Wood Easel Studio TV Stand with RGB Light
Instruction Manual
SKU: STAND-TV70D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv70d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-TV70D
Summary of Contents for Vivo STAND-TV70D
- Page 1 Wood Easel Studio TV Stand with RGB Light Instruction Manual SKU: STAND-TV70D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv70d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
I (x1) H (x1) F(x6) G (x6) Power Cord Remote 4mm Allen ST4.2x12 Cable Clip Wrench Screw *ONLY USED ON STAND-TV70D P-E (x4) P-C (x2) P-D (x1) P-B (x2) P-A (x1) ST4.8x38 Screw Security Cable 2mm Allen Security Security Clamp... -
Page 3: Assembly Steps
DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting hardware for brick and concrete walls. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. ASSEMBLY STEPS STEP 1 Screw the legs (B) into the base (A). - Page 4 STEP 3 Remove the screws from the lower VESA bracket (E) and open the clamps. STEP 4 OPTION A: Flat Back TV Position VESA brackets horizontally on the back of the TV, making sure upper VESA bracket (D) is on top and lower VESA bracket (E) is below. Secure using screws (M-A or M-B) with square washers (M-F) and D5 Washers (P-G), with security clips (P-B) installed to top holes.
- Page 5 Peel backing from the cable clips (G) and install clips on the rear legs. For STAND-TV70D, secure clips by threading ST4.2x12 screws directly into the wood legs. Use clips to organize cables.
- Page 6 STEP 6 (Continued) To connect to an external RGB controller, remove the screw on the underside of the base (A) holding the left side cover, then remove the cover. Remove the security tape from the RGB connector, then disconnect and pull out the cable. Connect the cable to the external RGB controller.
- Page 7 STEP 7 (Continued) OPTION B: Concrete/Brick Wall Using Security Cable Clamps (P-C) as guides, mark drilling locations on wall at the same height as the upper VESA bracket, spaced 400mm - 650mm (16” - 26”) apart. Drill holes at least 1.6” (40mm) deep using a 9/32” (7mm) drill bit. Insert concrete anchors (P-F) into holes and mount clamps to wall using ST4.8x38 screws (P-E).
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! AVG. RESOLUTION TIME : 5M 4S 309-278-5303 (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
