１０－５．Applicable Motors
● Applicable motors are 5-phase stepping motors ranging from 0.75A/phase ～ 1.4A/phase.
Representative Motors
ORIENTAL MOTOR CO., LTD.
PK543-A(B)
PK544-A(B)
PK545-A(B)
PK564-A(B)
PK566-A(B)
PK564H-A(B)
PK566H-A(B)
PK569-A(B)
PK596-A(B)
PK599-A(B)
TAMAGAWA SEIKI CO., LTD.
TS3667N1E2(N11E2)
TS3667N2E5(N12E5)
TS3667N3E7(N13E7)
SANYO DENKI CO., LTD.
103H5505-7040(7010)
103H5508-7040(7010)
103H5510-7040(7010)
103H6500-7041(7011)
103H6501-7041(7011)
103H7851-7051(7021)
103H7852-7051(7021)
103H7853-7051(7021)
103H8581-7041(7011)
103H8582-7041(7011)
Factory setting
( ) : Both axes
Basic Setting
Current
Angle DRIVE I.SEL
(A/phase)
(°) switch No.
0.72 0.75
0.72 1.4
0.72 1.4
0.72 0.75
0.72 0.75
0.72 0.75
0.72 0.75
0.72 0.75
-40-
Setting
MOTOR SEL
switch
6 OFF
(10L)
F OFF
(10L)
F OFF
(10L)
6 OFF
(10L)
F ON
(5L)
F ON
(5L)
F ON
(5L)
F ON
(5L)
F OFF
(10L)
Instructions Manual
Torque
Data
Fig. No.
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
Fig.9
Fig.10
Fig.11
Fig.12
Fig.13
Fig.14
Fig.15
Fig.16
Fig.17
Fig.18
Fig.19
Fig.20
Fig.21
Fig.22
Fig.23
－
