- Page 1 Apr. 25, 2015 Ver0.95 USB3.0 CMOS CAMERA ARTCAM-IMX-USB3-T2 Series INSTRUCTION BOOKLET 2.3 M Pixels ARTCAM-174IMX-USB3-T2 Series 6.0 M Pixels ARTCAM-178IMX-USB3-T2 Series ARTRAY CO., LTD.
-
Page 2: Table Of Contents
Contents 1. Attention ··········································· 3 2. Introduction ······································· 6 3. Main Features ··································· 6 4. The Product ······································ 7 5. Connect the Camera ·························· 7 6. Specifications ···································· 8 7. External Dimensions ·························· 10 8. Spectral Sensitivity Characteristics ········ 11 9. -
Page 3: Attention
1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4. - Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
- Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below : Hardware Warranty : http : //www.artray.us/download/artray_warranty.pdf - 5 -...
-
Page 6: Introduction
2. Introduction ARTCAM-IMX-USB3-T2 Series is CMOS cameras designed for industrial use. Adopting USB3.0 enable direct data transfer to PC without a capture board. 3. Main Features ・High Resolution, High Frame Rate We provide high speed CMOS cameras of a wide range of resolutions from 2.3 mega pixels to 6 mega pixels. -
Page 7: The Product
4. The Product 1) Camera 2) USB3.0 Cable A to B connector 3m 3) Introduction Booklet 4) Viewer software/Device Driver CD 5) Software Development Kit [ARTCCM-SDK] <Options> 1) C Mount lens 2) 2 Measurement & Filing Software [ART-MEASURE] 3) Recording Software [ART-REC] 5. -
Page 8: Specifications
6. Specifications 6-1 Color Model ARTCAM-174IMX-USB3-T2 ARTCAM-178IMX-USB3-T2 CMOS Color Image Sensor Sensor Type 1920(H)×1200(V) 3072(H)×2048(V) Active Pixels 11.25(H)×7.03(V)mm 7.43(H)×4.99(V)mm Active Imager 1/1.2 inch 1/1.8 inch Size Progressive Scan Scan Mode 2.4(H)×2.4(V)μm 5.86(H)×5.86(V)μm Pixel Size Global Shutter Rolling Shutter Shutter Type Color Filter Array RGB Bayer Pattern 130fps... - Page 9 6-2 Monochrome Model ARTCAM-174IMX-BW-USB3-T2 CMOS Monochrome Image Sensor Sensor Type 1920(H)×1200(V) Active Pixels 11.25(H)×7.03(V)mm Active Imager 1/1.2 inch Size Progressive Scan Scan Mode 5.86(H)×5.86(V)μm Pixel Size Global Shutter Shutter Type Frame Rate 130fps 1/10000～1/39.37sec Shutter Speed USB3.0 Bulk Transfer Interface Internal Synchronization Synchronization System...
-
Page 10: External Dimensions
7. External Dimensions 7-1 C-MOUNT, CASED CAMERA ARTCAM-174IMX-USB3-T2- ARTCAM-178IMX-USB3-T2- - 10 -... -
Page 11: Spectral Sensitivity Characteristics
8. Spectral sensitivity characteristics ARTCAM-178IMX-USB3-T2 Series - 11 -... - Page 12 ARTCAM-178IMX-USB3-T2 Series - 12 -...
-
Page 13: Recommended Pc
*For the recommended extension cable, please contact our sales department. (TEL : +81-3389-5488) ARTRAY CO., LTD. 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel : +81-3-3389-5488 Fax : +81-3-3389-5486 Email : sales@artray.us URL : www.artray. us - 13 -...
