Black Corner TV Stand with Dark Walnut Shelves
Instruction Manual
SKU: STAND-TV75BH
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv75bh
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV75BH
Summary of Contents for Vivo STAND-TV75BH
- Page 1 Black Corner TV Stand with Dark Walnut Shelves Instruction Manual SKU: STAND-TV75BH Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv75bh GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED TIPOVER WARNING SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER: • NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF TV OR STAND. Phillips • USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL Screwdriver USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER. - Page 4 STEP 3 Install Shelf Clips (M) to underside of Large Shelf (E) at a 45° angle facing inward, using M6x12mm Screws (S-C) and 4mm Allen Wrench (T-B). Insert Shelf Spacers (N) into the ends of Large Shelf (E). INSTALL AT 45° ANGLE Snap shelf assembly to the raised curves of assembled base as shown below.
- Page 5 STEP 4 Assemble Left Shelf Bracket (K) and Right Shelf Bracket (L) to Small Shelf (F) using M6x12mm Screws (S-C) and 4mm Allen Wrench (T-B). NOTE: Do not overtighten screws. Insert two M6x12mm Screws (S-C) into the bottom inner holes on the frame assembly as show below, using 4mm Allen Wrench (T-B), making sure to leave 5mm of threads exposed.
- Page 6 STEP 5 Assemble Left VESA Bracket (H) and Right VESA Bracket (I) to back of TV using appropriate Screws (M-A thru M-D), M8 Washers (M-E), Spacers (M-F, M-G) and a Phllips screwdriver. STEP 6 Place Bubble Level (T-A) on VESA Plate (G). Assemble VESA Plate (G) to Upper Support (C) in one of two postions as shown below using M8x55mm Screws (S-B), M8 Washers (S-D), M8 Nuts (S-E) and M8 Screw Caps (S-F).
- Page 7 STEP 7 Loosen the safety screws on Left VESA Bracket (H) and Right VESA Bracket (I) with a Phillips screwdriver, then place onto VESA Plate (G), as shown below. Retighten safety screws with a Phillips screwdriver once in place. STEP 8 Secure Cable Clips (J) to the frame assembly and manage cables.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
