5. Repeat steps 1 to 4 until you find the maximum
corridor width.
IMPORTANT INFORMATION
When Test IN (3-2-4) is used, the house icon
on the display will come on and the mower
will remain in the charging station. Press the
Home button to return to operations.
The adjacent picture shows how an Automower
negotiates a passage when a value of 5 is set for the
Corridor width, but not when a value of 6 is set.
The Test IN (3-2-4) function differs compared to using
the Home button to send Automower to the charging
station. When the Home button is pressed down, the
mower starts to search for the charging station
according to the defined settings. Depending on the
set delay for the boundary wire and the guide wires, it
will take a specific time before the mower starts to
follow the boundary wire or a guide wire in to the
charging station. Test IN (3-2-4) is a test function that
disregards the delay times. When the function is
selected the mower will immediately start to follow the
boundary wire or the guide wire in to the charging
station.
3.4.2 Test OUT (3-2-5)
The Test OUT (3-2-5) function is used to try different
charge exit settings and to find out how far it is from
the charging station to a remote area.
To test the settings for Follow loop out (3-2-1):
1. State the value 100 % for Proportion for the
remote area to be tested.
2. Place Automower in the charging station and
select Test OUT (3-2-5).
The mower will now leave the charging station
directly according to the stated direction and start
mowing after the stated distance.
3. Reset the Proportion value when testing is
finished.
To find out the distance from the charging station to a
remote area:
1. State a distance that easily exceeds the true
distance. The maximum distance that can be
stated is 500 metres (1600 ft).
2. State the value 100 % for Proportion for the area
to which the distance is to be measured.
50 - English
3. INSTALLATION
Follow loop out
Follow loop in
Corridor width
Test IN
Test OUT
3-2-4
3012-672
