2. Mounting Evolution to Baseplate
TM
Remove the Handle from the Evolution
and place the Press on front of the Autodrive baseplate in the
orientation shown below. Using the 4X 3/8-24 by 1.75" Socket Cap Screws secure the press to the
baseplate. Be mindful not to drag the bottom of the press against the baseplate.
Mounting
Hardware (QTY 4)
Leave Shaft
Adapter Installed
Figure 2 : Mounting to Baseplate
8
Mark 7® Reloading EVOLUTION User Manual version 1.1, Copyright 2018 All rights
reserved
