Mark 7® 1050 Autodrive User Manual
Read this manual and the Dillon Precision Manual completely. Understand all safety and
operating instructions. Failure to comply with the warnings and instructions may result in
serious injury, illness or death.
MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS
1
RESERVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mark 7 1050

  • Page 1 Read this manual and the Dillon Precision Manual completely. Understand all safety and operating instructions. Failure to comply with the warnings and instructions may result in serious injury, illness or death. MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 2: Table Of Contents

    Box Contents.................................. 6 Set-Up Procedures ................................. 7 1. Removal of equipment from the packing carton ....................8 2. Determine mounting holes for either Super 1050 or RL 1050 ................9 3. Mounting large sprocket ............................. 10 4. Belt installation ..............................11 5.
  • Page 3: Important Safety Instructions

    WARNING – Activities using the Mark 7 1050 Autodrive are inherently dangerous and may lead to injury and even death. Actions as a result of using the Mark 7 product are solely the responsibility of the user – if you get injured through the reloading process or through the use of ammunition as a result of the reloading process it is your fault.
  • Page 4 Mark 7 Autodrive. WARNING - Mark 7 provides you with a tablet mount. Never operate the Mark 7 Autodrive without the tablet securely fastened in the tablet mount and fixed to the case feeder post. The operator must be in a position to operate the tablet while observing all critical operations of the press.
  • Page 5 Manually manipulate the press to fix the impacted areas, clear the press, and start the loading process again while discarding the affected rounds. MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 6: Box Contents

     Low Primer Assembly (1X) Top Insert: (5 items)  Tablet (1X)  Belt (1X)  Mark7 Belt keeper (1X)  Belt guard (1X)  Setup instructions (1X) Mark 7 Reloading User Manual version 7.6, Copyright 2015 All rights reserved...
  • Page 7: Set-Up Procedures

    The Mark 7 Autodrive is manufactured with superior craftsmanship and quality that is backed by a factory warranty. WARNING Only use Mark 7 accessories with the Mark 7 Autodrive. Mark 7 equipment is prepared and tested by Mark 7 prior to delivery. To place the equipment into service, please review the following instructions carefully.
  • Page 8: Removal Of Equipment From The Packing Carton

    1. Removal of equipment from the packing carton Upon removal carefully inspect contents for damage. Damage that occurs during shipment should be reported immediately to the carrier. Top view of the Mark 7 Autodrive assembly as it comes out of the box Major components: 1. Baseplate 5.
  • Page 9: Determine Mounting Holes For Either Super 1050 Or Rl 1050

    Depending on whether you have a Super 1050 or an RL 1050 there are specific mounting holes for each. You can see in the picture above the two sets of four holes each. When mounting either 1050 to the baseplate, thread all four bolts into the baseplate before final tightening. Torque the ¼-20 screws to 10- 12 ft lbs (14-16 Nm).
  • Page 10: Mounting Large Sprocket

    There are two sets holes in the sprocket; one set for the super and one set for the RL. Make sure the press in in the UP position. Remove the lever and slide the large sprocket onto the 1050 input shaft. Position the sprocket so the labels are upright. Next insert the link bar and rotate the sprocket so the correct pair of holes lines up with the link bar.
  • Page 11: Belt Installation

    Place belt over small sprocket making sure motor mount is all the way forward. Loop belt under bottom section of large sprocket and rotate the large sprocket clockwise to properly seat the belt. MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 12: Belt Tensioning

    5. Belt tensioning Using the 1050 lever that you removed from your machine, tension the belt by prying against the tensioning bolt and front of motor mount as shown in the illustration. A properly tensioned belt can only be moved about 1 cm. Tighten the two motor mount cap screws to maintain the tension. Torque them to 12-15 ft lb (16-20 Nm).
  • Page 13: Belt Guard Installation

    The washers should rest against the inner surface of the guard into the baseplate. Tightening the screws is best done using a 5/32” ball end Allen wrench. Do not over-tighten. WARNING Never operate the machine without the belt guard installed properly. MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 14: Removing The Ratchet System On The 1050

    7. Removing the ratchet system on the 1050 The Mark 7 Autodrive works best if the ratcheting system on the Dillon is removed – but that is a decision best made by the user. WARNING If you remove the ratcheting system please be very careful to not over or under index the machine –...
  • Page 15: Tablet Holder Install

    The tablet holder is a two piece design and the bracket holding the tablet can slide laterally from the ball join – this is by design. If the tablet holder becomes loose at this point, slide the tablet holder back into position at the ball joint. WARNING MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 16: Tablet Cable Outlet Installation

    Locate and the insert power cable into the tablet’s power jack located directly below the Micro-USB. Insert Micro-USB into the input located directly above the power jack. The Micro-USB provided with the machine may be different from the picture above. Mark 7 Reloading User Manual version 7.6, Copyright 2015 All rights reserved...
  • Page 17: Console Inputs

    3. Eight pin Molex connector from the motor to the eight pin input to the right of the USB input on the console. 4. Four pin Molex connector from the motor to the bottom on the console, to the right of the power connection MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 18: Power Connection Input

    Never power on the console switch without the 4-pin molex connector plugged in and never install this connector with the power already on since the DC voltage would damage the motor's input contacts. Mark 7 Reloading User Manual version 7.6, Copyright 2015 All rights reserved...
  • Page 19: Low Primer Sensor Install

    New style primer alarm mount Old style primer alarm mount Upon checkout for your purchase of the Mark 7 Autodrive you would have been asked the style of primer alarms you have with your existing 1050. We supply the appropriate mounts based on this answer.
  • Page 20: For Double Alpha Or Kiss Bullet Feeder Users

    13. For Double Alpha or KISS bullet feeder users There is an external capacitor included with your Mark 7 autodrive. Ensure that this is attached to the bullet dropper assembly between that assembly and the cables to the bullet feeder to ensure error-free operation.
  • Page 21: Operating Instructions

    Contact with the drive belt or sprockets could result in serious injury or death. Waiver Screen Following proper installation of the Mark 7 Autodrive the user will be able to power up their tablet and launch the Mark 7 Autodrive application. The picture below is the first screen the operator will see. The operator must accept the terms and conditions and waiver on the Mark 7 Reloading website.
  • Page 22: Before Each Session Of Use Of The Machine

    Control Screen The control screen is the first screen the operator will see once they accept the waiver. Mark 7 Reloading User Manual version 7.6, Copyright 2015 All rights reserved...
  • Page 23 JOG UP - The JOG UP function will incrementally move the press upwards. The JOG UP functions is useful in clearing jams that may occur. The JOG UP function will only work when the Mark 7 Autodrive is at a stop.
  • Page 24: Monitors Screen

    SET PRIMER - The operator has the ability to set the number of primers used before the Mark 7 Autodrive ends its current run. SET BRASS - The operator has the ability to set the number of brass used before the Mark 7 Autodrive ends its current run.
  • Page 25: Setup Screen

    3. Turn off the power to the console of the autodrive 4. Turn off the power to the case feeder and the bullet feeder 5. Turn off the power to the tablet MARK 7 RELOADING USER MANUAL VERSION 7.6, COPYRIGHT 2015 ALL RIGHTS RESERVED...
  • Page 26: Reloading Manual

    Calibration WARNING Calibration can only be done when the Mark 7 Autodrive is empty with no casings in the shell plate. Only after calibration is complete you may start reloading ammunition Test Rounds Once calibration is completed, and you have loaded the shell plate with brass you must take the first round produced and remove it.
  • Page 27: Digital Clutch Setting

    WARNING The digital clutch setting will have an effecting change at higher production rates of the Mark 7 Autodrive. For example, loading .40 S&W at 1200 rounds per hour with the digital clutch setting of 2, you may be able to reduce the digital clutch setting to 1. You should always have the digital clutch setting at the appropriate level for you desired production rate.
  • Page 28: Jams

    2. Hard jam. If the jog buttons do not move the shell plate than the Mark 7 Autodrive needs to be powered down. Once powered down cut the power and when you are sure that the power is cut to the Mark 7 Autodrive you may attempt to manually clear the jam.
  • Page 29: Settings

    If you experience a jam or any type of activity that requires you to turn off the Mark 7 Autodrive at the console, you may decide or be required to calibrate the Mark 7 Autodrive again. Always repeat the process of ensuring that the measurements on your brass or ammunition are that same that they were in your previous calibration –...
  • Page 30: Communications Errors

    If you continue to have Communications Errors please contact us for technical support. Troubleshooting Refer to the knowledge base section on our website for troubleshooting articles relating to setup and operation. http://www.markvii-loading.net/ Please contact us for technical support. (617) 545-4890 Mark 7 Reloading User Manual version 7.6, Copyright 2015 All rights reserved...
