APPLIED FUNCTIONS
d-COLOR P3100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the d-COLOR P3100 and is the answer not in the manual?

Questions and answers

Related Manuals for Olivetti d-COLOR P3100

Summary of Contents for Olivetti d-COLOR P3100

  • Page 1 APPLIED FUNCTIONS d-COLOR P3100...

  • Page 3: Table Of Contents

    [PKI Settings] - [Device Certificate]....................1-21 [PKI Settings] - [SSL/TLS Settings]....................1-21 [PKI Settings] - [Protocol Settings] ....................1-22 [PKI Settings] - [External Certificate]....................1-25 [PKI Settings] - [Validate Certificate] ....................1-25 [IPsec] .............................. 1-26 [IP Address Filtering] ........................1-29 d-COLOR P3100 Contents-1...
  • Page 4 Overview ............................2-8 Self-creating a certificate ........................2-8 Requesting CA for a certificate issuance................... 2-9 2.4.2 Managing the certificates for this machine ..................2-10 Exporting a certificate ........................2-10 Importing a certificate ........................2-10 Deleting a certificate ........................2-10 Contents-2 d-COLOR P3100...
  • Page 5 [Text Options]............................. 5-7 [Graphics Options] ..........................5-7 [Simulation] ............................5-8 Printing procedure .......................... 5-8 Using the Authentication Unit (IC Card Type) Authentication Unit (IC card type) ....................6-3 Operations required to use this function (for Administrators)............ 6-4 d-COLOR P3100 Contents-3...
  • Page 6 6.2.1 Configuring authentication settings of this machine................6-4 6.2.2 Registering user authentication information ..................6-4 Data Administrator ..........................6-4 Setting up Data Administrator......................6-4 Registering user authentication information ..................6-6 Logging in to this machine......................6-7 Index Contents-4 d-COLOR P3100...

  • Page 7: Using Web Connection

    Using Web Connection...

  • Page 9: Web Connection

    Specifications Network Ethernet (TCP/IP) Web Browser For Windows • Microsoft Internet Explorer 8 or later • Mozilla Firefox 18 or later For Mac OS • Mozilla Firefox 18 or later On Linux • Mozilla Firefox 18 or later d-COLOR P3100...

  • Page 10: Operations Required To Use This Function

    [Network] tab under the [Advanced] menu, and select [Manual proxy configuration]. In the [No Proxy for] text box, enter the IP address or the host name of this machine and click [OK]. Reference For details, refer to the Help of your Web browser. d-COLOR P3100...

  • Page 11: Basic Usage

    If you use Internet Explorer 7/8/9 or a Web browser other than Internet Explorer in the IPv6 environment, enclose the IPv6 address in [ ]. Example: When the IPv6 address of this machine is fe80::220:6bff:fe10:2f16, enter "http://[fe80::220:6bff:fe10:2f16] /". d-COLOR P3100...

  • Page 12: Web Connection Screen Configuration

    Click the menu at the left-hand side of the screen, and the contents of tings that menu will appear. Menu Click the category of the menu to display the menu items of that cat- egory. Menu category Menu items are divided into some categories depending on each con- tent. d-COLOR P3100...

  • Page 13: Status Display

    1-8. Tips The screen that appears differs depending on whether Authentication is enabled on this machine. Also, op- erations available after you log in differ depending on the information you enter on this Login screen. d-COLOR P3100...

  • Page 14: Login Mode

    To log in as a registered user, select [Registered User] on the Log in screen. % To log in as a public user, select [Public User], then click [Log in] on the Log in screen. Enter the user name and password, then click [Log in]. The user mode window appears. d-COLOR P3100...

  • Page 15: Available Operations In User Mode

    Enables you to check the job that is currently being performed and the job log. Item Description [Current Jobs] Displays the print jobs that are currently being processed on this machine. [Job History] Displays the print jobs for which processing is completed on this machine. d-COLOR P3100...

  • Page 16: Print] Tab

    Select the report that you want to print, and click [Print]. [Direct Print] Prints the file on the computer by directly sending it to this machine. This function is available when an optional Hard Disk is installed. For details, refer to [User's Guide Print]. 1-10 d-COLOR P3100...

  • Page 17: Available Operations In Administrator Mode

    Displays the total number of sheets of paper that has been printed on this ma- per Size] chine by paper size. [Sheets Printed by Pa- Displays the total number of sheets of paper that has been printed on this ma- per Type] chine by paper type. d-COLOR P3100 1-11...

  • Page 18: [Online Assistance]

    Enter the month. [Day] Enter the day. [Hour] Enter the hour. [Minute] Enter the minute. [Time Zone] Select a time zone (time difference from world standard time) to suit your en- vironment. [GMT] is specified by default. 1-12 d-COLOR P3100...

  • Page 19: [Date/Time Settings] - [Time Adjustment Settings]

    Specifies daylight saving time for the current country setting. Item Description [Daylight Saving Time] Select [Enable] to use daylight saving time. Also enter the time to be adjusted for daylight saving time (in minutes). [Disable] is specified by default. d-COLOR P3100 1-13...

  • Page 20: [Machine Settings]

    When this option is selected, this machine restarts automatically. [Network Settings] Initializes the network settings. When this option is selected, this machine restarts automatically. [All Settings] Initializes the all settings. When this option is selected, this machine restarts automatically. 1-14 d-COLOR P3100...

  • Page 21: [Maintenance] - [Reset]

    Select whether or not to send a notification when a job is completed. [Enable] is specified by default. [Job Error] Select whether or not to send a notification when a job has terminated abnor- mally. [Enable] is specified by default. d-COLOR P3100 1-15...

  • Page 22: [Notification Settings] - [Total Counter Notification Settings]

    If there is a job log file that has not been downloaded since it was created, a confirmation dialog box appears, asking whether or not to delete the current job log file and create new job log file. 1-16 d-COLOR P3100...

  • Page 23: [Job Log] - [Download Job Log]

    [Allow]: Prints a received job as it is. • [Restrict]: Deletes a received job. [Restrict] is specified by default. [Counter] Click [Reset] to reset the counters for all users and all accounts. Tips This function is available when an optional Hard Disk is installed. d-COLOR P3100 1-17...

  • Page 24: [Authentication] - [User List]

    [Counter] Click [Reset] to reset the counters for the user. [Authentication Device Displays whether the information on the authentication device is registered. Settings] Tips This function is available when an optional Hard Disk is installed. 1-18 d-COLOR P3100...

  • Page 25: [Authentication] - [Account Track List]

    [Black]: To manage the upper limit for black and white printing, select this check box, then enter the maximum allowance. [Counter] Click [Reset] to reset the counters for the account. Tips This function is available when an optional Hard Disk is installed. d-COLOR P3100 1-19...

  • Page 26: [Authentication] - [Public User Registration]

    ID & Print job. If there is no ID & Print job, log in to this machine. • [Access Basic Screen]: Log in to this machine. The ID & Print job is not ex- ecuted. [Begin Printing] is specified by default. Tips This function is available when an optional Hard Disk is installed. 1-20 d-COLOR P3100...

  • Page 27: [Authentication Device Settings] - [General Settings]

    Select the SSL encryption strength. Select the appropriate strength to suit your environment. [AES-256, 3DES, RC4-128] is specified by default. [SSL/TLS Version] Select the version of the SSL to be used. Select the appropriate version to suit your environment. d-COLOR P3100 1-21...

  • Page 28: [Pki Settings] - [Protocol Settings]

    [Disable] is specified by default. • [Check OCSP Expiration]: Check whether or not the certificate has expired with the OCSP (Online Certificate Status Protocol) service. [Disable] is specified by default. [Device Certificate] Select the certificate to be used. 1-22 d-COLOR P3100...
  • Page 29 [Disable] is specified by default. • [Client Certificate]: Select whether or not to request a certificate from cli- ents that connect to this machine. [Disable] is specified by default. [Device Certificate] Select the certificate to be used. d-COLOR P3100 1-23...
  • Page 30 [Check OCSP Expiration]: Check whether or not the certificate has expired with the OCSP (Online Certificate Status Protocol) service. [Disable] is specified by default. [Device Certificate] Select the certificate to be used. Tips An optional i-Option LK-111 is required to use the ThinPrint function. 1-24 d-COLOR P3100...

  • Page 31: [Pki Settings] - [External Certificate]

    Enter the user name to log in to the proxy server (using ASCII characters of up to 63 bytes). [Password] Enter the password (using ASCII characters of up to 63 bytes). To enter (change) the password, select the [Change Password] check box, then enter a new password. d-COLOR P3100 1-25...

  • Page 32: [Ipsec]

    [Group2] is specified by default. [Negotiation Mode] Select the method to securely generate a common key used for encrypted communication. This option is available when [IKEv1] is selected in the [IPsec Settings] window. [Main Mode] is selected by default. 1-26 d-COLOR P3100...
  • Page 33 Specify the common key used for encryption. cryption] You can specify different common keys respectively for send and receive. [Common Key Au- Specify the common key used for authentication. thentication] You can specify different common keys respectively for send and receive. d-COLOR P3100 1-27...
  • Page 34 Select an action to be taken if no settings meet the [IPsec Policy] while IP- sec communication is enabled. Select [Deny] to discard IP packets that do not meet the [IPsec Policy] set- tings. [Allow] is specified by default. 1-28 d-COLOR P3100...

  • Page 35: [Ip Address Filtering]

    Select the check box for the protocol that you want to exclude from access re- striction using the IP address filtering. [OFF] (not selected) is specified by default. Tips IP address filtering is not supported in the IPv6 environment. d-COLOR P3100 1-29...

  • Page 36: [Ieee802.1X]

    To specify the delay time, set [Network Stop] to [Enable], and enter the delay (sec.) in [Limit Time]. To restart the authentication process after network communication stopped, reboot this machine. [Disable] is specified by default. 1-30 d-COLOR P3100...

  • Page 37: [Auto Logout]

    Displays the ID No. of the job. [User Name] Displays the user name of the job. [Document Name] Displays the name of the job. [Result] Displays the execution result of the job. [Detail] Displays the detailed information of the job. d-COLOR P3100 1-31...

  • Page 38: Print] Tab

    [Auto]: Prints on paper that matches the image size. • [Priority Paper Size]: Prints on the primary paper size. [Priority Paper Size] is specified by default. This function is available when an optional Hard Disk is installed. 1-32 d-COLOR P3100...

  • Page 39: [Default Settings] - [Paper Source Settings]

    Item Description [Tray Mapping Mode] Select whether or not to enable the tray mapping. [Off] is specified by default. [Logical Tray 0] to [Log- Assigns logical trays 0 to 9 to physical trays. ical Tray 9] d-COLOR P3100 1-33...

  • Page 40: [Default Settings] - [Pcl Settings]

    [Intent]: Specify the color conversion property that is changed from input RGB to device CMYK. [Vivid] is specified by default. • [Gray Treatment]: Specify the printing method of black and gray colors. [Black and Gray] is specified by default. 1-34 d-COLOR P3100...

  • Page 41: [Default Settings] - [Postscript Settings]

    RGB to device CMYK. [Vivid] is specified by default. • [RGB Gray Treatment]: Specify the printing method of black and gray colors. [Black and Gray] is specified by default. • [Destination Profile]: Specify the output profile. [Auto] is specified by de- fault. d-COLOR P3100 1-35...

  • Page 42: [Default Settings] - [Xps Settings]

    [Print to XPS Error] Select whether or not to print error information when an error occurs when an XPS file is being printed. [On] is specified by default. Tips This function is available when an optional Hard Disk is installed. 1-36 d-COLOR P3100...

  • Page 43: [Default Settings] - [Print Quality Settings]

    Adjust the density of yellow in highlight portions, intermediate portions, and shadow portions. [0] is specified by default in every case. [Black Density] Adjust the density of black in highlight portions, intermediate portions, and shadow portions. [0] is specified by default in every case. d-COLOR P3100 1-37...

  • Page 44: [Default Settings] - [Ooxml Settings]

    Select whether to automatically adjust the zoom ratio or specify any zoom ratio to enlarge or reduce a page. [Auto] is specified by default. [Frame] Select whether or not to print a border line between pages. [Disable] is specified by default. 1-38 d-COLOR P3100...

  • Page 45: [Default Settings] - [Barcode Settings]

    [Delete Color Pro- Delete the color profiles that are saved on the HDD of this machine. file] In the list of color profiles, select the check box of the color profile you want to delete, and click [Delete]. d-COLOR P3100 1-39...

  • Page 46: [Report Types]

    Change the time-out time to limit a communication with the computer. Item Description [I/O Timeout] When this machine is connected via a USB device to the computer, change the communication time-out time if necessary. [60] sec. is specified by default. 1-40 d-COLOR P3100...

  • Page 47: [Tcp/Ip Settings] - [Tcp/Ip Settings]

    [Enable] is specified by default. [DNS Server Automatic Select whether or not to automatically obtain the address of the DNS server. Acquisition] When using DHCPv6, the DNS server address can be specified automatically. [Enable] is specified by default. d-COLOR P3100 1-41...

  • Page 48: [Tcp/Ip Settings] - [Raw Port Settings]

    When your DNS server supports the Dynamic DNS function, the specified host name can be automatically registered on the DNS server or changes can be automatically updated as long as [Enable] is selected. [Disable] is specified by default. 1-42 d-COLOR P3100...

  • Page 49: [E-Mail Settings] - [E-Mail Tx (Smtp)]

    [Divided Mail Size] Enter the size to divide an E-mail when selecting [On] in [Binary Division]. [500] KB is specified by default. [SMTP Authentication] Configure the setting if your environment requires the SMTP authentication for sending an E-mail. d-COLOR P3100 1-43...

  • Page 50: [Http Settings] - [Http Server Settings]

    [Get Jobs]: Allows you to obtain a list of job attributes. • [Get Print Attributes]: Allows you to obtain printer attributes. [ON] (selected) is specified by default in every case. [IPP Authentication] Select the IPP authentication method. [Requesting-user-name] is specified by default. 1-44 d-COLOR P3100...

  • Page 51: [Ftp Settings] - [Ftp Server Settings]

    [SNMP v3 (IP)] Select whether or not to use SNMP v3. [Enable] is specified by default. [UDP Port] If necessary, change the UDP port number. [161] is specified by default. [SNMP v1/v2c Settings] Configure the SNMP v1/v2c settings. d-COLOR P3100 1-45...
  • Page 52 Select whether or not to allow a notification of the status of this machine using the SNMP TRAP function. [Enable] is specified by default. [Trap Setting When Select whether or not to send TRAP when authentication fails. Authentication [Disable] is specified by default. Fails] 1-46 d-COLOR P3100...

  • Page 53: [Web Service Settings] - [Common Settings]

    Select whether or not to use SSL for a communication via OpenAPI. This setting is available when the certification of this machine is registered. [Non-SSL Only] is specified by default. [Port Number If necessary, change the SSL communication port number. (SSL/TLS)] [50003] is specified by default. d-COLOR P3100 1-47...

  • Page 54: [Tcp Socket Settings]

    Select whether or not to use LLTD (Link Layer Topology Discovery). Using LLTD, you can display this machine on the network map if your computer is equipped with Windows Vista or later (Windows Vista/7/8/8.1/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2). [Enable] is specified by default. 1-48 d-COLOR P3100...

  • Page 55: Configuring The Operating Environment Of This Machine

    Configuring the Operating Environment of This Machine...

  • Page 57: Configuring The Ws Print Operating Environment

    Enter the name of this machine when using it as a WS printer (using up to 127 bytes, excluding !, \, and ,). [Printer Location] If necessary, enter the installation location of the printer (using up to 127 bytes). [Printer Information] If necessary, enter the printer information (using up to 127 bytes). d-COLOR P3100...

  • Page 58: Using Ssl Communication

    In the administrator mode, select [Network] - [Web Service Settings] - [Common Settings], then configure the following settings. Settings Description [Secure Mode] Select [Enable] to use SSL communication. [Disable] is specified by default. Tips If you are using Windows 8/8.1, a communication that utilizes the Web service cannot be encrypted using SSL. d-COLOR P3100...

  • Page 59: Employing User Authentication

    [Color]: To manage the upper limit for color printing, select this check box, then enter the maximum allowance. • [Black]: To manage the upper limit for black and white printing, select this check box, then enter the maximum allowance. d-COLOR P3100...

  • Page 60: Associating User Authentication With Account Track

    [Color]: To manage the upper limit for color printing, select this check box, then enter the maximum allowance. • [Black]: To manage the upper limit for black and white printing, select this check box, then enter the maximum allowance. d-COLOR P3100...
  • Page 61 [Color]: To manage the upper limit for color printing, select this check box, then enter the maximum allowance. • [Black]: To manage the upper limit for black and white printing, select this check box, then enter the maximum allowance. d-COLOR P3100...

  • Page 62: Using The Certificate Of This Machine

    Displays the date and time of this machine when this screen is displayed. [Validity Period] Enter the validity period of a certificate with the number of days that have elapsed since the starting date. When the certificate has been installed, enable SSL communication. % For details, refer to page 1-21. d-COLOR P3100...

  • Page 63: Requesting Ca For A Certificate Issuance

    In the administrator mode, select [Security] - [PKI Settings] - [Device Certificate] - [Edit] - [Install a Cer- tificate] - [Next], and specify the text data sent from the Certificate Authority (CA), and then click [Apply]. When the certificate has been installed, enable SSL communication. % For details, refer to page 1-21. d-COLOR P3100...

  • Page 64: Managing The Certificates For This Machine

    Enter the password specified when the certificate is exported. Deleting a certificate A certificate for this machine can be deleted if necessary. In the administrator mode, select [Security] - [PKI Settings] - [Device Certificate] - [Edit] - [Delete a Certificate], then click [Next]. 2-10 d-COLOR P3100...

  • Page 65: Manually Installing The Printer Driver (For Windows)

    Manually Installing the Printer Driver (for Windows)

  • Page 67: Checking The Connection Method

    For the installation procedure, refer to page 3-14. A connection using a USB port. Connection method in A connection using a USB port. which plug and play- • For the installation procedure, refer to page 3-15. based setup is possible d-COLOR P3100...

  • Page 68: In Windows Xp/Server 2003

    For the installation procedure, refer to page 3-11. A connection using a USB port. Connection method in A connection using a USB port. which plug and play- • For the installation procedure, refer to page 3-15. based setup is possible d-COLOR P3100...

  • Page 69: Using Lpr/Port9100 Connection For Installation

    Selectable printer drivers: PCL driver, PS driver, and XPS driver Click [OK]. The [Printers] list appears. Click [Next]. Follow the on-screen instructions to carry out operations. % If the [User Account Control] window appears, click [Continue] or [Yes]. Click [Finish]. d-COLOR P3100...

  • Page 70: In Windows Vista/7/Server 2008/Server 2008 R2

    % If the [User Account Control] window appears, click [Continue] or [Yes]. Click [Finish]. After finishing the installation, make sure that the icon for the installed printer is displayed in the [Print- ers] or [Devices and Printers] window. d-COLOR P3100...

  • Page 71: Installing The Printer Driver By Creating A New Port

    Click [Finish]. After finishing the installation, make sure that the icon for the installed printer is displayed in the [Devic- es and Printers] window. Remove the CD/DVD-ROM from the CD/DVD-ROM drive. Installation of the printer driver is then completed. d-COLOR P3100...

  • Page 72: In Windows Vista/7/Server 2008/Server 2008 R2

    Select the folder on the CD/DVD-ROM containing the desired printer driver, then click [Open]. % Select the folder according to the printer driver, operating system, and language to be used. Selectable printer drivers: PCL driver, PS driver, and XPS driver Click [OK]. The [Printers] list appears. Click [Next]. d-COLOR P3100...

  • Page 73: In Windows Xp/Server 2003

    % For the Port 9100 connection, select the [Raw] check box, then enter a RAW port number ([9100] by default) in [Port Number:]. Click [Next >]. Click [Finish]. [Add Printer Wizard] appears. Click [Have Disk...]. Click [Browse...]. d-COLOR P3100...
  • Page 74 Click [Finish]. After finishing the installation, make sure that the icon for the installed printer is displayed in the [Printers and Faxes] window. Remove the CD/DVD-ROM from the CD/DVD-ROM drive. Installation of the printer driver is then completed. 3-10 d-COLOR P3100...

  • Page 75: Using Ipp Connection For Installation

    Select the folder on the CD/DVD-ROM containing the desired printer driver, then click [Open]. % Select the folder according to the printer driver, operating system, and language to be used. Selectable printer drivers: PCL driver, PS driver, and XPS driver Click [OK]. The [Printers] list appears. Click [Next]. d-COLOR P3100 3-11...

  • Page 76: In Windows Vista/7/Server 2008/Server 2008 R2

    Select the folder on the CD/DVD-ROM containing the desired printer driver, then click [Open]. % Select the folder according to the printer driver, operating system, and language to be used. Selectable printer drivers: PCL driver, PS driver, and XPS driver Click [OK]. The [Printers] list appears. Click [OK]. 3-12 d-COLOR P3100...

  • Page 77: In Windows Xp/Server 2003

    The [Printers] list appears. Click [OK]. Follow the on-screen instructions to carry out operations. Click [Finish]. After finishing the installation, make sure that the icon for the installed printer is displayed in the [Printers and Faxes] window. d-COLOR P3100 3-13...

  • Page 78: Using The Web Service Connection For Installation

    After finishing the installation, make sure that the icon for the installed printer is displayed in the [Print- ers] or [Devices and Printers] window. Reference If the printer driver is not correctly installed, the driver must be updated using [Update Driver...]. For details, refer to page 3-16. 3-14 d-COLOR P3100...

  • Page 79: Using Usb Connection For Installation

    Selectable printer drivers: PCL driver and PS driver Click [Next >], and perform the procedure by following the on-screen instructions. Click [Finish]. After finishing the installation, make sure that the icon for the installed printer is displayed in the [Printers and Faxes] window. d-COLOR P3100 3-15...

  • Page 80: Updating The Printer Driver

    After finishing the installation, make sure that the icon for the installed printer is displayed in the [Devic- es and Printers] window. Remove the CD/DVD-ROM from the CD/DVD-ROM drive. This completes the update of the printer driver. 3-16 d-COLOR P3100...

  • Page 81: Manually Uninstalling The Printer Driver

    Click [Uninstall]. Close the open windows, and then restart the computer. % Be sure to restart the computer. Uninstallation of the printer driver is then completed. d-COLOR P3100 3-17...
  • Page 82 The number of the PNF file is the same as that of the inf file. If you have deleted a file using [Remove driver and driver package.] in Windows Vista/7/8/8.1/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2, this operation is not required. 3-18 d-COLOR P3100...

  • Page 83: Adding A Printer Using Lpr/Ipp Connection (Mac Os Environment)

    Adding a Printer Using LPR/IPP Connection (Mac OS Environment)

  • Page 85: Using Lpr Connection

    The printer driver for the machine specified with the IP address is displayed in [Print Using:] or [Use:]. % When the printer driver is displayed, go to Step 14. % When the printer driver is not correctly displayed, go to Step 13. d-COLOR P3100...

  • Page 86: In Mac Os X 10.3

    In [Printer Type:], select [LPD/LPR]. In [Printer Address:], enter the IP address for the machine. In [Printer Model:], select [GENERIC], then click the driver of the desired printer from the model list. Click [Add]. Addition of the printer is then completed. d-COLOR P3100...

  • Page 87: Using Ipp Connection

    % In Mac OS X 10.5, select [Select a driver to use...] in [Print Using:], then click the driver of the desired printer from the list. % In Mac OS X 10.4, select [GENERIC] in [Print Using:], and then click the driver of the desired printer from the list. d-COLOR P3100...

  • Page 88: In Mac Os X 10.3

    In [Printer Address:], enter the IP address for the machine. % Leave [Queue Name:] blank. In [Printer Model:], select [GENERIC], then click the driver of the desired printer from the model list. Click [Add]. Addition of the printer is then completed. d-COLOR P3100...

  • Page 89: Printing In The Linux Environment

    Printing in the Linux Environment...

  • Page 91: System Environment Requirements

    Any processor of the same or higher specifications as recommended for your oper- ating system Memory Memory capacity as recommended for your operating system Drive CD/DVD-ROM drive Tips The following describes the operation procedure using Red Hat Enterprise Linux 5, as an example. d-COLOR P3100...

  • Page 92: Preparation For Printing

    % You can obtain the PPD file of the various languages in the "Drivers/LinuxPPD/<language>" folder. Select the PPD file suitable for your language. Click [Forward]. Click [Apply]. Remove the CD/DVD-ROM from the CD/DVD-ROM drive. Installation of the printer driver is then completed. d-COLOR P3100...

  • Page 93: Manually Adding The Printer Driver

    % You can obtain the PPD file of the various languages in the "Drivers/LinuxPPD/<language>" folder. Select the PPD file suitable for your language. Select this machine in the model column, then click [Add Printer]. To use the administrator privileges, enter the user name and password, then click [OK]. d-COLOR P3100...

  • Page 94: Configuring The Default Settings Of The Printer Driver

    [2-Sided] is specified by default. [Orientation] Specify the orientation of the original. [Portrait] is specified by default. [Binding Position] Select the binding position. [Left Bind] is specified by default. [Select Color] Select colors for printing. [Auto Color] is specified by default. d-COLOR P3100...

  • Page 95: [Image Options]

    Treatment] [Black and Gray] is specified by default. [Graphics Halftone] Select the half-tone image processing method. [Detail] is specified by default. [Graphics Edge En- Select whether or not to sharpen the edges. hancement] [On] is specified by default. d-COLOR P3100...

  • Page 96: [Simulation]

    The following steps and operations may vary depending on the version of your operating system. Open data of the original using the application software. From the [File] menu, select [Print]. Specify the printer that you want to use for printing. Click [Print]. Printing is executed. d-COLOR P3100...

  • Page 97: Using The Authentication Unit (Ic Card Type)

    Using the Authentication Unit (IC Card Type)

  • Page 99: Authentication Unit (Ic Card Type)

    If this machine provides user authentication, you can log in to this machine or execute a print job using the IC card authentication function. Tips To employ IC card user authentication, the setting by your service engineer is required in addition to optional Hard Disk and Authentication Unit. For details, contact your service representative. d-COLOR P3100...

  • Page 100: Operations Required To Use This Function (For Administrators)

    To check the version of your Data Administrator, select the [Help] menu in Data Administrator, and also select [Version Information] - [Plug-in version]. IC CardDriver (USB-Driver) and Data Administrator PlugIn are stored on the CD/DVD-ROM included in the authentication unit. d-COLOR P3100...
  • Page 101 Select [I accept the terms in the license agreement], then click [Next]. Click [Install]. When the installation is complete, click [Finish]. This completes the installation of Data Administrator PlugIn for IC Card Authentication Unit AU-201, which completes the setup. d-COLOR P3100...

  • Page 102: Registering User Authentication Information

    Restart this machine. NOTICE When restarting this machine, turn the Power Switch off and on again after 10 or more seconds have elapsed. Not doing so may result in an operation failure. d-COLOR P3100...

  • Page 103: Logging In To This Machine

    Touch the IC card to or place it on the Authentication Unit. Authentication starts. If authentication succeeds, you can log in to this machine. Tips If authentication fails frequently, IC card information may not have been correctly registered. Register IC card information again. d-COLOR P3100...
  • Page 104 Logging in to this machine d-COLOR P3100...

  • Page 105: Index

    Index...
  • Page 107 Security 1-17 System 1-9 1-11 User Authentication (MFP authentication) Preparation 2-5 User mode 1-8 Web browser 1-4 Web Connection How to access 1-5 Icon 1-7 Login mode 1-8 Login screen 1-7 Overview 1-3 Preparation 1-4 Screen configuration 1-6 d-COLOR P3100...
  • Page 108 2) The Quality System is in compliance with the UNI EN ISO 9000 series of Standards Olivetti S.p.A. - Via Jervis, 77 - 10015 Ivrea (To) - Italy - Tel +39 0125 7751 - Cap. Soc. € 13.200.000 i.v. - R.E.A. 547040 - Cod. Fisc./P.IVA e iscriz. al Reg. Imp. Di Torino 02298700010...
