SolidRF Building Force Pro5 MANT User Manual

2g/3g/4g and 4g lte
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SolidRF BuildingForce
Pro5 MANT for
2G/3G/4G and 4G LTE
If you have any questions or concerns when
installing or operating your cell phone booster,
please email us:
Support@SolidRF.ca
Please provide the invoice of your product in
your email. Or visit www.SolidRF.ca for more
information.
Systems tested and certified against FCC
standard, Equipment Class: Part 20 Wideband
Consumer Booster (CMRS)
Systems tested and certified against IC standard,
Type of Equipment: Amplifier, RSS-131
IC
Manufactured and Warranted by
SolidRF Technology Inc. Canada
www.SolidRF.ca
Product Diagram
Package Contents
Features
Test Installation
Installation – Step By Step
Technical Specification
Self Oscillation
Quick Troubleshooting
Find Strongest Signal

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Building Force Pro5 MANT and is the answer not in the manual?

Questions and answers

Related Manuals for SolidRF Building Force Pro5 MANT

Summary of Contents for SolidRF Building Force Pro5 MANT

  • Page 1 Features Support@SolidRF.ca Test Installation Please provide the invoice of your product in your email. Or visit www.SolidRF.ca for more Installation – Step By Step information. Technical Specification Systems tested and certified against FCC standard, Equipment Class: Part 20 Wideband...

  • Page 2: Product Diagram

    Product Diagram Warning Lights INDOOR UNIT OUTDOOR UNIT Cable Connector Cable Connector Package Contents • Outdoor Unit • Indoor Unit • LM240 Cables: 1 x 45 feet • Power Adapter Indoor Unit Outdoor Unit LM240 Cable Power Adapter Features • Greatly reduces dropped calls, extends signal range, and increases data rates •...

  • Page 3: Test Installation

    Find a cell tower nearby! There are a bunch of resource online, here are some third party websites and app recommended. SolidRF does NOT guarantee the accuracy or completeness on Third Party content For Canada website: www.cellmapper.net app: TowerLocator(iPhone or Android) For U.S.
  • Page 4 Step3: Introduce cables into room Attention: Don’t excessive bending of the cable, otherwise it will be damaged and loss functions. Step4: Setup booster 1. Connect cable to outside connecter, make sure pin of the cable head smooth import connecter’s socket, and then screw well till the end;...
  • Page 5 The Formal Installation OUTDOOR Unit INSTALLATION a. Choose right position: 30 cm away from any other metallic objects, and 100 cm away from any windows b. Mount the antenna as the picture shows c. Connect the cable to the outdoor antenna •...

  • Page 6: Recommended Installation Position

    Recommended Installation Position ARRANGE BOOSTER a. Choose right position • Be sure to be far from any heat source • In a ventilated dry place, temperature range should be from - 25 ℃ to +50 ℃ b. Mount the booster as the picture shows Technical Specification Cellular...
  • Page 7 ATTENTION: Self Oscillation We strongly recommend it must achieve the Minimum Required Separation Distance for the installation. The improper installation could result in possible Self Oscillation. Minimum Required Separation Distance (MRSD)：6 meters (20 ft ) distance and 4 meters ( 13 ft ) vertical height distance.

  • Page 8: Quick Troubleshooting

    20 ℃ to +50 ℃. Too high or low temperatures beyond this range will cause the booster to lower output power to avoid damage. If you can not fix the problem, please contact the technical support or the reseller. SolidRF Technical Support: Support@SolidRF.ca Find Strongest Signal Use Cell Phone Only: •...

  • Page 9: Warnings And Recommendations

    Warning: It will damage the mobile device and the booster if connect them with a cable directly. Warning: Use the power supply provided by SolidRF only. Other power supplies may cause damage of the booster. Warning: Antenna installation is restricted to 10 meters or less height above ground, even if the antenna is installed inside when used with a mobile device that operates in the 1710-1755 MHz band.
  • Page 10 Description of network protection features: This booster including safeguards to protect the cellular network from interference. Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory reprogramming or disabling the hardware. The Signal Booster will amplify, but ONLY incoming and outgoing signals in order to increase coverage of authorized frequency bands.
