Wiring Diagram -
RT2
VOLT FREE TO BOILER
LS & LR ARE NORMALLY THE
ROOM THERMOSTAT CONNECTIONS
This product must only be installed by a quali ed electrician
UFHSMARTW
RT1
-
A2 A1
LR
LS
and comply with local installation regulations.
SmartStat
SmartStat to Boiler Volt free
230VAC
TO CONNECT BOILER CONSULT
N
L
BOILER MAKERS DIAGRAM
LIVE
NEUTRAL
230V SUPPLY IN
30
