Notes:
a) If n ports are used to
load, the number of cabinets
loaded by the first (n-1)
ports must be:
1. the same,
2. the integer multiple of the
number of rows/columns,
3. no less than the cabinets
loaded by the nth port.
b) If there are irregular cabinets, cabinets with different sizes or irregular screens, it is
required to connect NovaLCT-Mars for screen configuration.
c) During data flow settings, you can view the results of different data flow presets on
LED display by rotating the knob. When you are satisfied with the LED display picture,
press the knob to save the settings. Directly press BACK button to exit from current
operation and the previewed data flow won't be saved.
d) During data flow settings, you must make sure the physical connection of each port
is along the same direction and down to next one.
e) During data flow settings, you must make sure the start position of port 1 is the
start of whole physical connection.

Step 4 Brightness Adjustment

Back to the main menu and press the knob. Select the corresponding value in
Brightness menu. Rotate the knob to adjust brightness now.
MC TRL 4 K Us e r ' s M a n u a l
Example:
If Ethernet port 1~7 are used to load, the number of
cabinets loaded by port 1~6 must be the same and
the integer multiple of the number of rows/columns.
Therefore, it is needed to set the number of cabinets
loaded by port 1 according to the actual situation
during quick config. The number of cabinets loaded by
port 7≤ the number of cabinets loaded by port 1.
In multi-card mode, the corresponding output ports
are 9~16 if DVI 2 is used as input. Now port 9 is
considered as the first port. So it is required to set
the number of cabinets loaded by port 9.
Main
Brightness
Input Settings
Screen Settings
Display Control
Advanced Settings
Communication Settings
Language
