Summary of Contents for Burmester Classic Series

  • Page 3 Dear Audiophile, Thank you for choosing this Burmester audio component. We sincerely appreciate your trust in us. You have purchased a POWER AMP which excells in musical fidelity and combines uncompromising manufacturing quality with technical innovation and the highest degree of operating flexibility.

  • Page 4: Stand By - Led

    STAND BY - LED POWER LED POWER - button Input, right channel ( 9) AC mains switch Output, right channel, negative (10) Output, left channel, positive Output, right channel, positive (11) Output, left channel, negative AC voltage selector / fuse box (12) Input, left channel AC input...
  • Page 5 WIRING DIAGRAM FOR STEREO OPERATION WIRING DIAGRAM FOR MONO OPERATION (bridged) from pre - amp from pre - amp blue right channel left channel MONO adapter WIRING DIAGRAM FOR BI - AMPING from pre - amp right and with a split passiv frequence - crossover left channel respectively built into the speaker Tweeter /...

  • Page 6: Start-Up Procedure

    START - UP PROCEDURE Content of box Besides the power amp 956 MK 2 the shipping carton contains the following: · 1 power amplifier 956 MK 2 · 1 owner's manual · 1 power cord · 2 adapter plugs (16) ·...

  • Page 7: Operating The Amplifier

    OPERATING THE AMPLIFIER AC mains switch The AC mains switch (7) is located at the rear of the housing. It disconnects the 956 MK 2 from the AC supply. When it is set to OFF the unit is completely disconnected, the LEDs on the front panel remain dark. Switching to ON activates the stand - by mode and the left STAND BY- LED (1) on the front panel illuminates.

  • Page 8: The Monitoring System

    956 MK 2. The impedance of our cables is ideally matched with all BURMESTER audio components. For the cleanest power supply we recommend our triple - shielded power cord BURMESTER - POWER.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions (W x H x D): 482 x 191 x 482 mm Weight: app. 30 kg Power consumption: ( stand by ): Idling: 90 W Fuses Power ( max. ): 600 W 230 V setting: 2 x 3,15 A / slow - blow 115V setting: 2 x 6,3 A / slow - blow PLEASE NOTE:...

This manual is also suitable for:

956 mk 2
