- Page 1 Compact performance Brief description CPV valve terminal with AS-Interface type CPV10/14-ASI-8 – English 8101710 2018-11b [8101712]...
- Page 2 Translation of the original instructions Documentation on the product For all available product documentation è www.festo.com/pk Copyright: Festo AG & Co. Ruiter Straße 82 73734 Esslingen Germany Internet: http://www.festo.com E-Mail: service_international@festo.com Reproduction, distribution or sale of this document or communication of its contents to others without express authorization is prohibited.
- Page 3 S Connect the earth connection on the left end plate with low impedance (short cable with large cross-sec tional area) to the earth potential. S Commission only a valve terminal which has been fitted and wired completely. Festo CPV10/14-ASI-8E6A 2018-11b English...
- Page 4 AS-Interface voltage applied, no fault No AS-Interface voltage on the bus flashes AS-Interface address not set ( = 0) flashes Short circuit / overload at the inputs or address selector switch actuated Bus communication failed (watchdog expired) Festo CPV10/14-ASI-8E6A 2018-11b English...
-
Page 5: Installation Instructions
Slave 1: IO code 7 Slave 2: IO code 7 Data bits: Inputs: Outputs: – – E/A = bi directional (B) The address mapping depends on the configuration of the master. Festo CPV10/14-ASI-8E6A 2018-11b English... - Page 6 2.1. Other addressers do not permit clear access to the slaves and in some cases overwrite the ID1 codes. Recommendation: Use the Festo addresser type ASI-PRG- ADR with adapter cable type KASI-ADR. Factory setting:...
- Page 7 3.3 Address assignment of the valves During addressing, valve terminal CPV..-GE-ASI-8E6A-... behaves like two individual slaves each with 4 inputs and 3 outputs (see sections 3.1 and 2). The following fittings are possible for the two valve terminal halves: Festo CPV10/14-ASI-8E6A 2018-11b English...
- Page 8 (e.g. code J, N, C, H, G, D, I, E) *) 6 Only blanking or separator plate permitted (e.g. code L, S, T) 7 Valve plates with 1 valve solenoid coil (e.g. code M, F, A) *) *) or blanking or separator plate Festo CPV10/14-ASI-8E6A 2018-11b English...
- Page 9 When the short circuit is eliminated, the slave registers immedi ately as capable of functioning. Inputs of the first slave Inputs of the second slave Pin assignment: 1: 24 V 3: 0 V 4: Input Ix Festo CPV10/14-ASI-8E6A 2018-11b English...
- Page 10 PELV circuits in accordance with IEC/DIN EN 60204-1. By the use of PELV circuits, protection against electric shock (protection against direct and indirect contact) is guaranteed in accordance with IEC/EN 60204-1 (Electri cal equipment for machines, General requirements). Festo CPV10/14-ASI-8E6A 2018-11b English...
- Page 11 3. Place the cable socket in position and screw it tight (max. 0.3 Nm). Seal open flat cable ends with the Festo cable cap type ASI-KK-FK or the cable sleeve type ASI-KT-FK. In this way you will avoid leakage currents and comply with protection class IP65.
- Page 12 5 to 8 (slave 2) Instructions on removign the electric sub-base can be found in the Pneumatics Manual. The permitted valve com binations as well as the relevant DIP switch settings can be found in the table in section 3.3. Festo CPV10/14-ASI-8E6A 2018-11b English...
-
Page 13: Technical Specifications
– ID2 code ID2 = E – IO code IO = 7 – Profile S-7.A.E Factory setting: Slave 1 = address #1, A slave (ID1 = 7 Slave 2 = address #1, B slave (ID1 = F Festo CPV10/14-ASI-8E6A 2018-11b English... - Page 14 OFF: -30 ... 5 V – Reference potential – Response delay typ. 3 ms (at 24 V) e.g. per input 30 mA, incl. 7 mA for input circuit ) for max. 30 ms all valve coils switched simultaneously Festo CPV10/14-ASI-8E6A 2018-11b English...
