Goodrive300-01A-RT series integrated machine
Function
code
P08.28 Auto fault reset count During the automatic reset period, the fault
Auto fault reset interval
P08.29
Frequency decrease
P08.30
ratio in drop control
FDT1 electrical level
P08.32
detection value
FDT1 lagging detection
P08.33
FDT2 electrical level
P08.34
detection value
FDT2 lagging detection
P08.35
Detection value for
P08.36 frequency being
Running mode of
P08.39
cooling fan
P08.40 PWM selection
Name
1: Enable
will not be reported externally, only the
keypad TRIP indicator blinks, and
shows the warning code. The automatic fault
reset function is enabled for these faults,
such as OUt1, OUt2, Out3, OL1, OL2, OH1,
OH2, EF, CE, ItE, tE, EEP, END, PCE, UPE,
setting
DNE, ETH1, ETH2, PSF, etc. Fault codes
will be reported immediately when these
types of faults occur.
Setting range of P08.28: 0–10
Setting range of P08.29: 0.1–3600.0s
0.00–50.00Hz
0.00–P00.03
-100.0–100.0% (FDT1 electrical level)
value
0.00–P00.03
-100.0–100.0% (FDT2 electrical level)
value
0.0–P00.03
reached
0: Common running mode: Do not run during
sleep.
1: The fan keeps running after power-on
2: Temperature control: The fan turns on
when IGBT temperature is higher than 50℃
and turns off when it is lower than 45℃.
0x00–0x21
LED ones: PWM mode selection
0: PWM mode 1, 3PH modulation and 2PH
modulation
1: PWM mode 2, 3PH modulation
Description
(max. output frequency)
(max. output frequency)
(max. output frequency)
-53-
Function description
Default Modify
5
P17.39
5.0s
0.00Hz
50.00Hz
5.0%
50.00Hz
5.0%
0.00Hz
0
01
○
○
○
○
○
○
○
○
○
◎
