Specifications

Find Quality Products Online at:
Function Range& Resolution
DC Current 400.00 ADC
1500.0 ADC
AC Current 400.00 AAC
True RMS (50Hz to 60
1500.0 AAC
Hz)
400.00 mVDC
4.0000 VDC
DC Voltage 40.000 VDC
400. 00 VDC
1000.0 VDC
400.00 mVAC
4.0000 VAC
AC Voltage
40.000 VAC
True RMS (50 Hz to
400. 00 VAC
1000 Hz)
750.0 VAC
400.00 Ω
4.0000 kΩ
40.000 kΩ
Resistance
400.00 kΩ
4.0000 MΩ
40.000 MΩ
Capacitance 400.00 nF
4000.0 nF
40.00.μF
400.0.μF
4.000 mF
20.00 mF
40.00 mF
Frequency
40.000 Hz
400.00 Hz
4.0000 kHz
40.000 kHz
400.00 kHz
4.0000MHz
40.000MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @ 20% to 80%
Duty Cycle 10.0 to 95.0%
Temp -100.0 to 1000.0C
(type-K)
-148.0 to 1832.0F
GlobalTestSupply
www.
Accuracy (% of reading)
± (2.0% +30digits)
± (2.5% +30digits)
± (2.8% +30digits)
All AC current ranges are specified from 5% to 100% of range
± (0.1% + 5 digits)
± (0.1% + 4 digits)
± (0.5% + 4 digits)
± (0.8% + 40 digits)(50/60Hz)
± (1.0% + 30 digits)
All AC voltage ranges are specified from 5% to 100% of range
± (0.5% + 9 digits)
± (1.0% + 4 digits)
± (2.0% + 10 digits)
± (3.0% + 10 digits)
(3.5% reading + 40 digits)
(3.5% reading + 10 digits)
(5% reading + 10 digits)
Not specified
(0.3% reading + 2 digits)
duty cycle and > 100kHz.
 (1.0% reading + 2 digits)
Pulse width: 100µs - 100ms, Frequency: 10Hz to 100kHz
(1.0% reading + 2.5 C)
(1.0% reading + 4.5F)
(probe accuracy not included)
11 MA1500-en-GB_v1.4 10/18
