- Page 1 VMS-APL Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor Fanless Vehicle Telematics System Quick Reference Guide Ed – 25 October 2018 Copyright Notice Copyright 2018 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017HAI0A2R...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ 2 VMS-APL Quick Reference Guide...
-
Page 3: Table Of Contents
1.4.1 Front View ..........................13 1.4.2 Rear View ........................... 13 System Dimensions ..................... 15 Hardware Configuration ................... 16 VMS-APL connector mapping ................17 2.1.1 Serial Port 1 connector (COM1)....................17 2.1.2 Serial Port 2 connector/CAN connector (COM2/CAN) .............. 18 2.1.3 DC power-in connector (DC-in).................... - Page 4 CSM Configuration ......................... 53 3.6.2.10 NVMe Configuration ........................54 3.6.2.11 USB Configuration ......................... 54 3.6.2.12 Security Configuration ........................55 3.6.3 Chipset ............................. 56 3.6.3.1 North Bridge ..........................56 3.6.3.2 South Bridge ..........................57 3.6.3.3 Uncore Configuration ........................58 4 VMS-APL Quick Reference Guide...
- Page 5 4. Drivers Installation ....................... 72 Install Chipset Driver ................... 73 Install TXE Driver ....................74 Install VGA Driver ....................75 Install Audio Driver (For Realtek ALC892) ............76 Install Gigabit Driver .................... 77 Install Serial IO Driver ..................79 VMS-APL Quick Reference Guide...
-
Page 6: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. Packing List 1 x VMS-APL Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor Fanless Vehicle Telematics System Other major components include the followings: ... -
Page 7: System Specifications
1 x Push Button for Power on/off w/ LED I/O Connector 1 x Push Button for Reset in hiding 3 x LEDs for Storage, WLAN/ HSDPA 1 x Line-Out 1 x Mic-In 1 x 8-bit GPIO from EC VMS-APL Quick Reference Guide... - Page 8 1 x 5-pin lockable connector for LVDS inverter backlight control (JBKL1) 1 x 2 x 4-Pin header for SPI (SPI1) 1 x 6-Pin DC Output Connector (DCOUY_S1), 12V/6A for DC-Out and 8 VMS-APL Quick Reference Guide...
- Page 9 Single power ATX Support S0, S3, S4, S5 and ACPI 5.0 Compliant 9.4” x 7.3” x 2.44 (239mm x 186mm x 62mm) Dimension 2.7KG(4.85lbs) Weight Compliant with the color plan of the new family look Color Mounting Kit Wall mount kit (Standard) VMS-APL Quick Reference Guide...
- Page 10 This function will be active if ACC Function (JACC1) sets up Disable (Industrial PC power mode). Power Input Selection (SW2) To set up the DC input voltage is +12Vdc, +24Vdc or wide range from 10 VMS-APL Quick Reference Guide...
- Page 11 +12Vdc, +24Vdc or wide range from +9~36Vdc. The following behaviors happen if ACC Function (JACC1) sets up as Enable: VMS-APL won’t power on if the DC Input voltage is lower than the startup voltage. VMS-APL will automatically power on, if the DC input voltage reaches the startup voltage.
- Page 12 VMS-APL will cancel the delay and stayed in power off status, if the ignition is turned off again and power on delay is in process.
-
Page 13: System Overview
2 x SIM card slot SD card slot SD card slot 2.5” Drive Bay 2.5” Driver Bay socket GPIO General purpose I/O connector Line-out Line-out jack Mic-in audio jack Mic-in WWAN WWAN Indicator WLAN WLAN Indicator HDD Indicator VMS-APL Quick Reference Guide 13... - Page 14 VMS-APL RESET Reset button 2 x RJ-45 Ethernet connector DP connector COM1 Serial port 1 connector Serial port 2 connector COM2/CAN CAN connector LVDS LVDS connector DC power-in connector DC-in DC-out DC power-out connector 14 VMS-APL Quick Reference Guide...
-
Page 15: System Dimensions
Quick Reference Guide 1.5 System Dimensions (Unit: mm) VMS-APL Quick Reference Guide 15... -
Page 16: Hardware Configuration
VMS-APL 2. Hardware Configuration Jumper and Connector Setting, Driver and BIOS Installing For advanced information, please refer to: 1- EBM-APLV included in this manual. Note: If you need more information, please visit our website: http://www.avalue.com.tw 16 VMS-APL Quick Reference Guide... -
Page 17: Vms-Apl Connector Mapping
In RS-232 Mode Signal PIN PIN Signal NDCD# NDSR# NRXD NRTS# NTXD NCTS# NDTR# NRI# In RS-422 Mode Signal PIN PIN Signal TxD1- TxD1+ RxD1+ RxD1- In RS-485 Mode Signal PIN PIN Signal DATA1- DATA1+ VMS-APL Quick Reference Guide 17... -
Page 18: Serial Port 2 Connector/Can Connector (Com2/Can)
COM2/CAN Bus mode selected by SW1 pin8 & NRXD NRTS# JUART_SEL1/2. NTXD NCTS# NDTR# NRI# CAN BUS DB9/M In RS-422 Mode 1708- 1708+ Signal PIN PIN Signal 1939- TxD1- 1939+ TxD1+ RxD1+ RxD1- In RS-485 Mode Signal PIN PIN Signal DATA1- DATA1+ 18 VMS-APL Quick Reference Guide... -
Page 19: Dc Power-In Connector (Dc-In)
2.1.4 DC power-out connector (DC-out) Signal +12V 2.1.5 LVDS connector (LVDS) PIN Signal PIN Signal PIN Signal PS_ON 3.3V Backlight_EN VBRIGHT USB_VCC Note: This connector included LVDS, USB, 12V and 5V CLK+ USB_GND CLK- interfaces. VMS-APL Quick Reference Guide 19... -
Page 20: General Purpose I/O Connector (Gpio)
VMS-APL 2.1.6 General purpose I/O connector (GPIO) Signal Signal PIN Signal DIO_GPO0 DIO_GPI2 DIO_GPI0 DIO_GPO3 +3.3V DIO_GPO1 DIO_GPI3 DIO_GPI1 MBCLK DIO_GPO2 SMB_DATA 20 VMS-APL Quick Reference Guide... -
Page 21: Ebm-Aplv Overviews
Quick Reference Guide 2.2 EBM-APLV Overviews VMS-APL Quick Reference Guide 21... - Page 22 VMS-APL 22 VMS-APL Quick Reference Guide...
-
Page 23: Ebm-Aplv Jumper & Connector List
CAN connector 7 x 2 header, pitch 2.00 mm CAN1 CAN Module slot DP connector MPCIE1/2 Mini PCI Express connector 1/2 PWRBTN Power button RSTBTN Reset button LED Power HDD NGFF1 M.2 KEY-B 2242/3042 connector VMS-APL Quick Reference Guide 23... - Page 24 SATA1 Serial ATA connector 1 DCOUT1 DC Output connector 6 x 1 wafer, pitch 2.50 mm JEC_ROM2 EC Debug connector 5 x 2 header, pitch 2.00 mm SD card slot SIMCARD1/2 SIM card slot 1/2 24 VMS-APL Quick Reference Guide...
-
Page 25: Ebm-Aplv Jumpers & Connectors Settings
Quick Reference Guide 2.4 EBM-APLV Jumpers & Connectors settings 2.4.1 Clear CMOS (JCMOS1) Protect* Clear CMOS *Default 2.4.2 COM 1/2 pin 9 signal selector (JRI1/2) JRI1 Ring* JRI2 +12V * Default VMS-APL Quick Reference Guide 25... -
Page 26: Serial Port 1/2 - Rs232/422/485 Mode Select (Jcom_Sel1/2)
It is Vehicle PC power mode (Power on/off controlled by Ignition or Power button) if ACC Function sets up as Enable. It is Industrial PC power mode (Power on/off controlled by Power button) if ACC Function sets up as Disable. 26 VMS-APL Quick Reference Guide... -
Page 27: Digital Input Selector (Jdi1)
Quick Reference Guide 2.4.5 Digital Input selector (JDI1) Dry* Mode Digital Input Logic level 1: Close to GND Logic level 0: Open Logic level 1: < 3V Logic level 0: 5V ~ 30V * Default VMS-APL Quick Reference Guide 27... -
Page 28: Digital Output Selector (Jdo1)
VMS-APL 2.4.6 Digital Output selector (JDO1) Dry* * Default Note: Output Voltage: Max 250 mA per channel, current sink type. 28 VMS-APL Quick Reference Guide... -
Page 29: Multi-Function Select (Sw1)
2.4.7 Multi-function select (SW1) In Serial Port 1 mode RS-232* RS-422 RS-485 In Serial Port 2 mode RS-232* RS-422 RS-485 * Default Power mode DDI1 mode(DP+) DisplayPort* HDMI DDI0 mode(IET) DisplayPort HDMI* UART2 mode COM* VMS-APL Quick Reference Guide 29... -
Page 30: Power Input Selector (Sw2)
VMS-APL 2.4.8 Power Input selector (SW2) +12V* +24V +9V-+36V * Default 2.4.9 LCD backlight brightness adjustment (JVR1) PWM Mode* DC Mode * Default 30 VMS-APL Quick Reference Guide... -
Page 31: Can/Com Selector (Juart_Sel1/2)
Quick Reference Guide 2.4.10 CAN/COM selector (JUART_SEL1/2) COM* JUART_SEL2 JUART_SEL1 * Default 2.4.11 LPC port connector (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 PLT_RST_BUF# LPC_AD2 LPC_FRAME# LPC_AD3 LPC1_PORT80_CLK LPC_SERIRQ +5VSB VMS-APL Quick Reference Guide 31... -
Page 32: Lcd Inverter Connector (Jbkl1)
VMS-APL 2.4.12 LCD inverter connector (JBKL1) Signal +12V BKLEN VBRIGHT 2.4.13 BIOS SPI connector (BIOS_SPI1) Signal PIN PIN Signal +1.8VSB SPI_CS#0 SPI_CLK SPI_MISO SPI_MOSI SPI_HOLD# 32 VMS-APL Quick Reference Guide... -
Page 33: Dc Output Connector (Dcout1)
Quick Reference Guide 2.4.14 DC Output connector (DCOUT1) Signal +12VSB +12VSB +12VSB 2.4.15 EC Debug connector (JEC_ROM2) Signal Signal +VSPI_EC EC_FSCE# EC_FSCK EC_FMISO EC_FMOSI EC_HOLD# EC_SMCLK_DE EC_SMDAT_DE VMS-APL Quick Reference Guide 33... -
Page 34: On-Board Header For Usb2.0 (Jusb2)
VMS-APL 2.4.16 On-board header for USB2.0 (JUSB2) Signal Signal +5VSB +5VSB USB_HUB_Z_DN_4 USB_HUB_Z_DN_3 USB_HUB_Z_DP_4 USB_HUB_Z_DP_3 2.4.17 General purpose I/O connector (DIO1) Signal Signal DIO_GPO0 DIO_GPI0 DIO_GPO1 DIO_GPI1 DIO_GPO2 DIO_GPI2 DIO_GPO3 DIO_GPI3 SMB_SCL_S0 SMB_SDA_S0 +3.3V 34 VMS-APL Quick Reference Guide... -
Page 35: Can Module Slot (Can1)
Quick Reference Guide 2.4.18 CAN Module slot (CAN1) Signal Signal CAN_PWR CAN_8 CAN_IND CAN_9 BAT_GND CAN_WAKE CAN_11 CAN_TX CAN_12 CAN_RX CAN_13 CAN_14 2.4.19 DC Input connector (JVIN1) Signal +VIN_BAT ACC_ON VMS-APL Quick Reference Guide 35... -
Page 36: Battery Connector 1 (Bt1)
VMS-APL 2.4.20 Battery connector 1 (BT1) Signal +RTCBATT 2.4.21 Battery connector 2 (BT2) Signal +GPSBATT Note: Reserved for GPS module. 36 VMS-APL Quick Reference Guide... -
Page 37: Lvds Connector (Jlvds1)
Quick Reference Guide 2.4.22 LVDS connector (JLVDS1) Signal PIN PIN Signal +3.3V +3.3V LVDS_DATA0_P LVDS_DATA1_P LVDS_DATA0_N LVDS_DATA1_N LVDS_DATA2_P LVDS_DATA3_P LVDS_DATA2_N LVDS_DATA3_N LVDS_DATA4_P LVDS_DATA5_P LVDS_DATA4_N LVDS_DATA5_N LVDS_DATA6_P LVDS_DATA7_P LVDS_DATA6_N LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_CLK1_N LVDS_CLK2_N +12V +12V VMS-APL Quick Reference Guide 37... -
Page 38: Installing Hard Disk & Memory, Pci Devices
Step 3. Slide HDD into its bracket until properly seated. Step 4. Secure HDD by means of 4 screws. Step 5. Insert HDD bracket into designated locations and fasten with 2 screws to complete HDD installation. 38 VMS-APL Quick Reference Guide... -
Page 39: Bios Setup
Quick Reference Guide 3.BIOS Setup VMS-APL Quick Reference Guide 39... -
Page 40: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 40 VMS-APL Quick Reference Guide... -
Page 41: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. VMS-APL Quick Reference Guide 41... -
Page 42: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 42 VMS-APL Quick Reference Guide... -
Page 43: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. VMS-APL Quick Reference Guide 43... -
Page 44: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 44 VMS-APL Quick Reference Guide... -
Page 45: Trusted Computing
Item Options Description Enables or Disables BIOS support for security Disable, Security Device Support device. O.S. will not show Security Device. TCG EFI Enable[Default] protocol and INT1A interface will not be available. 3.6.2.2 ACPI Settings VMS-APL Quick Reference Guide 45... -
Page 46: It8528 Super Io Configuration
Wake Up by Ring from S3/S4/S5. Enabled[Default], 3.6.2.3 IT8528 Super IO Configuration You can use this item to set up or change the IT8528 Super IO configuration for serial ports. Please refer to 3.6.2.3.1~ 3.6.2.3.2 for more information. 46 VMS-APL Quick Reference Guide... -
Page 47: Serial Port 1 Configuration
Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). 3.6.2.3.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.3.2 Serial Port 2 Configuration VMS-APL Quick Reference Guide 47... -
Page 48: Ec 8528 H/W Monitor
Power On Delay 5 Min Power On Delay. 10 Min 15 Min 30 Min 1 Hour w/o delay[Default] 20 Sec 1 Min Power Off Delay 5 Min Power Off Delay. 10 Min 30 Min 1 Hour 48 VMS-APL Quick Reference Guide... -
Page 49: S5 Rtc Wake Settings
Enable or disable System wake on alarm Disabled[Default], event. Select Fixed Time, system will wake on Wake system from S5 Fixed Time the hr::min::sec specified. Select Dynamic Dynamic Time Time, System will wake on the current time + Increase minute(s). VMS-APL Quick Reference Guide 49... -
Page 50: Serial Port Console Redirection
Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.6.1 Legacy Console Redirection Settings Item Option Description Select a COM port to display redirection of Legacy Serial Redirection Port COM0[Default], Legacy OS and Legacy OPROM Messages. 50 VMS-APL Quick Reference Guide... -
Page 51: Cpu Configuration
PROCHOT# to throttle the processor. Disabled, Thermal Monitor Enable/Disable Thermal Monitor. Enabled[Default] Disabled[Default], Monitor Mwait Enabled Enable/Disable Monitor Mwait. Auto HW_ALL[Default] P-STATE Coordination SW_ALL Change P-STATE Coordination type. SW_ANY Disabled[Default], Enable/Disable Digital Thermal Sensor. Enabled VMS-APL Quick Reference Guide 51... -
Page 52: Socket 0 Cpu Information
VMS-APL 3.6.2.7.1 Socket 0 CPU Information 3.6.2.7.2 CPU Power Management Configuration Item Options Description Disabled, EIST Enable/Disable Intel SpeedStep. Enabled[Default] Disabled, Turbo Mode Turbo Mode. Enabled[Default] 52 VMS-APL Quick Reference Guide... -
Page 53: Network Stack Configuration
Quick Reference Guide 3.6.2.8 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default], 3.6.2.9 CSM Configuration Item Options Description Enabled CSM Support Enable/Disable CSM Support. Disabled[Default] VMS-APL Quick Reference Guide 53... -
Page 54: Nvme Configuration
Item Options Description Enables Legacy USB support. AUTO option Enabled[Default] disables legacy support if no USB devices are Legacy USB Support Disabled connected. DISABLE option will keep USB Auto devices available only for EFI applications. 54 VMS-APL Quick Reference Guide... -
Page 55: Security Configuration
100ms, for a Hub port the delay is taken form Hub descriptor. 3.6.2.12 Security Configuration Item Options Description Disabled[Default] TXE HMRFPO TXE HMRFPO. Enabled, Disabled TXE EOP Message Send EOP Message Before Enter OS. Enabled[Default], VMS-APL Quick Reference Guide 55... -
Page 56: Chipset
VMS-APL 3.6.3 Chipset 3.6.3.1 North Bridge Item Option Description 2 GB[Default] 2.25 GB Max TOLUD Maximum Value of TOLUD. 2.5 GB 2.75 GB 56 VMS-APL Quick Reference Guide... -
Page 57: South Bridge
BIOS assignment. This is disabled automatically assignment Enabled, when Aperture Size is set to 2048MB. 3.6.3.2 South Bridge Item Option Description Quiet Serial IRQ Mode Configure Serial IRQ Mode. Continuous[Default] Windows[Default] OS Selection Android Select the target OS. Intel Linux VMS-APL Quick Reference Guide 57... -
Page 58: Uncore Configuration
1600x1200 24/2 1366x768 24/1 1920x1080 24/2 1680x1050 24/2 LVDS Brightness Control Method. 1.BIOS BIOS[Default] Brightness Control Method 2.Brightness Button 3.Variable Resistor OS driver 4.OS Driver. LVDS Back Light PWM Select LVDS back light PWM duty. 58 VMS-APL Quick Reference Guide... -
Page 59: South Cluster Configuration
Quick Reference Guide 100%[Default] 200[Default] LVDS Back Light PWM Select LVDS back light PWM Frequency. Frequency 3.6.3.4 South Cluster Configuration VMS-APL Quick Reference Guide 59... -
Page 60: Hd-Audio Configuration
VMS-APL 3.6.3.4.1 HD-Audio Configuration Item Option Description Disable HD-Audio Support Enable/Disable HD-Audio Support. Enable[Default], 3.6.3.4.2 PCI Express Configuration 60 VMS-APL Quick Reference Guide... -
Page 61: Pci Express Root Port 3(I210/211)
Item Option Description Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 VMS-APL Quick Reference Guide 61... -
Page 62: Pci Express Root Port 4(I210/211)
Item Option Description Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 62 VMS-APL Quick Reference Guide... -
Page 63: Pci Express Root Port 5(Switch2-Mpcie)
Item Option Description Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 VMS-APL Quick Reference Guide 63... -
Page 64: Pci Express Root Port 6(Switch1-Iet)
Item Option Description Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 64 VMS-APL Quick Reference Guide... -
Page 65: Sata Drives
Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. Disabled[Default] Enable/Disable SATA Port 0/1 DevSlp. SATA Port 0/1 DevSlP Enabled Board rework for LP needed before enable. VMS-APL Quick Reference Guide 65... -
Page 66: Scc Configuration
VMS-APL 3.6.3.4.4 SCC Configuration Item Option Description Enable[Default] SCC SD Card Support(D27:F0) Enable/Disable SCC SD Card Support. Disable Enable SCC eMMC Support(D28:F0) Enable/Disable SCC eMMC Support. Disable[Default] 3.6.3.4.4 USB Configuration 66 VMS-APL Quick Reference Guide... -
Page 67: Security
USB devices are detectable and xHCI Mode Disable usable during boot and in OS. Do not disable it unless for debug purpose. 3.6.4 Security Setup Administrator Password Set setup Administrator Password User Password Set User Password VMS-APL Quick Reference Guide 67... -
Page 68: Secure Boot
VMS-APL 3.6.4.1 Secure Boot Item Option Description Secure Boot activated when Platform Key(PK) is Disabled Attempt Secure Boot enrolled, System mode is User/Deployed, and CSM Enabled[Default] function is disabled. 68 VMS-APL Quick Reference Guide... -
Page 69: Boot
1~ 65535 activation key. 65535(0xFFFF) means indefinite waiting. On[Default] Bootup NumLock State Select the Keyboard NumLock state Disabled[Default] Quiet Boot Enables or disables Quiet Boot option Enabled Boot Option #1 Set the system boot order. VMS-APL Quick Reference Guide 69... -
Page 70: Save And Exit
VMS-APL 3.6.6 Save and exit 3.6.6.1 Save Changes and Reset Reset the system after saving the changes. 70 VMS-APL Quick Reference Guide... -
Page 71: Discard Changes And Reset
This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell.efi) from one of the available filesystem devices. VMS-APL Quick Reference Guide 71... -
Page 72: Drivers Installation
VMS-APL 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 72 VMS-APL Quick Reference Guide... -
Page 73: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation Step 3. Click Install. process, click Continue to go on. Step1. Click Next. Step 4. Click Finish to complete setup. Step 2. Click Accept. VMS-APL Quick Reference Guide 73... -
Page 74: Install Txe Driver
If the warning message Step 3. Click Next to continue installation. appears while the installation process, click Continue to go on. Step 4. Click Finish to complete setup. Step1. Click Next to start installation. Step 2. Click Next. 74 VMS-APL Quick Reference Guide... -
Page 75: Install Vga Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 5. Click Finish to complete setup. Step 2. Click Yes to accept license agreement. VMS-APL Quick Reference Guide 75... -
Page 76: Install Audio Driver (For Realtek Alc892)
/Driver_Audio/Realtek/ALC892/VMS-APL_Audio. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Next to continue setup. Step 2. Click Finish to complete the setup. 76 VMS-APL Quick Reference Guide... -
Page 77: Install Gigabit Driver
Windows 10 operation system. Step 3. Click Next. Step 4. Click Next to proceed. Step 1. Click Install Drivers and Software. Step 5. Click Install. Step 2. Click Next to accept license agreement. VMS-APL Quick Reference Guide 77... - Page 78 VMS-APL Step 6. Click Finish to complete the setup. 78 VMS-APL Quick Reference Guide...
-
Page 79: Install Serial Io Driver
Windows 10 operation system. Step 3. Click Next. Step 4. Click Next to proceed. Step 1. Click Next. Step 2. Click Next. Step 5. Click Finish to complete the setup VMS-APL Quick Reference Guide 79...
