Summary of Contents for NIMO Easy Dryer 1700
- Page 1 Easy Dryer 1700/1900 Sensor Dryer 1700/1900 427001137 Keep this manual so that it will always be Drying cabinet User manual on hand for future reference.
- Page 2 NIMO offers you all these features. When you buy a NIMO product you can be sure that the inside is just as good as the outside and that the ethics and morals that go into building this product are just as high as the quality and function you are getting.
-
Page 3: Table Of Contents
CONTENTS THIS USER MANUAL OPERATION EASY DRYER 1700 / 1900 CONTROL PANEL SAFE OPERATION CHOICE OF SETTINGS DESCRIPTION OF THE DRYING CABINET 6 CARE UNPACKING CLEANING PACKAGING MATERIALS SERVICING ASSEMBLY KIT MANAGEMENT OF END-OF-LIFE DRYING REHANGING OF DOOR CABINET POSITIONING/ATTACHMENT... -
Page 4: This User Manual
THIS USER MANUAL The contents of this user manual describe Note: Keep this user the drying cabinet’s function and opera- manual so that it is always tion and instructions for installation and to hand for future use maintenance. -
Page 5: Safe Operation
SAFE OPERATION This advice on safe operation has been compiled to enable you to avoid incorrect use and unnecessary risks of accidents and should be read before the drying cabinet is installed and used. CAUTION This equipment is intended only to be used to dry fabrics washed in water. -
Page 6: Description Of The Drying Cabinet
DESCRIPTION OF THE DRYING CABINET The drying cabinet operates with hot air that removes moisture from the laundry. Heating and fan components are combined in the upper part of the drying cabinet behind the con- trol panel. The drying cabinet exists in two variants. Easy Dryer, where the cabinet is controlled by two knobs, one for setting power modes and the other for regulating drying time. - Page 7 AIR FLOW IN THE DRYING CABINET Note the direction of air flow inside the cabinet when positioning laundry. See also this section.
-
Page 8: Unpacking
UNPACKING PACKAGING MATERIALS The packaging that protects the drying cabinet against damage in transit has been chosen with concern for the environment in mind and is therefore recyclable. Packaging that is returned to the material cycle means reduced consumption of raw materials and a smaller volume of waste. -
Page 9: Assembly Kit
UNPACKING ASSEMBLY KIT Plastic plug Draught stabiliser Spacer 8.2x12x15 Hose, Ø 120 x 1000 mm Spigot Screw TRX 5x70 fzk Washer NB 5x25... -
Page 10: Rehanging Of Door
REHANGING OF DOOR The door may be right-hung or left-hung. 3 Detach the hinge pin at the upper hinge Lay the drying cabinet down on its side. (2) and install it on the opposite side. The 2 Loosen the hinge pin at the lower hinge pin has a slot for a screwdriver. -
Page 11: Positioning/Attachment
POSITIONING/ATTACHMENT The drying cabinet is intended only for location indoors in a dry place and secured to a wall. The drying cabinet must not be placed in an environment in which high-pressure water is used for cleaning. The drying cabinet must be level on a flat The cabinet must be attached to a wall to surface, resting on all four feet. -
Page 12: Evacuation / Supply Air
EVACUATION / SUPPLY AIR When the cabinet is on, approx. 95 m³ moist air per hour is evacuated. It must therefore be ensured that air can enter the room to replace the moist air that is vented out. CONNECTION TO EVACUATION The drying cabinet is connected to exhaust air ventilation in accordance with standard. - Page 13 EVACUATION / SUPPLY AIR With draught stabiliser Moist air out Connect the flexible hose (2) to the spigot. Connect the other end of the hose to the draught stabiliser (3) which is then pressed home on the exhaust vent in the room. The drying cabinet must not be connected to a flue.
-
Page 14: Electrical Connection
ELECTRICAL CONNECTION The drying cabinet must be connected to a If the mains lead for any reason is dam- 230 V single-phase 50-60 Hz and protectively aged, it must be replaced. A genuine earthed wall socket. spare part can be obtained from the dealer who supplied the cabinet. -
Page 15: Start-Up
START-UP Read these op erating CAUTION Read the safety instructions instructions before using on page 5 before using the cabinet. the drying cabinet for the first time. 1 Make sure that the cabinet is firmly attached to the wall. See page 11. 2 Make sure that no packaging material has been left behind. -
Page 16: Arranging Laundry For Drying
ARRANGING LAUNDRY FOR DRYING There are three sections with hangers in the cabinet, depending on choice of interior fittings. Each section has a number of rails for hanging laundry. USER TIPS Hang the items in the drying cabinet according to how much space they require Always following the laundry instructions - not according to their weight. -
Page 17: Operation Of Sensor Dryer 1700/1900
OPERATION OF SENSOR DRYER 1700/1900 The drying cabinet is equipped with three automatic programmes and three manually time-controlled programmes suited to different types of clothing. There are also extra functions for the automatic programmes. The drying process is controlled by sensors or timer and temperature settings. Choice of drying programme is guided by: - energy efficiency - gentle treatment of fabrics - dealing with fabrics that are difficult to dry... -
Page 18: Control Panel
OPERATION SENSOR DRYER 1700 / 1900 CONTROL PANEL Programme selec- Programme selection for au- tion for manual time tomatic time control of the control of the drying drying process process ON/OFF Display showing time remaining for selected drying programme. Under the time reading, a row of LEDs shows that the drying Start/Stop process is under way. - Page 19 OPERATION SENSOR DRYER 1700/1900 You can choose an optional extra function, EXTRA DRY, for AUTO LOW and AUTO HIGH. EXTRA DRY is for fabrics that are thicker and more difficult to dry, such as children's overalls, ski suits, etc. AUTO HIGH and EXTRA DRY or AUTO LOW and EXTRA DRY now light up.
-
Page 20: Start-Up Of The Drying Cabinet With Automatic Time Control
OPERATION OF SENSOR DRYER 1700/1900 START-UP OF THE DRYING CABINET WITH AUTOMATIC TIME CONTROL The cabinet is started by pressing ON/OFF. The cabinet is activated by default with the previous programme selection active. If no programme has been selected previously or if the cabinet has been without power or is completely new, the cabinet is started in AUTO HIGH by default. -
Page 21: Starting The Drying Cabinet With Manual Time Control
OPERATION OF SENSOR DRYER 1700/1900 STARTING THE DRYING CABINET WITH MANUAL TIME CONTROL The cabinet is started by pressing ON/OFF. The cabinet is activated with the previous programme selection active. If no pro- gramme has been selected previously or if the cabinet has been without power or is completely new, the cabinet is started in AUTO HIGH by default, i.e. -
Page 22: Door
OPERATION OF SENSOR DRYER 1700/1900 DOOR Avoid opening the door while the drying process is under way as this prolongs the programme time. When the door is opened, the display shows -P-. You have 5 minutes in which to close the door before the cabinet turns the programme off completely and the cabinet has to be restarted. - Page 23 OPERATION SENSOR DRYER 1700/1900 Parameters to adjust If the laundry is felt not to be dry, increase the parameter value for the programme- specific parameter If the laundry is felt to be over-dried, long drying time,reduce the parameter value for the programme-specific parameter. See the table for the parameter of the programme concerned to be adjusted.
-
Page 24: Breakdowns
BREAKDOWNS OVERHEAT CUT-OUT The cabinet is equipped with an overheat cut-out. This trips when the temperature in the fan unit exceeds 120 °C. Sensor Dryer When the overheat cut-out has tripped, the display and LEDs flash. The user can now reset the overheat cut-out by turning off the power supply with the switch inside the roof of the cabinet. - Page 25 BREAKDOWNS OFF - press the switch in the rear hole ON - press the switch in the front hole Illustration shows the Sensor Dryer drying cabinet Toggle switch behind inner panel Hole in inner panel for operation of the toggle switch with a screwdriver or similar tool...
-
Page 26: Operation Easy Dryer 1700 / 1900
OPERATION EASY DRYER 1700 / 1900 CONTROL PANEL HEAT DRYING TIME The cabinet is equipped with two knobs The right-hand knob regulates drying for setting different power modes. time steplessly up to four hours. The left-hand knob regulates heat with power modes on a stepless scale. -
Page 27: Care
This information can be found on the identification plate located inside the cabinet. Identification plate (inside) Illustration shows the Sensor Dryer drying cabinet Name of the drying cabinet Article number Serial number (12 digits) Follow NIMO instructions in repair and replacement of parts. -
Page 28: Management Of End-Of-Life Drying Cabinet
MANAGEMENT OF END-OF-LIFE DRYING CABINET When the drying cabinet has reached the end of its useful life, it must be taken to a recycling centre for disposal. Many parts of the drying cabinet can be re- used, but it also contains other material that must be dispose of correctly. -
Page 29: Technical Data Sensor Dryer 1700 / 1900
TECHNICAL DATA SENSOR DRYER 1700 / 1900 Capacity: Up to 6.0 kg laundry (cotton) Dewatering capacity: Up to 25 g/min Electrical connection: Single-phase 230 V, 50-60 Hz Fuse 10 A Motor: 38 W Heating element output: 2,000 W Overheat cut-out: Fan capacity: 184 m³/hour Hanging length:... -
Page 30: Technical Data Easy Dryer 1700 / 1900
TECHNICAL DATA EASY DRYER 1700 / 1900 Capacity: Up to 6.0 kg laundry (cotton) Dewatering capacity: Up to 25 g/min Electrical connection: Single-phase 230 V, 50-60 Hz Fuse 10 A Motor: 38 W Heating element output: 2,000 W Overheat cut-out: Fan capacity: 184 m³/hour... -
Page 31: Troubleshooting
TROUBLESHOOTING EASY DRYER Questions What you can do The drying cabinet is 1. Check that the mains lead is connected to a power not working. socket and that power is supplied. 2. Check that no fuse has tripped. 3. Is the door closed? 4. -
Page 32: Sensor Dryer
TROUBLESHOOTING SENSOR DRYER Questions What you can do The drying cabinet is 1. Check that the mains lead is connected to a power not working. socket and that power is supplied. 2. Check that no fuse has blown 3. Have you pressed the start button? 4. -
Page 33: List Of Error Codes For Sensor Dryer
TROUBLESHOOTING LIST OF ERROR CODES FOR SENSOR DRYER Error code Cause Error 1 Regulator sensor. Error in the sensor at the element. The error is either a discontinuity or short-circuit in the Er 1 sensor. Reset by disconnecting the power supply. Error 2 Outlet sensor. -
Page 34: Dimensional Drawing
DIMENSIONAL DRAWING 1700 / 1900 1700/1900 1474/1674...
