AX92324 2-port 10GbE PoE PCI Express Card
2.1.2

4-pin Molex Male connector (ATX2)

The power connector is used for PoE function when total power of powered device is
over 20 watts.
Pin
1
2
3
4
2.1.3 RJ-45 Connector (LAN1 & 2)
Pin
J1
J2
J3
J4
J5
J6
J7
J8
Left LED
Right LED
6
Signal
+12V
GND
GND
NC
Description
MDI0+
MDI0-
MDI1+
MDI2+
MDI2-
MDI1-
MDI3+
MDI3-
Speed LED：
10G (Green)
1G (Orange)
100M (No light)
Active LED (Green)
Connectors
