Camera

Camera Specifications

MX Sensor

SENSOR
PIXEL ARRAY
DYNAMIC RANGE
MAX IMAGE AREA
LENS COVERAGE
MAX DEPTH OF FIELD
ACQUISITION FORMATS
PROJECT FRAME RATES

I/O ports:

DSMC Side Handle

SSD Module and Cards:

The side mount SSD module is technically removable, but we record only to SSD cards so it is
14 MEGAPIXEL MYSTERIUM-X™
5120 (h) x 2700 (v)
13.5 stops, up to 18 stops with HDRx™ 6 fps with
5K FF and HDRx On 15 fps with 4K HD and
HDRx™ On
5120 (h) x 2700 (v)
27.7mm (h) x 14.6mm (v) = 31.4 mm (d)
Equivalent to S35mm (Motion) / APS-H (Still)
lenses
5K FF REDCODE RAW (Full Frame)
4K HD REDCODE RAW
3K HD REDCODE RAW
1080p REDCODE RAW
1K REDCODE RAW
23.98, 24, 25, 29.97, 47.96, 48, 50, 59.97
Front
2 x balanced 1/8" jacks
EVF/LCD
Rear
SDI
HDMI
Sync (Genlock/Timecode/Word Clock)
Power
The side handle is a removable item which expands the user interface and gives extra battery
options. It has a LCD display, navigation wheel, record start/stop, and user programmable
buttons (8 total).
1 Redvolt battery can be mounted inside the handle. Redvolts last for about 25 minutes.
The handle screws into the Scarlet body and may be removed and replaced with a flat body
panel.
