Quantum QT-710 Installation And Operation Manual page 43

ITEM
1
2
3
4
5
6
7
8
9
10
11
Model QT-710/720 Radiographic Table
REPLACEMENT PARTS AND ORDERING INFORMATION
Table 1 below provides a list of replaceable parts for the Radiographic Table.
Figures 17 through 21 show the locations of the replaceable parts in the sys-
tem.
Table 1. Replaceable Parts
DESCRIPTION
Brake Handle Cover
Tabletop (Phenolic)
Receptor Cabinet Rubber Stop
Receptor Cabinet Stop Spacer
Receptor Cabinet Stop Hardware (10-
32 x 2-1/4" screw)
Bearing, R6ZZ
Spring, Extension
Table Wheel, 5" Locking (Model QT-
710 only)
Table wheel, 5" Non-Locking (Model
QT-710 only)
Wheel Mounting Hardware (2-13 x 1"
hex head screw) (Model QT-710 only)
Wheel Mounting Hardware (1/2-13
lockwasher) (Model QT-710 only)
Chapter 5 Maintenance
PART NUMBER
ME30-012
ME31-001
ME41-002
FA80-003
FSH-1436-2
ME40-180S
FA95-001-S
ME41-001
ME41-002
FHN-1316-3
FFW-12N-3
QTY
1
1
2
2
2
8
2
2
2
4
4
31
