MODBUS MAP:

Data in reading:
Input Register
Input Register
Input Register
Input Register
Data in writing:
Holding Register
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Input/Coil Status (Function 02 and Functions 01/05/15).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Type Address
0
1
2
.
749
Type Address
0
1
2
.
2047
User Manual IO-Link / Modbus TCP Slave
Document code: MN67863_ENG
Function Description
Bytes 0-1 of internal array (Position)
04
Bytes 2-3 of internal array (Position)
04
Bytes 4-5 of internal array (Position)
04
Bytes 1498-1499 of internal array
04
(Position)
Function Description
R: 03
Bytes 0-1 of internal array (Position)
W: 06/16
R: 03
Bytes 2-3 of internal array (Position)
W: 06/16
R: 03
Bytes 4-5 of internal array (Position)
W: 06/16
R: 03 Bytes 1498-1499 of internal array
(Position)
W: 06/16
