Melec GD-5410 Instruction Manual page 8

●When setting up the MOTOR SELECT switch:
●When setting up the STEP ANGLE SELECT switch:
●When setting up the HOLD CURRENT SELECT switch:
●When setting up the DRIVE CURRENT SELECT switch:
●When inputting the motor excitation stop (M.F) signal:
 I
Erroneous setting may cause burn on the
skin due to overheating of the motor.
Ensure correct setting.
 I
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
 I
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
 I
Erroneous setting may cause burn on the
skin due to overheating of the motor.
Ensure correct setting.
 I
Deterioration of the holding power with
the motor may cause breakage of machine
or injury.
Check safety before inputting.
-8-
Instructions Manual
