Summary of Product Parts

No. Element
Fieldbus interface connector
1
(BUS)
Socket for the power supply
2
(PWR(V))
Socket for the power supply
3
(PWR)
4 FG terminal
5 Display
6 Switch setting part

■Definition and terminology

Term
N
Node number
Number of stations
O
Occupied node number
R
Remote I/O
S Slave station
Communication connector for CC-Link (1 pc.)
The connector for CC-Link (
The connector for the power supply (
the solenoid valves.
The connector for the power supply in accessories (
the power for the SI unit.
Functional Earth.
LED diagnostic display.
Set the number of the host stations and the communication speed.
0 is assigned to the master station of the CC-Link network. 1 to 64 are assigned
to slave stations. It is necessary to assign node numbers to slave stations
taking into consideration the number of occupied stations, so that node
numbers are not duplicated.
The total number of occupied slave stations connected to the CC-Link network
Station number that one slave station uses on the network. It can be set from 1
to 4 stations depending on the amount of data.
Station for which only bit data can be used. Occupies only one station.
(Example: Digital unit, solenoid valve, sensor, etc.)
Collective description of stations other than the master station.
-8-
EX180-SMJ3/5
(EX180-CMJ1)
Power supply connector (2 pcs.)
(EX180-CP1)
Accessories
Description
) that is used to connect to the CC-Link bus line.
) that is used to supply the power for
Explaination
EX180-SMJ3A/5A
(EX180-CMJ2)
) that is used to supply
