OVERVIEW
This manual provides information for installing, operating, and maintaining Quan-
tum Medical Imaging's Mobile and Fixed, Non-Float-Top, Radiographic Tables, Mod-
els QT-710 and QT-720, respectively (hereinafter referred to as the Radiographic
NOTE
Table). It is imperative that all safety procedures described in this manual be
strictly adhered to in order to ensure the safety of both patient and user.
The user
should read
this manual in The key features of the Radiographic Table are as follows:
its entirety
prior to using
this equip-
ment. It
should be kept
in a location
near the
equipment
and readily
accessible to
the those that
operate it.
NOTE
Most tables
are shipped
with a Recep-
tor Cabinet (I.
e., fixed grid
cabinet or
bucky) factory
installed.
However, the
table may be
ordered with-
out a Receptor
Cabinet.
Model QT-710/720 Radiographic Table
Large tabletop area (74 inches long and 28 inches wide) provides an ample
•
examination platform
Typical patient-to-film plane distance of only 2.3 to 2.9 inches provides im-
•
proved radiography with minimum magnification
Compact, low-maintenance design
•
Model QT-710 features large 5-inch wheels for optimal table mobility with
•
foot-operated locks on front wheels
Accepts either a fixed grid or bucky receptor cabinet
•
Both Models QT-710 and QT-720 accept a fixed grid cabinet; Model QT-720
•
also accepts a reciprocating bucky (with or without ACL)
350 lbs. maximum patient load rating
•
INTENDED USE
Model QT-710 and QT-720 Radiographic Tables are intended for use as a pa-
tient support device during the performance of radiographic examinations.
MAIN COMPONENTS
See Figures 1 and 2. Model QT-710 and Model QT-720 Radiographic Tables
contain:
1 Tabletop
2 Receptor Cabinet
3 Receptor Cabinet Lock Lever
4 Compliance Label
5 Non-Locking Wheels (Model QT-710 only)
6 Locking Wheels (Model QT-710 only)
Chapter 1 Introduction
3
