Max/Min
Peak Hold
Inrush
Range
LCD Backlight
Automatic Power OFF with Disable
Low battery indication
Find Quality Products Online at:
Press the MAX/MIN button to activate the MAX/MIN recording mode. The display icon "MAX"
1.
will appear. The meter will begins recording and displaying the maximum value measured.
2.
Press the MAX/MIN button and "MIN" will appear. The meter will display the minimum value
measured during the recording session.
3.
Press the MAX/MIN button and "MAX MIN" will appear. The meter will display the present
reading, but will continue to update and store the max and min readings.
4.
To exit MAX/MIN mode press and hold the MAX/MIN button for 2 seconds.
When ACA or ACV is selected, pressing the PEAK button enables the peak capture circuit. The
meter will now capture and display the maximum and minimum peaks of the waveform.
With ACA is selected, press the INRUSH button to activate the inrush capture circuit,
"- - - -" will appear in the display. Any transient condition, generally lasting 110-120 milliseconds,
that occurs during motor start-up will be captured in the display.
In the Voltage, Resistance, Capacitance, Frequency or μA function the meter automatically selects
the best range for the measurements being made. For measurement situations requiring that a
range be manually selected, perform the following:
Press the RANGE button. The "AUTO" display icon will turn off.
1.
2.
Press the RANGE key to step through the available ranges. Observe the decimal point and
units displayed until the preferred range is located.
3.
To exit the Manual Ranging mode and return to Autoranging, press and hold the RANGE key
for 2 seconds.
The LCD is equipped with backlighting for easier viewing, especially in dimly lit areas. Press
turn the backlight on and again to turn it off.
In order to conserve battery life, the meter will automatically turn off after approximately 30 minutes.
To turn the meter on again, turn the function switch to the OFF position and then turn to the desired
function position.
To disable APO:
1.
From the OFF position, hold the MODE button and rotate the FUNCTION switch to a
measurement function.
2.
will appear in the display
3.
Release the MODE button
4.
APO is now disabled (APO icon is off) and will be reset when the Function switch is returned to
the OFF position.
When the
icon and "-----"appears in the display, the battery should be replaced. Refer to the
battery replacement procedure in the maintenance section.
