D) Scenario Of Connecting An Entrance Gate With The Central Units - Intratone Visio Installation And Connection

S
D)
CENARIO OF CONNECTING AN ENTRANCE GATE WITH THE
UNITS
/ 2
Connections in black refer to (+ / - and D+ / D- and A+ / A-)
S
E)
CENARIO OF CONNECTING AN ENTRANCE GATE PLUS A BUILDING
It is mandatory to use an EEN-CEN12 central unit with, in this example, an extension board.
Scenario:
"Audio and Video" calls from the entrance gate
Only "Audio" calls can be made from the building entrance.
/ 6
Extension board
Building
/ 6
EN-V233 – 5004 – AA Installation and use of call panel + key safe EEN-PVIBCV3
/2
/ 4
Connections in red refer to video (V+ / V-)
Add an extension board - doors 3 and 4
/ 6
Entrance
/ 2
In this example, door 4 remains available
[41 49 and CRT]
Connections in red refer to Video (V+ / V-)
Connections in black refer to (+ / - and D+ / D- and A+ / A-)
2
TYPES OF CENTRAL
/ 6 / 6
/ 2
There can only be one
key safe per central unit.
Page 6 / 12
