectivity Panel for location details on this connection). To keep it handy, store the barcode reader in one of the smaller transducer holders. SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals...

  • Page 284: Power Cord

    It may also damage the cable reel, leading to further hazards when operating the system. Should the cable reel require maintenance or replacement, contact Ultrasonix Technical Support. DO NOT use excessive force when extending or retracting the cord. This can cause the cord to separate from the reel and potentially expose anyone in the vicinity to lethal voltages.

  • Page 285: Power Cord: International (Cep)

    When the system is unplugged, the power cord on the OP, SP, RP and 01 models can be wrapped around the power cable hooks to keep it tidy yet easily accessible. Figure 11-21: Power Cord: OP, SP, RP and 01 Power Cable Hooks SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals 11-19...

  • Page 286: Wireless

    Caution: System networking options are intended for use inside your organization's firewall. Organizations that elect to configure/use the networking functionality provided by Ultrasonix are assuming all liabilities and risks associated with that decision. Caution: For details on FCC regulations as they apply to the wireless adapter, refer to the manufacturer's User Guide included with the system.

  • Page 287: Cep

    USB port on the System Case Connectivity Panel. Figure 11-24: CEP Wireless Connection USB cable attached to the System Case Connectivity Panel. SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals...

  • Page 288: Console Cover

    Gently lift the front section of the cover and remove the paper backing from the Velcro. Press the Velcro into place, taking care to ensure that exposed glue is positioned correctly. Chapter 11: Connectivity and Peripherals 00.040.144, Revision E SONIX Series User Manual 11-22...
  • Page 289 Make sure the cover sits behind the TGC SLIDE PODS. Repeat steps 2 and 3 for the left and, then the right hand side of the console until the console cover is snugly attached. SONIX Series User Manual 00.040.144, Revision E Chapter 11: Connectivity and Peripherals...
  • Page 290 Gently smooth all the Velcro fasteners into place, starting across the bottom, then moving to the top and the sides. Make sure the cover sits behind the TGC SLIDE PODS. Chapter 11: Connectivity and Peripherals 00.040.144, Revision E SONIX Series User Manual 11-24...

  • Page 291: Appendix A: Safety

    As Low As Reasonably Achievable (ALARA). Without compromising diagnostic quality, patient ultrasound exposure should be kept to a minimum while using the lowest output power possible. SONIX Series User Manual 00.040.144, Revision E Appendix A: Safety...

  • Page 292: Basic Precautions

    ALWAYS power the system from a grounded outlet. Ultrasonix does not recommend the use of transducer covers containing natural rubber latex and talc as these ingredients are known to cause an allergic reaction in some individuals. Refer to "21 CFR 801.437"...

  • Page 293: Ups Precautions (Cep

    Should the UPS require maintenance or replacement, only qualified Ultrasonix Service Technicians may perform service as detailed in the Service Manual. For UPS and battery service issues, contact Ultrasonix Technical Support.

  • Page 294: Electrical Safety Requirements

    Ultrasonix Medical Corp. Failure to comply with these conditions may result in damage to the system which is not covered by the Ultrasonix warranty. Caution: For users running the 120V system, always ensure the utility supply voltage is 120 VAC nominal.

  • Page 295: Additional Hardware

    Portable and mobile RF communications equipment can affect the SONIX Ultrasound System. Transducer cables have to be raised above the ground during scanning. Warning: The use of accessories, transducers and cables other than those specified by Ultrasonix may result in increased emissions or decreased immunity of the SONIX. A.6.2 Additional Hardware...

  • Page 296: Environmental Conditions

    Warning: Operate in an indoor environment only, free from moisture, flammable liquids, gases, corrosive substances, strong electrical or magnetic fields and equipment that generates high frequency waves. Ultrasonix cannot guarantee the proper performance of the SONIX CEP if used in the above-listed conditions. Appendix A: Safety 00.040.144, Revision E...

  • Page 297: Additional Hardware

    -4° to 158° F (-20° to 70° C) Humidity 80% maximum, non-condensing Note: For more details on the wireless adapter, refer to the manufacturer's User Guide included with the system. SONIX Series User Manual 00.040.144, Revision E Appendix A: Safety...

  • Page 298: Limiting Transducer Surface Heating

    LIMITING TRANSDUCER SURFACE HEATING Ultrasonix has ensured that the transducer surface temperature in still air does not exceed 50°C and applied on tissue does not exceed 43°C. Surface heating may be created by transmitting energy on the same area of a transducer at a high rate.

  • Page 299: Appendix B: System Specifications

    APPENDIX B: SYSTEM SPECIFICATIONS Note: Optional features may not be available on all system configurations. Ultrasonix Medical Corporation reserves the right to alter system specifications at any time. ♦ – Optional – Standard – Not Applicable Table B-1: SONIX Series System Specifications...
  • Page 300 Video input – S-Video Serial connector Parallel and USB standard inkjet or laser printer output Integrated modem and Network connection ♦/ ♦ ♦ Wireless networking ♦/ ♦ ♦ Streaming video (SONIX Live) Appendix B: System Specifications 00.040.144, Revision E SONIX Series User Manual...
  • Page 301 Display method (scroll or moving bar, Spectral Doppler, B/M) Sweep Speed (M-Mode, PW) Automatic optimization key (Spectral Doppler) Easy-to-use Interface LCD touch screen command centre User-programmable PRINT keys Text, Annotations, Pictograms RESETS Default presets User-defined presets SONIX Series User Manual 00.040.144, Revision E Appendix B: System Specifications...
  • Page 302 ), the first refers to the OP platform and the second to the CEP platform. 2 Ultrasonix Medical Corporation is not responsible for misdiagnosis from customized measurements. 3 Not available in all markets. Consult your dealer or Ultrasonix Technical Support to determine availability in your area. 4 Where available. Requires Internet connection and ISP.

  • Page 303: Appendix C: Transducer Specifications

    Small parts, Superficial, Msk, Vascular, Superficial Abd MEASUREMENT ACCURACY Table C-2: Transducers Used for Advanced 3D/4D Measurement Accuracy Tests Transducer Name Type Applications 4DC7-3/40 3D Abdominal Obstetrics, Abdomen, Gyn 4DEC9-5/10 3D Endocavity Transvaginal, Transrectal SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications...
  • Page 304 Max. Value Among Probes minimum values were used) was chosen for presentation. Difference between the Trial 1 and Trial 2 errors. Indicates the possible Estimated Uncertainty uncertainty when taking measurements. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual...

  • Page 305: Transducer Specifications

    Phased Array ± 2.97% ± 2.50% 1.86 mm 1225.97 mm Multipurpose Phantom*** Max. Value ± 2.97% ± 2.50% 1.76 mm 1326.17 mm Multipurpose Phantom*** ± 0.47% {1%} Among Probes SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications...
  • Page 306 M-MODE TEST Linear ± 1.65% ± 2.13% 8.58 bpm 15000.00 bpm Ultrasonix Test Equipment Convex ± 1.08% ± 4.81% 8.58 bpm 15000.00 bpm Ultrasonix Test Equipment Phased Array ± 1.88% ± 3.40% 8.58 bpm 15000.00 bpm Ultrasonix Test Equipment Max. Value ±...

  • Page 307: Acoustic Output Reporting Tables

    This formulation for TIS is less than that for an alternate formulation in this mode. No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications...
  • Page 308 @PII [MPa] 0.87 Other Information @PII [cm] Focal Length [cm] 5.03 5.03 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 1.91 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual...
  • Page 309 @PII [MPa] 0.44 Other Information @PII [cm] Focal Length [cm] 4.90 4.90 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 32.29 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications...
  • Page 310 [cm] Information X [cm] 4.71 4.71 Focal Length Y [cm] 4.71 4.71 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 3.09 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual...
  • Page 311 [cm] Information X [cm] 4.71 4.71 Focal Length Y [cm] 4.71 4.71 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 48.81 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications...
  • Page 312 Information X [cm] 5.50 5.50 Focal Length Y [cm] 5.50 5.50 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 15.72 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-10...
  • Page 313 Information X [cm] 8.00 8.00 Focal Length Y [cm] 8.00 8.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 600.41 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-11...
  • Page 314 3.00 [W/cm 0.16 PA .3 Control 1 Depth [mm] Operating Control 2 Focus [mm] Control [mm] Control 3 Gate Conditions Penetration Control 4 Preset ISPTA.3 [mW/cm2] = 158.74 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-12...
  • Page 315 3.00 [W/cm 0.59 PA .3 Control 1 Depth [mm] Operating Control 2 Focus [mm] Control [mm] Control 3 Gate Conditions Penetration Control 4 Preset ISPTA.3 [mW/cm2] = 592.88 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-13...
  • Page 316 3.00 0.65 [W/cm PA .3 Control 1 Depth [mm] Operating Control 2 Focus [mm] Control [mm] Control 3 Gate Conditions Control 4 Preset Penetration ISPTA.3 [mW/cm2] = 648.73 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-14...
  • Page 317 [MPa] 1.23 Other Information @PII [cm] Focal Length [cm] 5.39 5.39 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 3.49 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-15...
  • Page 318 [MPa] 1.32 Other Information @PII [cm] Focal Length [cm] 4.90 4.90 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 80.79 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-16...
  • Page 319 Information X [cm] 4.70 4.70 Focal Length Y [cm] 4.70 4.70 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 27.01 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-17...
  • Page 320 Information X [cm] 8.00 8.00 Focal Length Y [cm] 8.00 8.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 658.66 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-18...
  • Page 321 Information X [cm] 4.75 4.75 Focal Length Y [cm] 4.75 4.75 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 7.13 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-19...
  • Page 322 Information X [cm] 8.00 8.00 Focal Length Y [cm] 8.00 8.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 678.71 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-20...
  • Page 323 0.0602 Operating [mm] ISTPA (B+Color) 265.887 Control 2 Focus Control ‫ـ‬ [mm] Control 3 Gate ITA [mW/cm Conditions GEN–General Control 4 Preset ITA.3 [mW/cm ISPTA.3 [mW/cm2] = 402.986 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-21...
  • Page 324 PII.3 [mJ/cm 0.0602 Operating [mm] ISTPA (B+PW) 184.965 Control 2 Focus Control [mm] Control 3 Gate ITA [mW/cm Conditions GEN–General Control 4 Preset ITA.3 [mW/cm ISPTA.3 [mW/cm2] = 403.407 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-22...
  • Page 325 PII.3 [mJ/cm 0.0602 Operating ISTPA (B+PW) Control 2 Focus [mm] 184.965 Control Control 3 Gate [mm] ITA [mW/cm Conditions Control 4 Preset GEN–General ITA.3 [mW/cm ISPTA.3 [mW/cm2] = 508.372 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-23...
  • Page 326 [MPa] 1.92 Other Information @PII [cm] Focal Length [cm] 5.36 5.36 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 6.17 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-24...
  • Page 327 Information X [cm] 4.00 4.00 Focal Length Y [cm] 4.00 4.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 378.27 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-25...
  • Page 328 [MPa] 1.49 Other Information @PII [cm] 5.62 5.61 Focal Length [cm] [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 1.93 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-26...
  • Page 329 Information X [cm] 4.00 4.00 Focal Length Y [cm] 4.00 4.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 386.67 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-27...
  • Page 330 2.00 Other Information @PII [cm] Focal Length X [cm] 5.40 5.40 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 9.48 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-28...
  • Page 331 Information X [cm] 5.00 5.00 Focal Length Y [cm] 5.00 5.00 [W/cm PA.3 Control 1 Operating Control 2 Control Control 3 Conditions Control n ISPTA.3 [mW/cm2] = 667.64 SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-29...

  • Page 332: Ultrasound Indications For Use Tables

    *2. Freehand 3D imaging, Live 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. *3. Imaging for guidance of nerve block injections. *4. Imaging for guidance of central or peripheral lines. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-30...
  • Page 333 N = New indication; P = Previously cleared Additional Comments: *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD). SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-31...
  • Page 334 N = New indication; P = Previously cleared Additional Comments: Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Live 3D imaging, Directional Power Doppler (DPD). Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-32...
  • Page 335 N = New indication; P = Previously cleared Additional Comments: Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Live 3D imaging, Directional Power Doppler (DPD). SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-33...
  • Page 336 Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Live 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-34...
  • Page 337 N = New indication; P = Previously cleared Additional Comments: *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-35...
  • Page 338 Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-36...
  • Page 339 Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-37...
  • Page 340 *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. *3. Imaging for guidance of nerve block injections. *4. Imaging for guidance of central or peripheral lines. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-38...
  • Page 341 Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-39...
  • Page 342 *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. *3. Imaging for guidance of nerve block injections. *4. Imaging for guidance of central or peripheral lines. Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-40...
  • Page 343 Small Organ: Breast, Thyroid, Testicle *1. B/M, B/PWD, B/CWD, B/CFM/PWD, B/AD/PWD, B/DPD/PWD, B/CFM/CWD, B/AD/CWD, B/DPD/CWD. *2. Freehand 3D imaging, Directional Power Doppler (DPD), Imaging for guidance of biopsy. SONIX Series User Manual 00.040.144, Revision E Appendix C: Transducer Specifications C-41...
  • Page 344 Appendix C: Transducer Specifications 00.040.144, Revision E SONIX Series User Manual C-42...

  • Page 345: Appendix D: Maintenance And Cleaning

    TRANSDUCERS D.1.1 Guidelines Ultrasonix recommends inspecting the SONIX transducers prior to each use: • Ensure the transducers are always clean before they are used. There must be no ultrasound gel (from previous imaging), any debris, films or unusual odors present.

  • Page 346: Cleaning/Disinfecting Recommendations And Warnings For All Non-Invasive Transducers

    DO NOT use sterilization or disinfection methods that have not been recommended by Ultrasonix. Severe damage will result. Contact Ultrasonix if you have any doubt about sterilization or disinfection methods. Warning: Any transducer suspected of being contaminated with Creutzfeld Jacob disease material cannot be cleaned or sterilized.

  • Page 347: Cleaning (Non-Invasive Transducers

    • Cidex plus • Sani-Cloth ® • Wavicide • T-spray • Omnicide D.1.3.3 Sterilization (Non-Invasive Transducers) Sterilization of transducers is not possible. Follow the instructions for disinfection (above) instead. SONIX Series User Manual 00.040.144, Revision E Appendix B: System Specifications...

  • Page 348: Maintenance (Non-Invasive Transducers

    Ultrasonix. DO NOT use sterilization or disinfection methods that have not been recommended by Ultrasonix. Severe damage will result. Contact Ultrasonix if you have any doubt about sterilization or disinfection methods. Use of non-recommended cleaning agents may cause damage to the housing and will void transducer warranties.

  • Page 349: Storing And Packaging (Non-Invasive Transducers

    DO NOT use sterilization or disinfections methods that have not been recommended by Ultrasonix. Severe damage will result. Contact Ultrasonix if you have any doubt about sterilization or disinfection methods. Warning: Any transducer suspected of being contaminated with Creutzfeld Jacob disease material cannot be cleaned or sterilized.

  • Page 350: Cleaning (Invasive Transducers

    Table D-4: Recommended Disinfectants for Disinfecting Invasive Transducers High level disinfectants • Cidex plus ® • Wavicide • Omnicide D.1.4.3 Sterilization (Invasive Transducers) Sterilization of transducers is not possible. Follow the instructions for disinfection (above) instead. Appendix B: System Specifications 00.040.144, Revision E SONIX Series User Manual...

  • Page 351: Maintenance (Invasive Transducers

    Ultrasonix. DO NOT use sterilization or disinfection methods that have not been recommended by Ultrasonix. Severe damage will result. Contact Ultrasonix if you have any doubt about sterilization or disinfection methods. Use of non-recommended cleaning agents may cause damage to the housing and will void transducer warranties.

  • Page 352: Storing And Packaging (Invasive Transducers

    (D.1.3 and D.1.4) • the transducer is properly packaged for shipment (D.1.3.6 and D.1.4.6) • all shipping waybills/paperwork is completed as per the relevant regulations and laws. Appendix B: System Specifications 00.040.144, Revision E SONIX Series User Manual...

  • Page 353: System Components

    SYSTEM COMPONENTS Ultrasonix recommends the following cleaning instructions for all external surfaces, including the cart, cables and connectors. Cautions: Power off and unplug the system before cleaning. Do not spill or spray water on the controls, transducer connection receptacle, or transducer ports.

  • Page 354: Touch Screen

    Apply a small amount of one of the following recommended cleaning solutions to a soft, non- abrasive cloth and wipe the console cover: • Water • Mild detergent (PH level at or near 7) and water solution. Appendix B: System Specifications 00.040.144, Revision E SONIX Series User Manual D-10...

  • Page 355: Barcode Reader

    Apply a small amount of one of the following recommended cleaning solutions to a soft, non- abrasive cloth and wipe the power cord: • Water • Mild detergent (PH level at or near 7) and water solution. SONIX Series User Manual 00.040.144, Revision E Appendix B: System Specifications D-11...

  • Page 356: Wireless Adapter

    • Water • Mild detergent (PH level at or near 7) and water solution. Reinstall the transducer basket when cleaning is complete. Appendix B: System Specifications 00.040.144, Revision E SONIX Series User Manual D-12...

  • Page 357: Appendix E: Obstetrical Tables

    Nyberg Hadlock Rempen Hansmann BCWomen's Osaka Hadlock Tokyo Hansmann Hill Jeanty CEREB Hansmann BCWomen's Jeanty Hadlock Hansmann Hansmann Osaka Tokyo (No age table – for EFW only) Rempen Jeanty SONIX Series User Manual 00.040.144, Revision E Appendix E: Obstetrical Tables...
  • Page 358 Parameter Authors Doubilet Hadlock Osaka Warning: Ultrasonix does not endorse user-defined Measurements, Calculations and Tables for diagnostic purposes. All user-defined Measurements, Calculations and Tables are used at the operator's discretion and risk only. Appendix E: Obstetrical Tables 00.040.144, Revision E...

  • Page 359: Appendix F: References

    Campbell, S., Thomas Alison. "Ultrasound Measurements of the Fetal Head to Abdomen Circumference Ratio in the Assessment of Growth Retardation," British Journal of Obstetrics and Gynaecology, 84: (March 1977), 165-174. SONIX Series User Manual 00.040.144, Revision E Appendix F: References...

  • Page 360: Gestational Age Tables

    Tokyo, Shinozuka, N. FJSUM, et al. "Standard Values of Ultrasonographic Fetal Biometry." Japanese Journal of Medical Ultrasonics, 23:12 (1996), 886 FTA (Fetal Trunk Area) Osaka University. Ultrasound in Obstetrics and Gynecology. (July 20, 1990), 99-100 Appendix F: References 00.040.144, Revision E SONIX Series User Manual...
  • Page 361 Hansmann, M., et al. Ultrasound Diagnosis in Obstetrics and Gynecology. New York: Springer-Verlag, (1986), 431. UL (Ulnar Length) Jeanty P, et al. "Estimation of Gestational Age from Measurements of Fetal Long Bones." Journal of Ultrasound Medicine (1984) 3:75-79 SONIX Series User Manual 00.040.144, Revision E Appendix F: References...

  • Page 362: Growth Analysis Tables

    Assessment of Growth Retardation," British Journal Obstetrics and Gynaecology, 84: (March 1977), 165- 174. HL (Humeral Length) Jeanty P., E. et al. "Ultrasonic Evaluation of Fetal Limb Growth." Radiology (1982) 143: 751-754 Appendix F: References 00.040.144, Revision E SONIX Series User Manual...

  • Page 363: General And Cardiac References

    Kurtz, A.B., W.D. Middleton. Ultrasound-the Requisites. Mosby Year Book., (1996), 467. VTI (Velocity Time Integral) Reynolds, Terry. The Echocardiographer's Pocket Reference. 2nd ed., School of Cardiac Ultrasound, Arizona Heart Institute, (2000), 383. SONIX Series User Manual 00.040.144, Revision E Appendix F: References...
  • Page 364 Appendix F: References 00.040.144, Revision E SONIX Series User Manual...

  • Page 365: Appendix G: Glossary

    ....Acceleration Time ....DICOM ....Average Ultrasound Age ....Delete ....Aortic Valve ....Digital Imaging and Communications in DICOM Medicine ....Audio Video Interleave ....Display DISP ....Mean Average Velocity SONIX Series User Manual 00.040.144, Revision E Appendix G: Glossary...
  • Page 366 ... Left Ventricular Posterior Wall diastole LVPWd ....Gestational Age ... Left Ventricular Posterior Wall systole LVPWs ....Gigabyte ....Maximum ....General ....Megabyte ....Graphics Interchange File or Format ....Middle Cerebral Artery Appendix G: Glossary 00.040.144, Revision E SONIX Series User Manual...
  • Page 367 RVWd ....Penetration ....Right Ventricular Wall systole RVWs .... Persistence Persist ....Short Axis ....Pressure Gradient ....Sagital ....Pressure Half Time ....Service Class Provider ..... Pulsatility Index ....Service Class User SONIX Series User Manual 00.040.144, Revision E Appendix G: Glossary...
  • Page 368 ....Volume Rendering ....Thermal Index – Soft Tissue ....Velocity Time Integral ....Tibia Length ....Wall Filter .... Transverse TRANS ..... World Wide Web .... Transparency Transp ....Yolk Sack Appendix G: Glossary 00.040.144, Revision E SONIX Series User Manual...

Table of Contents
