Analog Devices EVAL-ADF4602EB1Z Preliminary Technical Data page 28

EVAL-ADF4602EB1Z
C74 CAP DNI
C75 CAP DNI
C76 CAP DNI
C77 CAP DNI
C78 CAP DNI
C79 CAP 4.7uF
C80 CAP 0.1uF
C81 CAP 0.1uF
C82 CAP 0.1uF
C83 CAP 0.1uF
C84 CAP 4.7uF
C85 CAP 0.1uF
C86 CAP 0.1uF
C87 CAP 0.1uF
C88 CAP 0.1uF
C89 CAP 0.1uF
C90 CAP 0.1uF
C91 CAP 22pF
C92 CAP 1.5pF
C93 CAP 10nF
C94 CAP 10uF
C95 CAP 0.1uF
C96 CAP 0.1uF
C97 CAP 4.7uF
C98 CAP 1uF
C99 CAP 0.1uF
C100 CAP 0.1uF
C101 CAP 33pF
C102 CAP DNI
C103 CAP 10nF
C104 CAP_TBA DNI
C105 CAP 10nF
C106 CAP 0.1uF
C108 CAP DNI
C109 CAP+ 22uF
C110 CAP 0.1uF
C112 CAP 1nF
C113 CAP DNI
C115 CAP 0.1uF
C0402 SMD Capacitor
C0402 SMD Capacitor
C0402 SMD Capacitor
C0402 SMD Capacitor
C0402 SMD Capacitor
±10% C0603 CAPACITOR, 0603 4.7UF 6.3V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0603 CAPACITOR, 0603 4.7UF 6.3V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±5% C0402 CAPACITOR, 0402 22PF 50V
±5% C0402 CAPACITOR, 0402 1.5PF 50V
±10% C0402 CAPACITOR, 0402 10NF 16V
±20% C0603 CAPACITOR, 10UF X5R 6.3V 0603
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0603 CAPACITOR, 0603 4.7UF 6.3V
±10% C0603 CAPACITOR, 1UF X5R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±5% C0402 CAPACITOR, 0402 33PF 50V
C0402 SMD Capacitor
±10% C0402 CAPACITOR, 0402 10NF 16V
C0402 SMD Capacitor - Loop Filter
±10% C0402 CAPACITOR, 0402 10NF 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
C0402 SMD Capacitor
±10% RTAJ_B CAPACITOR, CASE B 22UF 16V
±10% C0402 CAPACITOR, 100NF X7R 16V
±10% C0402 CAPACITOR, 0402 1.0NF 50V
C0402 SMD Capacitor
±10% C0402 CAPACITOR, 100NF X7R 16V
Rev. PrC | Page 28 of 37
Preliminary Technical Data
Not Inserted Not Inserted
Not Inserted Not Inserted
Not Inserted Not Inserted
Not Inserted Not Inserted
Not Inserted Not Inserted
KEMET C0603C475K9PAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0603C475K9PAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
MURATA GRM1555C1H220JZ01D
PHYCOMP 2238 869 15158
AVX CM05X7R103K16AH
KEMET C0603C106M9PAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
KEMET C0603C475K9PAC
KEMET C0603C105K4PAC
KEMET C0402C104K4RAC
KEMET C0402C104K4RAC
MURATA GRM1555C1H330JZ01D
Not Inserted Not Inserted
AVX CM05X7R103K16AH
Not Inserted Not Inserted
AVX CM05X7R103K16AH
KEMET C0402C104K4RAC
Not Inserted Not Inserted
AVX TAJB226K016R
KEMET C0402C104K4RAC
PHYCOMP 2238 587 15623
Not Inserted Not Inserted
KEMET C0402C104K4RAC
Not Inserted
Not Inserted
Not Inserted
Not Inserted
Not Inserted
FEC 9227784
FEC 1288252
FEC 1288252
FEC 1288252
FEC 1288252
FEC 9227784
FEC 1288252
FEC 1288252
FEC 1288252
FEC 1288252
FEC 1288252
FEC 1288252
FEC 8819629
FEC 3019111
FEC 1216548
FEC 1288201
FEC 1288252
FEC 1288252
FEC 9227784
FEC 1288256
FEC 1288252
FEC 1288252
FEC 8819645
Not Inserted
FEC 1216548
Not Inserted
FEC 1216548
FEC 1288252
Not Inserted
FEC 197294
FEC 1288252
FEC 3019380
Not Inserted
FEC 1288252
