Parts List - Linear Technology DC1485A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
1 16 C1-C4, C6-C8, C10-C12, C19, C25,
C29, C31, C33, C40
2 2 C5, C20
3 1 C9
4 2 C34, C37
5 6 C13, C18, C30, C36, C39, C41
6 1 C14
7 0 C15, C16
8 0 C21
9 3 C17, C23, C28
10 2 C38, C35
11 3 D1, D2, D5
12 9 E1, E2, E3, E4, E5, E6, E7, E8, E9
13 3 JP1, JP2, JP3
14 2 JP4, JP5
15 1 J1
16 0 J2
17 1 P1
18 2 R1, R2
19 3 R7, R8, R3
20 6 R4, R9, R20, R21, R22, R23
21 1 R5
22 1 R6
23 8 R11, R16, R17, R18, R19, R27, R29,
R30
24 4 R24, R25 ,R26, R31
25 1 R28
26 1 U1
27 1 U2
28 1 U3
29 1 U4
30 1 U5
31 0 U6
32 1 U8
32 4 U9, U10, U11, U12
33 1 U13
34 1 U14
35 1 U15
36 1 U16
37 8 SHUNTS AS SHOWN ON ASSY DWG
38 4 MTG
39 2
DEMO MANUAL DC1485A
PART DESCRIPTION
CAP ., X5R, 0.1μF 25V 20%, 0402
CAP ., NP0, 100pF 50V, 5%,1206
CAP ., X7R, 1μF 25V 10%, 0805
CAP ., X5R, 1μF 25V 20%, 0603
CAP ., X5R, 10μF 25V 20%,1206
CAP ., X7R, 1μF 25V 10%,1206
CAP ., 0603
CAP ., 1206
CAP ., NP0, 100pF 50V, 5%,0402
CAP ., X7R, 0.01μF 25V 20%,0402
DIODE, SCHOTTKY, SOT23
TEST POINT, TURRET, 0.064"
JMP , 2X3, 0.079"
JMP , 1X3, 0.079"
HEADER, 2X7 PIN, 0.079CC
CONN, BNC, RTANG 50Ω
JMP , 2X20, 0.100"
RES., Chip 10k 1/16W 5%, 0603
RES., Chip 1k 1/16W 5%, 0603
RES., Chip 100Ω 1/16W 5%, 0402
RES., Chip 10Ω 1/16W 5%, 0603
RES., Chip 4.02k 1/16W 1%, 0603
RES., Chip 4.99k 1/16W 1%, 0402
RES., Chip 10k 1/16W 5%,0402
RES., Chip 20k 1/16W 5%,0402
I.C., LTC2757CLX, LQFP48LX
I.C., LT1012ACS8, SO8
I.C., LTC2054CS5, SOT23-5
I.C., LTC6240CS5, SOT23-5
I.C., LT1360CS8, SO8
I.C., LTC6655AHMS8-5, MSOP8
I.C., LT1236ACS8-5, SO8
I.C., 74VHC595MTC, TSSOP16
I.C., NC7SZ14P5X, SC70-5
I.C., Serial EEPROM, TSSOP8
I.C., LT1761ES5-5, SOT23-5
I.C., LT1964ES5-5, SOT23-5
SHUNT, 0.079" CENTER
STAND-OFF , NYLON (SNAP ON), 0.50" TALL
STENCILS BOTH SIDES
MANUFACTURE/PART NUMBER
NUMBER OF BOARDS =
TDK, C1005X5R1E104M
AVX, 12065A101JAT2A
TDK, C2012X7R1E105K
TDK, C1608X5R1E105M
TDK, C3216X5R1E106M
AVX, 12063C105KAT2A
OPT
OPT
AVX, 04025A101JAT2A
TDK, C1005X7R1E103M
DIODES INC., BAT54C-7-F
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-D
SAMTEC, TMM-103-02-L-S
MOLEX, 87831-1420
OPT (TYCO ELEC. AMP , 413631-1)
SAMTEC, TSW-120-07-L-D
VISHAY, CRCW060310K0JNEA
VISHAY, CRCW06031K00JNEA
VISHAY, CRCW0402100RJNED
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW06024K02FKED
VISHAY, CRCW04024K99FKED
VISHAY, CRCW040210K0JNED
VISHAY, CRCW040220K0JNED
LINEAR TECH., LTC2757CLX
LINEAR TECH., LT1012ACS8
LINEAR TECH., LTC2054CS5
LINEAR TECH., LTC6240CS5
LINEAR TECH., LT1360CS8
OPT
LINEAR TECH., LT1236ACS8-5
FAIRCHILD SEMI., 74VHC595MTCX
FAIRCHILD SEMI., NC7SZ14P5X
MICROCHIP , 24LC025-I/ST
LINEAR TECH., LT1761ES5-5
LINEAR TECH., LT1964ES5-5
SAMTEC, 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
DC1485A-1
KIT QTY
175
2800
350
175
350
1050
175
0
0
525
350
525
1575
525
350
175
0
175
350
525
1050
175
175
1400
700
175
175
175
175
175
175
0
175
700
175
175
175
175
1400
700
2
