Block Diagram - Lantronix Open-Q 845 mSOM User Manual

28 Audio Codec Module (on top side of Carrier Board underneath
Display Adapter)
29 Power Header
30 Coin Cell Holder
31 Open-Q 845 µSOM, WLAN/BT CH0 Antenna Connector
32 Open-Q 845 µSOM, WLAN CH1 Antenna Connector
33 Open-Q 845 µSOM
34 On-Board Quiet Thermistor
35 SOM Current Sense Probe Header
36 LEDs: (Charge State / Power / Blue / Green / Red)
37 System Configuration DIP Switch
38 Open-Q LCD Panel
3.4.2

Block Diagram

The block diagram below shows the connectivity and major components of the Open-Q 845 µSOM
Development Kit.
Open-Q 845 µSOM Development Kit User Guide
3: Open-Q 845 µSOM Development Kit
U1700
J700
B300
J2200 (on µSOM)
J2201 (on µSOM)
RT800
J301
DS2503 / DS2504 /
DS2500 / DS2501 /
DS2502
S2600
