Notes:
The maximum current for each terminal is 36 Amps RMS for 6kVA, 65 Amps RMS for 8
•
to 10kVA.
For 120Vac output only application, output terminal N22 must use AWG #8 wire
•
connected to ground. (Neutral Bonding)
AC Input / Output Current and Wire Recommendation
Model
6KVA
8KVA
10KVA
FN2 Series OM480053 Rev.: C
Maximum
Current
Input: Use #8 AWG, 90°C copper wire, TRQ: 12 IN LB
36 A
Output: Use #8 AWG, 75°C copper wire, TRQ: 12 IN LB
Input: Use #6 AWG, 90°C copper wire, TRQ: 18 IN LB
52A (Input)
40A Output: Use #8 AWG, 90°C copper wire, TRQ: 10 IN LB
(Output)
Input: Use #4 AWG, 90°C copper wire, TRQ: 18 IN LB
62A (Input)
50A (Output) Output: Use #6 AWG, 90°C copper wire, TRQ: 10 IN LB
Conductor Selection
