- Page 1 June 17, 2020 Ver1.00 DIGITAL VIDEO OUTPUT CAMERA ARTCAM-185IMX-HD3 INSTRUCTION BOOKLET 2.3M Pixels ARTCAM-185IMX-HD3 ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
CONTENTS 1. Attention ··········································· 3 2. Introduction ······································· 6 3. Main Features ··································· 6 4. The Product ······································ 6 5. Connect the Monitors/TVs··················· 7 6. Specifications ···································· 8 7. External Dimensions ·························· 11 8. Spectral Sensitivity Characteristics········ 12 9. Button Control Operation····················· 13 - 2 -... -
Page 3: Attention
1. Attention ■ About this Manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4. - Page 4 ■ For Safe Use Warning ● In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
- Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf - 5 -...
-
Page 6: Introduction
Adopting HD-SDI, NTSC, etc. enable direct data transfer to monitor and TV. 3. Main Features ・HD-SDI Output ARTCAM-185IMX-HD3 adopts digital output terminal HD-SDI, so the image can be delivered to digital monitors directly. ・NTSC Output ARTCAM-185IMX-HD3 adopts analog output terminal NTSC, so the image can be delivered to analog monitors directly. -
Page 7: Connect The Monitors/Tvs
5. Connect the Monitors/TVs How to Connect a Camera ・HD-SDI Output ・NTSC Output - 7 -... -
Page 8: Specifications
3.75(H)×3.75(V)μm SHUTTER TYPE Rolling Shutter ARRAY RGB Bayer Array FRAMERATE MAX: 60fps SYNC SYSTEM Internal Sync 6.2 Camera Specification MODEL ARTCAM-185IMX-HD3 LENS MOUNT C-MOUNT POWER SUPPLY DC5V POWER Approx. 2W CONSUMPTION AMBIENT Operating Temperature/Humidity : 0～35°c/10～80%(Non Condensing) CONDITIONS Storage Temperature/Humidity : 0～60°c /10～95%(Non Condensing) EXTERNAL 50.0(W) ×... - Page 9 6.3 Camera Function 6.3.1 Exposure and Gain Control Manual / Auto (Exposure priority / FPS fixed) 6.3.2 White Balance Manual / Auto / One Push Auto 6.3.3 Image Quality Correction Function ・ Lens shading correction ・ Gamma correction ・ Contrast correction ・...
- Page 10 6.3.5 Camera Rear Terminal Information Digital Video Output (Type D) Digital Output Remote Control HD-SDI Receiver Power Supply Analog Output DC5V NTSC/PAL - 10 -...
-
Page 11: External Dimensions
7. External Dimensions 7.1 ARTCAM-185IMX-HD3 - 11 -... -
Page 12: Spectral Sensitivity Characteristics
8. Spectral Sensitivity Characteristics 8.1 ARTCAM-185IMX-HD3 - 12 -... -
Page 13: Button Control Operation
9. Button Control Operation Use remote control to use functions listed in “6.3 Camera Function”. 9.1 Function of Button ① Menu Button Show the menu screen. While in menu screen, press to return. ② Arrow Buttons Move upward/downward/leftward/rightward. ③ Select Button Press to select. - Page 14 ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel : +81-3-3389-5488 Fax : +81-3-3389-5486 Email: sales@artray.us URL: www.artray. us - 14 -...
