Polypipe SmartStat Manual page 32

Wiring Diagram -
LS
TO BOILER
LR
HEATING VALVE
This product must only be installed by a quali ed electrician
31
UFHSMARTW
RT2 RT1 - A2 A1
L
N NEUTRAL
LS & LR ARE NORMALLY THE
ROOM THERMOSTAT CONNECTIONS
and comply with local installation regulations.
Smart Series
SmartStat to Valve
230VAC
TO CONNECT BOILER CONSULT
N L
BOILER MAKERS DIAGRAM
LIVE
NEUTRAL
230V SUPPLY IN
