3. POSITIONING

Remove the protective film from the appliance.
The appliance must be perfectly level, and any differences in floor level can be compensated by
regulating the height of the feet.

4. LEGAL PROVISIONS AND DIRECTIVES

The following provisions must be observed when connecting the appliance:
1. Current building and fire prevention provisions;
2. Current accident-prevention standards;
3. Installation provisions, CEI STANDARDS.
5) ELECTRIC AND EQUIPOTENTIAL WIRING
To reach the terminal block, remove the vertical panel on the right side of the unit.
The main switch upstream from the appliance must be in an easily reached position close to the
appliance itself.
The installer must be supplied with the suitable electric lead (H05 RN-F5x1.5mm²), which must
be firmly fixed in the cable clamp. The single wires must be joined to the corresponding terminals;
the earth wire must be longer than the others to ensure that it can only be disconnected in the
event of pulling, after the power wires have been disconnected.
Appliance safety is only guaranteed with the earth wire correctly connected as required by
current legislation in force.
The appliance must be incorporated in the equipotential system.
The screw is on the bottom of the right side (the serving side) and is clearly marked by a special
symbol.
4
