Easel Studio TV Stand
STAND-TV65AB Series
Assembly Manual
Individual Product SKUs
STAND-TV65A STAND-TV65AB STAND-TV65AW

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-TV65A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-TV65A

  • Page 1 Easel Studio TV Stand STAND-TV65AB Series Assembly Manual Individual Product SKUs STAND-TV65A STAND-TV65AB STAND-TV65AW...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
  • Page 3 Package Contents A (x2) B (x1) C (x1) D (x1) Side Leg Center Leg Lower VESA Upper VESA Bracket Bracket E (x1) F (x2) G (x1) H (x2) Pole Cable Clip Steel Cable Security Clip Clamp Included Hardware & Tools S-A (x2) M-A (x4) M-B (x4)
  • Page 4: Assembly Steps

    Assembly Steps STEP 1 Screw Legs (A,B) into base of Pole (E).
  • Page 5 STEP 2 Adjust collar height using 4mm Allen Wrench (T-A), then secure it in place.
  • Page 6 STEP 3 Remove Screw (C1) from center clamp on lower VESA Bracket (C). Open the clamp.
  • Page 7 STEP 4 Position the Upper Bracket (D) over the top holes on the TV and secure it with the appropriate Screws (M-A through M-D), Security Clips (M-H), M8 Washers (M-E), and Spacers (M-F, M-G) if needed, using a Phillips screwdriver. Attach the Lower Bracket (C) the same way, but without Security Clips.
  • Page 8 STEP 5 Grab a friend and slide the TV with VESA Brackets (C,D) onto Pole (E). 2 Person Mounting Recommended Close the clamp on the Lower VESA Bracket around the pole, then secure it with Screw (C1).
  • Page 9 STEP 6 Peel the backing from the Cable Clips (F) and attach them to the rear leg for cable organization. OPTIONAL: Securing Cable Clips Secure the Cable Clips using ST4.2x12 Screws (S-A), which can thread directly into wood without the need for pilot holes.
  • Page 10 STEP 7 - Option 1 - Wood Stud Anchoring For Concrete/Brick Mounting, go to Page 11 Locate two adjacent studs using a stud finder and level. Position the Security Cable Clamps (H) and mark the drilling points. Drill mounting holes at marked locations using the infographic below. Drill Bit: 1/8”...
  • Page 11 - Option 2 - Concrete / Brick Anchoring Position the Security Cable Clamps (H) on the wall and mark the drilling points. Drill mounting holes at marked locations using the infographic below. Drill Bit: 9/32” (7mm) Hole Depth: 1.6” (40mm) Insert Anchors (W-B) into the holes and secure the Cable Clamps (H) with ST4.8x38 Screws (W-A).
  • Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...

This manual is also suitable for:

Stand-tv65abStand-tv65aw
