8. Console Rear inputs
USB
#5
Micro
8-Pin
#7
#6
6
USB
Figure 8: Rear of console Inputs
Before powering on the Mark 7 Units please make the following connections:
Micro-USB: Tablet to Console USB data communication cable
USB: Motor to Console USB data communication cable
8-Pin: Motor to console signal cable
Port #7. Digital Powder Measure (optional)
Port #6. Remote Stop (optional)
Port #5. DecapSense (optional)
14
Mark 7® Reloading EVOLUTION User Manual version 1.1, Copyright 2018 All rights
reserved
