1. Removal of Main Autodrive assembly from the packing carton
Upon removal carefully inspect contents for damage. Damage that occurs during shipment should be
reported immediately to the carrier. Major system components listed below.
Electronics
Console
Base Plate
MARK 7® RELOADING EVOLUTION USER MANUAL VERSION 1.1, COPYRIGHT 2018
Motor
Figure 1: Major Component Overview
Gear Box
Motor Mount
Belt Tensioning
shoulder Bolt
Rubber Feet
(4 Corners)
ALL RIGHTS RESERVED
Drive
Sprocket
7
