Control Room Unit for Model 9100 Carbon Monoxide Monitors

Menu Tree

CO Reading
Parameters
Faults
Calibration
Setup
Faults
Any faults indicated by the Model 9100 can be viewed on the Faults display. If no
faults are found, the display will show "No Faults". If faults are present, the display will
indicate the relevant fault message. Multiple faults can be viewed by scrolling left or
right using the touch screen.
Large text display
Display units (ppm or mg/m3) match those selected on the
Model 9100
Parameters page 1
Parameters page 2
Parameters page 3
Parameters page 4
Parameters page 5
List of active faults
Start Cal Check
Start Zero Cal
Set Modbus Address
O/P Range 1
O/P Range 2
Alarm 1
Alarm 2
