2.Connect the outside antenna to the
"OUTSIDE" port of booster.
4.Connect the other end of the coax cable to splitter at the "INPUT" port, and two inside
antennas' cables connect to the other side port.
5.Connect the other end of the coax
cables to the panel antennas.
3.Connect the 15 ft RG6 cable to the
booster at the "INSIDE" port.
6.Plug in the power adaptor and connect it
to the nearest power outlet (surge
protector recommended).
The logo will be
illuminated
after the power
is turned on.
12
