Industrial Electronic Devices
User Manual
Revision 1.100
English
M-Bus / M-Bus Wireless / BACnet
Slave - Converter
(Order Code: HD67086-IP-B2-xxxMHz-0, HD67086-IP-B2-xxxMHz-20,
HD67086-IP-B2-xxxMHz-40, HD67086-IP-B2-xxxMHz-80,HD67086-IP-
B2-xxxMHz-160, HD67086-IP-B2-xxxMHz-250)
(Order Code: HD67086-MSTP-B2-xxxMHz-0, HD67086-MSTP-B2-
xxxMHz-20, HD67086-MSTP-B2-xxxMHz-40, HD67086-MSTP-B2-
xxxMHz-80,HD67086-MSTP-B2-xxxMHz-160, HD67086-MSTP-B2-
xxxMHz-250)
For Website information:
www.adfweb.com?Product=HD67086
For Price information:
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-0
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-20
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-40
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-80
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-160
www.adfweb.com?Price=HD67086-IP-B2-xxxMHz-250
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-0
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-20
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-40
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-80
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-160
www.adfweb.com?Price=HD67086-MSTP-B2-xxxMHz-250
Benefits and Main Features:
Very easy to configure
Triple electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
ADFweb.com S.r.l.
User Manual M-Bus / M-Bus Wireless / BACnet Slave
Document code: MN67086_ENG
For others M-Bus products see also the following link:
Converter M-Bus Wireless to
www.adfweb.com?Product=HD67082
www.adfweb.com?Product=HD67084
Converter M-Bus to
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
Analyzer / Scanner /Sniffer M-Bus
www.adfweb.com?Product=HD67031
Isolator/Repeater M-Bus
www.adfweb.com?Product=HD67032M
Gateway M-Bus / Modbus RTU
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
Gateway M-Bus / Modbus TCP
www.adfweb.com?Product=HD67044
Gateway M-Bus / PROFIBUS
www.adfweb.com?Product=HD67053M
Gateway M-Bus Concentrator
www.adfweb.com?Product=HD67054M
Gateway M-Bus Slave / Modbus RTU master
www.adfweb.com?Product=HD67059M-232
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
User Manual
Revision 1.100
Page 1 of 43
(Modbus Slave)
(Ethernet)
(RS232)
(RS485)
(on RS232)
(on RS485)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67086-IP-B2 MHz-0 Series
Summary of Contents for ADF Web HD67086-IP-B2 MHz-0 Series
- Page 1 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 1 of 43 Industrial Electronic Devices User Manual Revision 1.100 English M-Bus / M-Bus Wireless / BACnet Slave - Converter (Order Code: HD67086-IP-B2-xxxMHz-0, HD67086-IP-B2-xxxMHz-20, HD67086-IP-B2-xxxMHz-40, HD67086-IP-B2-xxxMHz-80,HD67086-IP- For others M-Bus products see also the following link: B2-xxxMHz-160, HD67086-IP-B2-xxxMHz-250) (Order Code: HD67086-MSTP-B2-xxxMHz-0, HD67086-MSTP-B2-...
-
Page 2: Updated Documentation
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 2 of 43 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you INDEX that you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 3 of 43 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 4 of 43 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 5 of 43 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67086-IP-B2-xxxMHz-0 ADFweb.com S.r.l. - Page 6 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 6 of 43 Industrial Electronic Devices Figure 1b: Connection scheme for HD67086-IP-B2-xxxMHz-xxx ADFweb.com S.r.l.
- Page 7 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 7 of 43 Industrial Electronic Devices Figure 1c: Connection scheme for HD67086-MSTP-B2-xxxMHz-0 ADFweb.com S.r.l.
- Page 8 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 8 of 43 Industrial Electronic Devices Figure 1d: Connection scheme for HD67086-MSTP-B2-xxxMHz-xxx ADFweb.com S.r.l.
- Page 9 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 9 of 43 Industrial Electronic Devices CHARACTERISTICS: The HD67086 are converters from M-Bus Wireless and M-Bus to BACnet Slave. They allows the following characteristics: Electrical isolation between Ethernet and M-Bus; Baud Rate and Parity (for M-Bus on wire) changeable with software;...
-
Page 10: Power Supply
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 10 of 43 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 15…21V AC and 18…35V DC. The consumption depends to the code of the device. For more details see the two tables below. -
Page 11: Function Modes
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 11 of 43 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’... - Page 12 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 12 of 43 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 13 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 13 of 43 Industrial Electronic Devices ETHERNET: Ethernet port is used for BACnet/IP communication and for programming the device. The Ethernet connection must be made using Connector2 of HD67086-xxx-B2-xxxMHz-0 or HD67086-xxx-B2-xxxMHz-xxx with at least a Category 5E cable.
- Page 14 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 14 of 43 Industrial Electronic Devices RS485: RS485 port is used for BACnet MS/TP communication. To terminate the RS485 line with a 120Ω resistor, it is necessary to put dip 1 ON, like in figure. The maximum length of the cable should be 1200m (4000 feet).
- Page 15 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 15 of 43 Industrial Electronic Devices M-BUS WIRELESS: The standards of M-Bus Wireless are specified in EN 13757-4. The signal is @ 868Mhz or 433 MHz or 169 MHz (in relation to the order code).
- Page 16 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 16 of 43 Industrial Electronic Devices USE OF COMPOSITOR SW67086: To configure the Converter, use the available software that runs with Windows called SW67086. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site).
-
Page 17: New Configuration / Open Configuration
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 17 of 43 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “M-Bus / M-Bus Wireless / BACnet Slave - Converter”... -
Page 18: Software Options
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 18 of 43 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 19 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 19 of 43 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 20: Set Communication
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 20 of 43 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of buses, BACnet, M- Bus and M-Bus Wireless. By Pressing the “Set Communication”... - Page 21 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 21 of 43 Industrial Electronic Devices If selected “BACnet MS/TP” the means of the fields for “BACnet” are: In the field “Baudrate” the data rate of the BACnet line is defined; In the field “Parity”...
- Page 22 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 22 of 43 Industrial Electronic Devices M-BUS By Pressing the “M-Bus” button from the main window for SW67086 (Fig. 2) the window “M-Bus Network” appears (Fig. 4). In the section “Nodes”...
- Page 23 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 23 of 43 Industrial Electronic Devices If the field “Send SND_NKE” is checked, the converter sends the “SND_NKE” frame to start the communication. In the field “Send Reset App.”...
- Page 24 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 24 of 43 Industrial Electronic Devices ECTION ODES US NODES In the field “Manufacturer ID” it is necessary to define the Manufacturer ID of the wM-Bus node. In the field “Address”...
- Page 25 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 25 of 43 Industrial Electronic Devices In the field “Variables List” it is necessary to select which type of variables definition to use. If is selected “By Type” it is necessary to fill all fields, in the section Variables, with the correct values;...
- Page 26 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 26 of 43 Industrial Electronic Devices ECTION ARIABLES Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 27 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 27 of 43 Industrial Electronic Devices If the field “From BCD to Integer” is checked the Converter converts the BCD value of variable in Integer format. This happens only if the variable is in BCD format;...
- Page 28 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 28 of 43 Industrial Electronic Devices SECTION VARIABLES (BY POSITION): Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 29 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 29 of 43 Industrial Electronic Devices Example: 0x68 – Start Byte 0xBD – L Fied 0xBD – L Field 0x68 – Start Byte 0x08 – C Field 0x02 –...
- Page 30 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 30 of 43 Industrial Electronic Devices ASTE AND ELETE TEMS By pressing the right button of the mouse over an item (Variable or Node) it is possible to Copy, Paste and Delete. It is possible to Copy a variable from a Node and copy it to another Node, or copy a Variable from a project and paste in another one.
- Page 31 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 31 of 43 Industrial Electronic Devices BACNET ENG. UNIT: By pressing to button the left window appears (Fig. 5). Is possible to insert directly the Unit (using its unique number) by compiling the “Selected BACnet Engineering Unit”...
- Page 32 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 32 of 43 Industrial Electronic Devices Possible choices for the fields used to create a variable: Type of Data: Function Field: |_Energy (Wh) [BACnet Data Type: 1] |_Instantaneous Value |_Energy (J) |_Minimum Value...
- Page 33 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 33 of 43 Industrial Electronic Devices VIFE: |_ Not Selected |_ Period of tariff months(s) |_ Credit of the nominal local legal currency units |_ Period of tariff year(s) |_ Debit of the nominal local legal currency units |_ dimensionless/ no VIF |_ Access Number (transmission count)
- Page 34 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 34 of 43 Industrial Electronic Devices |_ per second |_ # of exceeds of lower/upper limit |_ per minute |_ Date(/time) of begin/end of first/last lower/upper limit exceed[2] |_ per hour |_ Duration of limit exceed...
- Page 35 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 35 of 43 Industrial Electronic Devices Swap Identification: This field is used for select the Swap mode of Identification Number. At the moment there are these possibilities: None;...
-
Page 36: Update Device
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 36 of 43 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 37 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 37 of 43 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67086 device. Warning: If Fig.
- Page 38 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 38 of 43 Industrial Electronic Devices SCAN & DECODE FUNCTION: “SCAN & DECODE” functions are integrated in the configurator software SW67086. It is possible to access to these functions by simple click on the “...
-
Page 39: Mechanical Dimensions
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 39 of 43 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67086-xxx-B2-xxxMHz-xxx ADFweb.com S.r.l. -
Page 40: Ordering Informations
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 40 of 43 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67086 – xxx - B 2 – xxxMHz – xxx Available M-Bus ports 0: only M-Bus Wireless port 20: M-Bus Wireless port + M-Bus port (up to 20 standard M-Bus slaves (1.5mA consumption)) - Page 41 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 41 of 43 Industrial Electronic Devices ACCESSORIES: Order Code: APW020 Power Supply for M-Bus Master device that supports up to 20 Slaves Order Code: APW040 Power Supply for M-Bus Master device that supports up to 40 Slaves Order Code: APW080 Power Supply for M-Bus Master device that supports up to 80 Slaves...
- Page 42 User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 42 of 43 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
-
Page 43: Warranties And Technical Support
User Manual M-Bus / M-Bus Wireless / BACnet Slave Document code: MN67086_ENG Revision 1.100 Page 43 of 43 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
