English Display Touchpad - ADT Security Manager 3000 User Manual

AWAY: All burglary zones, interior and
perimeter, are armed.
STAY: Perimeter burglary zones, such as
protected windows and doors, are
armed.
Perimeter burglary zones armed
INSTANT:
and entry delay is turned off.
BYPASS: This appears when one or more burglary protection zones have been
bypassed.
NOT READY: Appears when burglary portion of the system is not ready for arming
(due to open protection zones). The system is ready to arm when this
message disappears and the READY indicator light comes on.
NO AC: Appears when AC power has been cut off. System is operating on
backup battery power.
AC: Appears when AC power is present.
Appears when the CHIME feature is activated.
CHIME:
Low battery condition in a wireless sensor (if zone number displayed)
BAT:
or low system battery (if no zone number displayed).
Appears when an intrusion has been detected and the system is armed
ALARM:
(also appears during a fire alarm or audible emergency alarm).
Accompanied by the protection zone in alarm.
CHECK: Appears when a malfunction is discovered in the system at any time or
if an open is detected in a FIRE zone at any time or a fault in a
DAY/NIGHT burglary zone during a disarmed period. Accompanied by
a display of zone number in trouble.
Appears when a fire alarm is present. Accompanied by a display of the
FIRE:
zone in alarm.
A FIRE display, accompanied by a display of zone 95, also appears
when a fire alarm is manually activated.
AWAY
BYPASS
NOT READY
STAY
ALARM
CHIME BAT
FIRE
CHECK INSTANT

ENGLISH DISPLAY TOUCHPAD

NO AC
TEST
– 9 –
