6) WATER CONNECTIONS

INLET:
The pressure in the main water supply must be between 50 and 500 Kpa, in the event the
pressure is higher, a pressure reducer must be installed upstream from the appliance.
¾" attachments are used.
OUTLET:
¾" attachments are used. In the event the outlet pipe needs extending, only heat resistant piping
must be used with a fixed diameter of ¾". The outlet pipe must flow into an open drain, to avoid
polluting the appliance.

7) GENERAL OPERATING INSTRUCTIONS

Please read these instructions carefully, as they give the basic safety, operating and
maintenance instructions for the appliance.
Before leaving the factory, the appliance underwent very strict tests and controls by our qualified
staff. Any repair work that may be required must only be performed by qualified persons.
We strongly recommend contacting the authorised centre where you purchased your appliance,
giving clear details about the problem and the construction details given on the data plate, to
ensure that precise and specific servicing assistance can be supplied.
BAIN-MARIE UNITS
The appliance must not be used unless there is sufficient water in the tank, as given in the
instructions on page 11.
HEATED GLASS TOPS
WARNINGS:
a) Should there be even the smallest sign of breakage in the heated surface, the appliance
must be immediately disconnected from the mains and our service department should be
contacted.
b) The hardened glass surface must be protected against impact, knocks and violent
mechanical and thermal stress. At the end of each day, the top must be carefully cleaned
(refer to "CLEANING AND CARE") to guarantee long life for the appliance.
At the end of each day's work, the appliance must be turned off and disconnected from
the mains upstream.
The appliance may be supplied on 4 castors, 2 of which have brakes.
The installer must install a coiled lead and in the event the appliance needs moving, it must be
turned off and disconnected from the mains beforehand.
Failure to comply with this rule could jeopardize safety of both the appliance and the operator
The manufacturer declines all responsibility for any alterations made to the original functions of
the appliance, for failure to observe the instructions or for any alterations or additions made to the
devices.
5
