NeoGate TA400/800
User Manual
Version 41.18.0.8
Yeastar Information Technology Co. Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NeoGate TA400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yeastar Technology NeoGate TA400

Summary of Contents for Yeastar Technology NeoGate TA400

  • Page 1 NeoGate TA400/800 User Manual Version 41.18.0.8 Yeastar Information Technology Co. Ltd...

  • Page 2: Table Of Contents

    NeoGate TA400/800 User Manual Table of Contents Introduction ..................4 Part I. Configuration Guide ............... 5 1. Login .................... 5 2. Status ................... 7 2.1 System Status ................7 2.1.1 Port Status ................7 2.1.2 Network status ..............8 2.1.3 System Info ................8 2.2 Reports ..................
  • Page 3 NeoGate TA400/800 User Manual 4.2 VoIP Settings ................39 4.2.1 VoIP Server Settings .............39 4.2.2 Dial Pattern Template ............42 4.2.3 SIP Settings.................43 4.2.4 IAX Settings ................49 4.3 Gateway Settings ...............50 4.3.1 General Preferences ..............50 4.3.2 Feature Codes ..............50 4.3.3 Speed Dial Settings ..............53 4.4 Audio Settings ................53...

  • Page 4: Introduction

    NeoGate TA400/800 User Manual Introduction NeoGate TA400/800 FXS Analog VoIP Gateways are cutting-edge products that connect legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems. Featuring rich functionalities and easy configuration, NeoGate TA is ideal for small and medium enterprises that wish to integrate a traditional phone system into IP-based system.

  • Page 5: Part I. Configuration Guide

    NeoGate TA400/800 User Manual Part I. Configuration Guide 1. Login The NeoGate TA attempts to contact a DHCP server in your network to obtain valid network settings (e.g., the IP address, subnet mask, default gateway address and DNS address) by default.
  • Page 6 NeoGate TA400/800 User Manual Figure 1-2 Login NeoGate TA 6/62...

  • Page 7: Status

    NeoGate TA400/800 User Manual 2. Status Click to check the status of NeoGate TA, including the system status and the detailed reports. 2.1 System Status In this page, we can check the status of the system, including trunk status, network status and system information.

  • Page 8: Network Status

    NeoGate TA400/800 User Manual Off-hook/On-hook Hook Description On Hook The FXS port is idle. Off Hook The FXS port is busy. 2.1.2 Network status In this page, the IP address of LAN port will appear with their status. Figure 2-2 Network Status If your VLAN or VPN are configured, you can check the status in this page also.

  • Page 9: Reports

    NeoGate TA400/800 User Manual 2.2 Reports In this page, we can check the call detailed log, system log, and use the packet tool to debug the system when needed. 2.2.1 Call Logs The call log captures all call details, including call time, caller number, callee number, call type, call duration, etc.

  • Page 10: Packet Tool

    NeoGate TA400/800 User Manual Options ·Enable Hardware Log Save the information of hardware; (up to 4 log files) ·Enable Normal Log Save the prompt information; (up to 16 log files) ·Enable Web Log Save the history of web operations (up to 2 log files) ·Enable Debug Log...

  • Page 11: Network Preferences

    NeoGate TA400/800 User Manual 3.1 Network Preferences 3.1.1 LAN Settings Figure 3-1 Static IP Address Mode Table 3-1 Description of LAN Settings Items Description Hostname Set the host name for NeoGate TA Static IP Address Set the NeoGate TA’s IP address as a static IP Set the IP Address for NeoGate TA.

  • Page 12: Service

    NeoGate TA400/800 User Manual 3.1.2 Service The administrator can manage all the access methods on NeoGate TA on the "Service" page. Figure 3-4 Service Settings Table 3-2 Description of Service Settings Items Description By using SSH, you can log in to NeoGate and run commands.
  • Page 13 NeoGate TA400/800 User Manual Figure 3-5 VLAN Settings Table 3-3 Description of VLAN Settings Items Description NO.1 Click the NO.1 you can edit the first VLAN over LAN The VLAN Number is a unique value you assign to each VLAN Number...

  • Page 14: Vpn Settings

    NeoGate TA400/800 User Manual VLAN IP Address Set the IP Address for NeoGate TA VLAN over LAN. VLAN Subnet Mask Set the Subnet Mask for NeoGate TA VLAN over LAN. Default Gateway Set the Default Gateway for NeoGate TA VLAN over LAN.

  • Page 15: Ddns Settings

    NeoGate TA400/800 User Manual 3.1.5 DDNS Settings DDNS (Dynamic DNS) is a method / protocol / network service that provides the capability for a networked device, such as a router or computer system using the Internet Protocol Suite, to notify a Domain Name System (DNS) name server to change, in real time, the active DNS configuration of its configured hostnames, addresses or other information.

  • Page 16: Security Center

    NeoGate TA400/800 User Manual Figure 3-8 Static Route 1) Route Table The current route rules of NeoGate TA. 2) Static Route Rules You can add new static route rules here. Table 3-5 Description of Static Route Settings Items Description Destination The destination network to be accessed to by NeoGate TA.
  • Page 17 NeoGate TA400/800 User Manual Firewall: Figure 3-9 Firewall In the “Firewall” tab, you can check firewall configuration and alert settings. You can enter the configuration page directly by clicking the relevant button. Service: Figure 3-10 Service In “Service” tab, you can check AMI /SSH/FTP/TFTP/HTTP/HTTPS status. You can enter the configuration page directly by clicking the relevant button.

  • Page 18: Alert Settings

    NeoGate TA400/800 User Manual 3.2.2 Alert settings If the device is under attack, the system will alert users via call or E-mail. The attack modes include IP attack and Web Login. Figure 3-12 Alert Settings 1. IPATTACK When the system is attacked by IP address, the firewall will add the IP to auto IP Blacklist and notify the user if it matches the protection rule.
  • Page 19 NeoGate TA400/800 User Manual Subject The subject of the alert email. Text content supports predefined variables. Variable names and corresponding instructions are as follows: gateway hostname:$(HOSTNAME) Email Content attack source ip address:$(SOURCEIP) attack dest mac:$(DESTMAC) attack source port:$(DESTPORT) attack source protocol:$(PROTOCOL)

  • Page 20: Ami Settings

    NeoGate TA400/800 User Manual 2. WEBLOGIN Web Login Alert Notification: entering the wrong password consecutively for five times when logging in NeoGate TA Web interface will be deemed as an attack, the system will limit the IP login within 10 minutes and notify the user.
