Basic Specifications - Extech Instruments EX623A Quick Start Manual

BASIC SPECIFICATIONS

For complete specifications, please download the user manual.
Display
Over-range
indication
Battery power
Operating
temperature
Operating humidity
Dimensions
Weight
Safety
Agency approvals
Fuse types
Input impedance
AC bandwidth
AC response
Peak detector
Supplied
Thermocouple
#NAS100185; r. AE/96702/98047; en-US
Backlit LCD with bar graph
OL display
9 V battery
32 to 122℉ (0 to 50℃)
80% RH max. up to 87℉ (31℃)
9.5 x 3.8 x 1.75 in. (241 x 96 x 44.5 mm)
11.1 oz. (315 g)
Meter: Over-voltage CAT III 600 V, Pollution Degree 2
Supplied test leads: Over-voltage CAT IV 600 V, CAT
III 1000 V
ETL, CE, UKCA
200 mA (600 V) ceramic fast blow, 5 x 20 mm
> 10 MΩ (Voltage AC/DC)
50 Hz to 1 kHz (AC voltage); 50/60 Hz (AC current)
True RMS (AC voltage/current)
> 1 ms
Type K; rated 482℉ (250℃) maximum
12
