Table 1. List of Development Kit Features itemized in the figure above

Position Feature Description
1 DC Power Supply Jack
2 Power Source Selector
3 Battery Input Header
4 Battery Configuration DIP Switch
5 USB 3.1 Type A Connector
6 Mini-PCIe USB Enable DIP Switch
7 Buttons: General Purpose / Power / Volume Up / Volume
Down
8 Audio Headset Jack
9 Haptic Motor Header
10 Audio I/O Header
11 USB 3.1 Type-C connector for ADB
12 USB Serial Debug Console
13 WLAN/BT Channel 0 External Antenna Connector
14 WLAN Channel 1 External Antenna Connector
15 Camera 1 Connector
16 Camera 2 Connector
17 Camera 3 Connector
18 Camera 4 Connector
19 Flash 1 Header
20 Flash 2 Header
21 Sensors Expansion Header
22 Micro SD card socket (on bottom side of Carrier Board)
23 Digital IO Expansion Header
24 Mini-PCIe Card Connector (on bottom side of Carrier Board)
25 SIM Card Socket for Mini-PCIe (on bottom side of Carrier
Board)
26 Audio Outputs Expansion
27 Audio Inputs Expansion
Open-Q 845 µSOM Development Kit User Guide
3: Open-Q 845 µSOM Development Kit
Reference Designator
J400
S300
J300
S301
J2400
S2401
S2501 / S2503 / S2500 /
S2502
J1800
J802
J2000
J2300
J1600
J2701
J2700
J1000
J1100
J1200
J1300
J1001
J1201
J2100
J1500
J2200
J2801
J2800
J1901
J1900
