Gree KW09HQ3D6D Series Service Manual page 21

09/12K
● Top view
1
1 Interface of reactor
Interface of electronic
2
expansion valver
3 Interface of fan
4 Live wire of 4-way valve 8
Bottom view
18
2 3
16
Neutral wire of electric
5
heater for compressor
Neutral wire of electric
6
heater for chassis
Neutral wire of 4-way
7
valve
Live wire of electric
heater
4 5 6
15 14 13
9 Earthing wire
Power supply neutral
10
wire
11 Power supply live wire
Communication wire with
12
indoor and outdoor unit
Service Manual
7 8
High pressure protection
13
terminal HPP
14 Temp. sensor
15 Input of overload
U,V,W three phases of
16
compressor
Technical Information
9
10
11
12
