TA1610 FXO VoIP Gateway
TA1610 FXO VoIP Gateway
User Manual
User Manual
Sales Tel:
+86-592-5503309
E-mail:
sales@yeastar.com
Support
Tel:+86-592-5503301
E-mail:
support@yeastar.com
Web:
http://www.yeastar.com
Version: 48.0.0.14
Revised:
September 3, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TA1610 and is the answer not in the manual?

Questions and answers

Related Manuals for Yeastar Technology TA1610

Summary of Contents for Yeastar Technology TA1610

  • Page 1 TA1610 FXO VoIP Gateway User Manual Sales Tel: +86-592-5503309 TA1610 FXO VoIP Gateway E-mail: sales@yeastar.com Support Tel:+86-592-5503301 E-mail: support@yeastar.com Web: http://www.yeastar.com User Manual Version: 48.0.0.14 Revised: September 3, 2020...
  • Page 2 Declaration of Conformity Hereby, Yeastar Information Technology Co., Ltd. declares that TA1610 is in conformity with the essential requirements and other relevant provisions of the CE, FCC. Warranty The information in this document is subject to change without notice.

  • Page 3: Table Of Contents

    TA1610 User Manual Contents About This Guide ....................6 Getting Started ....................7 Accessing Web GUI ......................7 Web Configuration Panel ....................9 Application Description ..................... 9 FXO Port Settings ..................... 13 FXO Port Settings ......................13 Port Group ........................19 VoIP Settings.....................
  • Page 4 TA1610 User Manual DTMF Settings........................ 45 Network Preferences ..................46 LAN Settings ........................46 WAN Settings ......................... 48 Service ........................... 49 VLAN Settings ........................ 50 VPN Settings ........................51 DDNS Settings ....................... 52 Static Route ........................53 Remote Management ..................... 55 Security Center ....................
  • Page 5 TA1610 User Manual Port/Trunk Status ......................77 Network status ........................ 79 System Info ........................79 Reports ......................80 Call Logs ........................80 System Logs........................80 Packet Tool ........................81 Port Monitor Tool......................82 5/82...

  • Page 6: About This Guide

    VoIP. Audience This manual will help you learn how to operate and manage your TA1610 FXO Analog VoIP Gateway. In this guide, we describe every detail on the functionality and configuration of TA1610. We begin by assuming that you are interested in TA1610 and familiar with networking and other IT disciplines.

  • Page 7: Getting Started

    TA1610 User Manual Getting Started In this chapter, we guide you through the basic steps to start with a new TA1610:  Accessing Web GUI  Web Configuration Panel  Application Description Accessing Web GUI The TA1610 attempts to contact a DHCP server in your network to obtain valid network settings (e.g., the IP address, subnet mask, default gateway address and...
  • Page 8 TA1610 User Manual Figure 2-1 TA1610 Login page 8/82...

  • Page 9: Web Configuration Panel

    Three modes are available for you to connect your SIP server and TA1610 gateway. We call them SIP Account Mode, VoIP Mode and SPS (Service Provider SIP) Mode. You can choose any one of the 3 modes to connect your SIP server and TA1610. SPS Mode is recommended.
  • Page 10 TA1610 and receive incoming calls on your SIP phone or softphone. In this way, you don’t have to set up any SIP server. VoIP Mode Take a SIP account from your SIP server, and register it on TA1610 as a VoIP trunk. In this way, TA1610 and your SIP server are connected. 10/82...
  • Page 11 TA1610 User Manual  Calls from SIP to PSTN 1) Configure a IP-> Port route on TA1610; choose the VoIP trunk in the field “Call Source”, and choose PSTN trunk in the field “Call Destination”. Enable Two-stage Dialing on the route.
  • Page 12 TA1610 route. Figure 2-2 Connect IPPBX and TA FXO Gateway For incoming calls from the PSTN to TA1610, TA1610 will forward the call to a configured SIP extension or to an inbound destination of IPPBX like IVR. Connect TA FXO Gateway and FXS Gateway TA FXO gateway can be connected to a FXS gateway using SPS/SPX Mode.

  • Page 13: Fxo Port Settings

    TA1610 User Manual FXO Port Settings This chapter explains how to configure FXO port on TA1610, go to Gateway→ Port List→ Port List page to configure the FXO ports.  FXO Port Settings  Port Group FXO Port Settings Click "Edit" button to configure the FXO port.
  • Page 14 TA1610 User Manual Select the impedance of the analog line connected to the FXO port. Here is the impedance value for the settings: 0 - 600 Ohm ( North American ) 1 - 900 Ohm 2 - 270 Ohm + (750 Ohm || 150nF) and 275 Ohm +...
  • Page 15 Enable Clear Stat. The date to clean the duration status each month. When Max. Call Duration(min) is configured a 0 (no Balance Alarm Settings limit), this feature is disabled. Alarm threshold(min) Cofigure the time duration when TA1610 will send 15/82...
  • Page 16 TA1610 User Manual the alarm message. The value must be less than “Max Call Duration”. Port Choose the port to dial the alarm call. Number The number to receive the alarm call. The prompt played during the alarm call,you can Prompt customize the prompts as your wish.
  • Page 17 Answer Detection settings are configured for accurate billing. Answer Detection Select which type to detect the call as answered. Type 1) Default.TA1610 will start to charge once you grab the PSTN trunk to call out, whether the call is answered or not. 17/82...
  • Page 18 TA1610 starts to bill. 3) Ring back Tone: If you choose this option, TA1610 will charge the call according to PSTN ring back tone detection. When the "ring duration" or the "ring interval duration"...

  • Page 19: Port Group

    TA1610 User Manual Before Ring: start to detect before a ring tone This option defines the type of caller ID signaling to use. Bell-USA: US standard V23-UK: UK standard V23-Japan: Japanese standard Caller ID V23-Japan Pure: Japanese standard Signaling DTMF: DTMF signal Please check with your PSTN service provider to configure Caller ID Settings.
  • Page 20 TA1610 User Manual Figure 3-4 Port Group 20/82...

  • Page 21: Voip Settings

    There are 3 types of trunks listed in this page, Account, Trunk and Service Provider. Figure 4-1 VoIP Trunk 1) Account It’s an SIP account created in TA1610 so that the other devices can register SIP trunk at their side using these information. Figure 4-2 Account...
  • Page 22 Set a password for this account. 2) VoIP Trunk It’s a SIP trunk configured in TA1610 to register to the SIP provider, please make sure this trunk works properly in advance with provider before configuring TA1610. Figure 4-3 VoIP Trunk Settings...
  • Page 23 TA1610 User Manual protocol. Don’t change this part if it is not required. VoIP provider’s server domain name or IP address. Domain User name of SIP account provided from the SIP User Name Server provider. Authorization Name of SIP account provided from Authorization Name the SIP Server provider.

  • Page 24: Trunk Group

    TA1610 User Manual Trunk Group Trunk group is a feature that allows you to define specific SIP trunks to a group. A trunk group can be used in a route. When a call is coming or going through the route, an available trunk would be selected in the trunk group.
  • Page 25 TA1610 User Manual 1) General Figure 4-6 SIP General Settings Table 4-4 Description of SIP General Settings Items Description UDP Port Port used for SIP registrations. The default is 5060. Enable Random Port Enable or Disable Random SIP port. Random Port Update Set the Random Port Update Interval.
  • Page 26 TA1610 User Manual it as tlsv1, sslv2 or sslv3. RTP Port Start Beginning of the RTP port range. RTP Port End End of the RTP port range. Set the default mode for sending DTMF. Default setting: DTMF Mode rfc2833 Maximum duration (in seconds) of a SIP registration.
  • Page 27 TA1610 User Manual 2) NAT Figure 4-7 NAT Settings Table 4-5 Description of SIP NAT Settings Items Description Enable STUN (Simple Traversal of UDP through NATs) is a protocol for assisting STUN devices behind a NAT firewall or router with their packet routing.
  • Page 28 3) Codecs We can choose the allowed codec in TA1610, a codec is a compression or decompression algorithm that used in the transmission of voice packets over a network or the Internet. For more information about codec, you can refer to this page: http://en.wikipedia.org/wiki/List_of_codecs...
  • Page 29 TA1610 User Manual 4) Qos QoS (Quality of Service) is a major issue in VoIP implementations. The issue is how to guarantee that packet traffic for a voice or other media connection will not be delayed or dropped due interference from other lower priority traffic. When the network capacity is insufficient, QoS could provide priority to users by setting the value.
  • Page 30 TA1610 User Manual 6) Advanced Settings Figure 4-11 SIP Advanced Settings Table 4-6 Description of SIP Advanced Settings Items Description Call ID Field Where to get the caller ID in SIP packet. DID Field Where to get the DID in SIP packet.

  • Page 31: Iax Settings

    TA1610 User Manual Enable session-timer mode, default: yes. If you find Session-timers the call is cut off every 15 minutes every time, please disable this. Session-expires The max refresh interval The min refresh interval, which mustn't be shorter Session-minse than 90s.
  • Page 32 TA1610 User Manual Time/Subscription Time Default is 60 seconds Maximum Registration Maximum duration (in seconds) of an IAX2 registration. Time/Subscription Time Default is 1200 seconds. Codecs Enable the codec you want for IAX communication. 32/82...

  • Page 33: Routes Settings

    TA1610 User Manual Routes Settings After connecting Yeastar TA1610 gateway with the VoIP server, you need to configure the routes settings on TA1610 to route the calls through the gateway. In this chapter, we introduce the following sections:  IP->Port ...
  • Page 34 TA1610 User Manual Table 5-1 Description of Simple Mode Route Items Description Route Name Define the route name. Choose the trunk or trunk group for the incoming Call Source calls. Choose the trunk or trunk group to route the incoming Call Destination calls to.
  • Page 35 TA1610 User Manual Table 5-2 Description of Match Incoming Calls Settings Items Description Call Source Choose the trunk or trunk group for the incoming calls. Inbound Caller Pattern Match the prefix of caller ID for incoming calls. Define the expected DID Number if this trunk passes DID on incoming calls.

  • Page 36: Port->Ip/Port

    Port->IP/Port routes are used to control incoming calls to PSTN trunks on TA1610 and route the calls to your SIP server or another PSTN trunk on TA1610. Click “Edit” to check the route details, there are two modes for you.
  • Page 37 TA1610 User Manual 2) Detail Mode Choose “No” for Simple Mode, you will see the detailed configuration page as the following picture shows. Detailed settings for Match Incoming Calls and Handle Matched Incoming Calls are provided in Detailed Mode. Figure 5-4 Detailed Mode Route...

  • Page 38: Blocklist

    TA1610 User Manual Table 5-5 Description of Handle Matched lncoming Calls Settings Items Description Choose the trunk or trunk group to route the incoming calls Call Destination Direct number to the SIP Server. The parameter is ignored Hotline if a SIP Account is selected on this route.

  • Page 39: Callback Settings

    TA1610 User Manual Callback Settings 1) If you’d like to use callback feature, please make sure it’s enabled on the IP->Port or Port->IP/Port route setting panel. 2) No callback rules needed to be set if the trunk supports call back with the caller ID directly.

  • Page 40: Gateway Settings

    TA1610 User Manual Gateway Settings This chapter explains Gateway settings, which can be applied globally to TA1610. The gateway settings can be configured under Gateway→ Gateway Settings.  General Preferences General Preferences Figure 6-1 General Preferences Table 6-1 General Preferences...
  • Page 41 TA1610 User Manual option is enabled. Max length of the jitter buffer in milliseconds. Jitter Buffer MaxSize Default: 40. Voice Activity Detection. In some cases, the echo canceller doesn’t train quickly Echo Tail Length enough and there is echo at the beginning of the call which then quickly fades out.

  • Page 42: Audio Settings

    TA1610 User Manual Audio Settings This chapter explains prompt settings on TA1610.  Custom Prompts Custom Prompts We can upload the prompts in this page; you can also download it and save it as a backup. Figure 7-1 Custom Prompts The administrator can upload prompts by doing the following: 1) Click “Upload Prompt”.
  • Page 43 TA1610 User Manual Note: The file size must not be larger than 1.8 MB, and the file must be WAV format: GSM 6.10 8 kHz, Mono, 1 Kb/s; Alaw/Ulaw 8 kHz, Mono, 1 Kb/s; PCM 8 kHz, Mono, 16 Kb/s.

  • Page 44: Advanced Settings

    TA1610 User Manual Advanced Settings This chapter explains SIP settings and Distinctive Ringtones.  Tone Zone Settings  DTMF Settings Tone Zone Settings Advanced ring tones for all the FXO ports can be configured on this page. There are pre-grogrammed tone zone settings for some countries and regions. Users can simply find and select thier country to get tone zone settings for the gateway.

  • Page 45: Dtmf Settings

    2nd Dial Tone Used for the second stage dial tone. DTMF Settings DTMF signal sent from TA1610 to the receiver can be set on this page. Digit Length and Dial Pause Between Digit: 100.100 (ms) Default Digit Volume: -10,-10 (dB)

  • Page 46: Network Preferences

     VPN Settings  DDNS Settings  Static Route LAN Settings After successfully logging in the TA1610 Web GUI for the first time, users could go System→Network Preferences→LAN Settings to configure the network for TA1610. Figure 9-1 LAN Settings 46/82...
  • Page 47 Set the primary DNS for TA1610. Secondary DNS Set the secondary DNS for TA1610. IP Address2 Set the second IP Address for TA1610. Subnet Mask2 Set the second subnet mask for TA1610. Figure 9-2 DHCP Mode Select DHCP mode to get network automatically from the local network.

  • Page 48: Wan Settings

    TA1610 User Manual WAN Settings WAN port is disabled by default. If you want to use dual network, you should enable WAN port, and configure the network settings and static routes to route network traffic through the proper Ethernet interface.

  • Page 49: Service

    TA1610 User Manual Default Gateway Set the gateway of the public network. Primary DNS Set the primary DNS of the public network. Secondary DNS Set the secondary DNS of the public network. Figure 9-5 DHCP Mode Select DHCP mode to get network automatically from the local network.

  • Page 50: Vlan Settings

    TA1610 User Manual Table 9-3 Description of Service Settings Items Description By using SSH, you can log in to TA1610 and run commands. It's disabled by default. We don't recommend enabling it if not needed. The default port for SSH is 8022.

  • Page 51: Vpn Settings

    The VPN can be used to send any kind of network traffic securely. TA1610 supports OpenVPN. Figure 9-9 VPN Settings 51/82...

  • Page 52: Ddns Settings

    Notes: 1. Uncomment “user” and “group” in the “config” file. You can get the config package from the OpenVPN provider. 2. TA1610 works as VPN client mode only. DDNS Settings DDNS(Dynamic DNS) is a method/protocol/network service that provides the capability for a networked device, such as a router or computer system using the...

  • Page 53: Static Route

    TA1610 User Manual Table 9-4 Description of DDNS Settings Items Description DDNS Server Select the DDNS server you sign up for service. User Name User name the DDNS server provides you. User account’s password. Password Host Name The host name you have got from the DDNS server Note: DDNS allows you to access your network using domain names instead of IP address.
  • Page 54 TA1610 User Manual Figure 9-11 Static Route 1) Route Table The current route rules of TA FXO Gateway. 2) Static Route Rules You can add new static route rules here. Table 9-5 Description of Static Route Settings Items Description Destination The destination network to be accessed to by TA FXO Gateway.

  • Page 55: Remote Management

    TA1610 User Manual Remote Management Yeastar Remote Management provides an affordable, low maintenance solution to easily deploy Yeastar VoIP PBX and TA VoIP gateways across multiple locations, reducing complexity and providing deep visibility and control. Figure 9-12 Remote Management Yeastar Remote Management Quick Start Add TA gateway to Yeastar Remote Management as follows.
  • Page 56 TA1610 User Manual Click “Save”, the TA gateway will be added to Remote Management. “Connected” displays if the device is added successfully.  Connect to Remote Management by Authentication Code If you cannot access the TA gateway, you can add the TA gateway to Yeastar Remote Management by authentication code.

  • Page 57: Security Center

    TA1610 User Manual Security Center This chapter describes how to secure your TA1610. It is strongly recommended that users configure firewall and other security options on TA1610 to prevent the attack fraud and the system failure or calls loss. ...

  • Page 58: Alert Settings

    TA1610 User Manual 2) Service In “Service” tab, you can check AMI/SSH status. For AMI/SSH, you can enter the according page by clicking the button in “Setting” column. Figure 10-2 Security Center—Service 3) Port In “Port” tab, you can check SIP port and HTTP port. You can also enter the relevant page by clicking the button in “Setting”...
  • Page 59 TA1610 User Manual  WEBLOGIN Web Login Alert Notification: entering the wrong password consecutively for five times when logging in TA FXO Gateway Web interface will be deemed as an attack, the system will limit the IP login within 10 minutes and notify the user.
  • Page 60 TA1610 User Manual Example: “500;9911”, if the extension has configured Follow Me Settings, the call would go to the forwarded number directly. The attempts to dial a phone number when there is no Attempts answer. The interval between each attempt to dial the phone number.

  • Page 61: Ami Settings

    If necessary, you can enable it. Figure 10-5 AMI Settings  User Name, Password & Port After enabling AMI, you can use this username and password to log in TA1610. The default port is 5038.  Permitted "IP address/Subnet mask"...

  • Page 62: Certificates

    Gateway Certificate This certificate is server certificate. No matter selecting “TLS Verify Client” as “Yes” or “NO”, you should upload this certificate to TA1610. If the VoIP provider enables “TLS Verify server”, you should also upload the relevant CA certificate on the VoIP provider.

  • Page 63: Firewall Rules

    TA1610 User Manual Firewall Rules Firewalls are used to prevent unauthorized Internet users from accessing private networks connected to the Internet, especially intranets. All messages entering or leaving the intranet pass through the firewall, which examines each message and blocks those that do not meet the specified security criteria.
  • Page 64 TA1610 User Manual 2) Common Rules There is no default rule; you can create one as required. Figure 10-8 Common Rules Table 10-3 Description of Common Rules Items Description A name for this rule, e.g. “HTTP”. Name Simple description for this rule. E.g. accept the specific host to Description access the Web interface for configuration.
  • Page 65 TA1610 User Manual Drop: Drop the access from remote hosts. Ignore: Ignore the access. Note: the MAC address will be changed when it’s a remote device, so it will not be working to filter using MAC for remote devices. 3) Auto Defense...

  • Page 66: Ip Blocklist

    TA1610 User Manual IP Blocklist You can set some packets accept speed rules here. When an IP address, which hasn’t been accepted in common rules, sends packets faster than the allowed speed, it will be set as a black IP address and be blocked automatically.
  • Page 67 TA1610 User Manual Table 10-5 Description of Auto Blocklist Rules Items Description Port Auto defense port Protocol Auto defense protocol. TCP or UDP. IP Packets Allowed IP packets number in the specific time interval. The time interval to receive IP packets. For example, IP packets 90, Time interval time interval 60 means 90 IP packets are allowed in 60 seconds.

  • Page 68: System Preferences

    2. Enter a new password and retype the new password to confirm. The password complexity will be detected, which will help users to set a strong password and make TA1610 safer. A strong password is comprised of letters, numbers and characters.

  • Page 69: Date And Time

    TA1610 User Manual Date and Time Please adjust the time of TA1610 (including the time zone) consistent with your local time. Go to System→System Preferences→Date and Time to configure the system date and time. Figure 11-2 Date and Time ...
  • Page 70 MyPBX during boots up. In PNP mode, you just need to place the TA1610 in the same IP range network with MyPBX, then you can find the TA1610 and provision it on MyPBX ”TA Provisioning”...
  • Page 71 Figure 11-6 Set TA1610 as a DHCP Client Another way to do auto provision is to download configuration file from the configured server URL. Fill in the URL, user name, password, and set the time, TA1610 will get the configuration file from the server automatically and regularly.

  • Page 72: Firmware Update

    2. When updating the firmware, please don’t turn off the power. Or the system will be damaged. 3. If you are trying to upgrade through HTTP, please make sure that your TA1610 is able to visit external network, or it cannot access Yeastar website to get the firmware file, causing the upgrade fail.

  • Page 73: Upgrade Through Http

    TA1610 User Manual Upgrade through HTTP On the Firmware Upgrade page, choose HTTP URL. Step1. Enter the download link of the firmware file. Note: the HTTP URL should be a BIN file download link. Step2. Click “Start” to upgrade. Figure 11-8 Upgrade through HTTP Upgrade through TFTP Step1.Download firmware file from Yeastar website.
  • Page 74 TA1610 User Manual Figure 11-9 Configure Tftpd32 System→System Step3. Logon TA1610’s page Preferences→Firmware Update, choose “TFTP Server”. 1) TFTP Server: fill in IP address of tftpd32 server (your PC’s IP address). 2) File Name: enter the name of firmware update. It should be a BIN file name.

  • Page 75: Backup And Restore

    TA1610 configurations to a file. Notes: 1. When you have updated the firmware version, it’s not recommended to restore using an old package. 2. Backup from an earlier version cannot be restored on TA1610 of a later version.  Create a New Backup Click to create a new backup.
  • Page 76 TA1610 User Manual Figure 11-12 Reset and Reboot 76/82...

  • Page 77: Status

    TA1610 User Manual Status Users could check the system status on Status→System Status, where FXO Port and trunk Status, Network Status and System Info can be checked.  Port/Trunk Status  Network Status  System Info Port/Trunk Status Figure 12-1 Port/Trunk Status ...
  • Page 78 TA1610 User Manual Status Idle The FXO port is idle. Busy The FXO port is busy. Disconnect There is no line connected to the FXO port.  VoIP Trunk Status 1) SIP/IAX Type Table 12-2 Description of SIP/IAX Trunk Status...

  • Page 79: Network Status

    TA1610 User Manual Network status In this page, the IP address of TA gateway will appear with their status. Figure 12-2 Network Status If your VLAN or VPN are configured, you can check the status in this page also. System Info In this page, we can check the hardware/firmware version, or the disk usage of TA1610.

  • Page 80: Reports

    TA1610 User Manual Reports Users could check the call logs, system logs on Status→Reports page, and use the packet Tool and Port Monitor Tool to capture debug logs from TA1610.  Call Logs  System Logs  Packet Tool ...

  • Page 81: Packet Tool

    Figure 13-2 System Logs Packet Tool This feature is used to capture packets for technician. Integrate packet capture tool “Wireshark” in TA1610. Users also could specify the destination IP address and port to get the packets. Figure 13-3 Packet Tool...

  • Page 82: Port Monitor Tool

    TA1610 User Manual  Specify the destination IP address to get the packets.  Port Specify the destination Port to get the packets. Port Monitor Tool This tool is used to debug a FXO port. Select a FXO port and click “Start” to monitor the FXO port, stop monitoring by clicking “Stop”...
