CHARACTERISTICS:
The HD67086 are converters from M-Bus Wireless and M-Bus to BACnet Slave.
They allows the following characteristics:
Electrical isolation between Ethernet and M-Bus;
Baud Rate and Parity (for M-Bus on wire) changeable with software;
Available wM-Bus frequency: 169 MHz or 433 MHz or 868 MHz (in relation to the order code);
Mountable on 35mm Rail DIN;
Wide power supply input range: 15...21V AC or 18...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67086 software on your PC in order to perform the following:
Define the parameter of BACnet;
Define the parameter of M-Bus line;
Define the parameter of wM-Bus line;
Define which M-Bus variables are readable on BACnet;
Update the device.
