"K" Constant
(Car Transmission Ratio)
The "K Constant" is the number of pulses per Kilometer emitted by a transducer and received by a taximeter.
The pulses can be emitted by the car's electronic transducer or, if the car is not provide of it, by the Digitax
mechanical one. This constant can be knowed or be tested on road.
Follow this procedure to find out the car tansmission ratio (K‐constant).
For a right procedure it must be done in a road with a carefully marked distance of 1 Kilometer(default).

Align carefully the car's front wheels with the test distance's start line


Autotest Finishing Point


Select  For Hire position.
Press K2 and K3 buttons  at the same time.
The fare  display  shows "Attest" for a few seconds and then the
"For Hire ‐ Stopped ‐ Hired" signs  light on together.

Now  start  driving  the    test  distance  (1  kilometer)  at  30  Km/Hour
maximum.

Reach the finish line, previously marked, and stop the car:
the  extras  display  will  show  the  number  of  pulses  emitted  during  the
test‐distance run.

Keep  note  of  this  value.  The  aim  of  it  is  to  calibrate  the  taximeter  to
calculate the K‐constant.

Press OP button to end the procedure and go back to  For Hire position.
Take out the taximeter programming cover
Select  For Hire position.
Insert the Black Programming Key in its  slot.
Press K2 and K3 buttons  at the same time.
The big display  shows "Attest" for a few seconds.

The  "For Hire ‐ Stopped ‐ Hired" signs light on together.
The fare display shows  the programmed  K‐Constant value.
The extras  display shows  the  meters to be covered  for the Autotest

Press  K2 button to increase the pulses/km number.




Press  K1 button to decrease the pulses/km number.


Referring  to the above example, press K1 button till to reach 680 value
( pulses finded out in the autotest) showed in the fare display.


Press OP button to end the procedure and go back to  For Hire position.
Take out the Black Programming Key from the taximeter.
12
The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
K Constant = Pulses/Kilometer
How to find out the K‐Constant value (Autotest)
1 Kilometer at Max 30 Km/Hour.

How to insert the K‐Constant  value
Follow this procedure to calibrate the taximeter with a know K‐Constant value.


Autotest Starting Point

party is strictly prohibited.

Meters
